Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Adjuster Plug Lock Nut | 68 N.m | 50 lb ft |
| Flow Control Valve Fitting | 75 N.m | 55 lb ft |
| Cylinder Pipe Fittings | 31 N.m | 23 lb ft |
| Cylinder Pipe Retaining Plate Screw | 15 N.m | 12 lb ft |
| Inner Tie Rod Housing | 100 N-m | 74 lb ft |
| Lower Intermediate Shaft to Power Steering Gear Input Shaft Pinch Bolt | 40 N.m | 30 lb ft |
| Outer Tie Rod Retaining Nut | 60 N.m | 44 lb ft |
| Power Steering Cooler Mounting Bolts | 20 N.m | 15 lb |
| Power Steering Gear to the Frame Mounting Bolts | 110 N.m | 81 lb ft |
| Power Steering Hose Assembly to the Frame Brackets Mounting Bolts | 10 N.m | 89 lb in |
| Power Steering Hose Assembly to the Front Crossmember Bracket Mounting Bolt | 10 N.m | 89 lb in |
| Power Steering Hose Assembly to the Power Steering Gear Retaining bolt | 12 N.m | 106 lb in |
| Power Steering Hose Assembly (Pressure Hose) to the Power Steering Pump | 25 N.m | 18 lb ft |
| Power Steering Hose Assembly to the Wheel Well Bracket Mounting Bolt | 10 N.m | 89 lb in |
| Power Steering Pump Mounting Bolts | 25 N.m | 18 lb ft |
| Power Steering Pump Bracket Mounting Bolts | 50 N.m | 37 lb ft |
Fastener Tightening Specifications
Scheme 1
Scheme 2
Scheme 3
Begin the system diagnosis by reviewing the system Description and Operation. Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to SYMPTOMS - POWER STEERING SYSTEM in order to identify the correct procedure for diagnosing the system and where the procedure is located.
Review the system description and operation in order to familiarize yourself with the system functions. Refer to POWER STEERING SYSTEM DESCRIPTION AND OPERATION .
