Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Bearing Cap Bolts | 75 N.m | 55 lb ft |
| Differential Housing Cover Bolts, 8.0" Axle | 30 N.m | 20 lb ft |
| Differential Housing Cover Bolts, 8.6" Axle | 25 N.m | 18 lb ft |
| Drain Plug | 48 N.m | 35 lb ft |
| Fill Plug | 33 N.m | 24 lb ft |
| Pinion Shaft Lock Bolt | 36 N.m | 27 lb ft |
| Ring Gear Bolts | 120 N.m | 89 lb ft |
Fastener Tightening Specifications
Scheme 189
Scheme 190
Scheme 191
Scheme 192
Scheme 193
Begin the system diagnosis by reviewing the system Description and Operation. Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to SYMPTOMS - REAR DRIVE AXLE in order to identify the correct procedure for diagnosing the system and where the procedure is located.
Review the system and operation in order to familiarize yourself with the system functions. Refer to Rear Drive Axle DESCRIPTION AND OPERATION .
