HVAC System - General Servicing Procedures: Component Locations Chevrolet Tracker II

SERVICE VALVE LOCATIONS

For service valve locations, see SERVICE VALVE LOCATIONS (CARS) or SERVICE VALVE LOCATIONS (TRUCKS & VANS) table.

VehicleHighLow
2000
DaimlerChrysler Corp.
Avenger & Sebring Coupe(1)(2)
Breeze, Cirrus & Stratus(7)(4)
Concorde, Intrepid, LHS & 300M
2.7L(3)(4)
3.2L & 3.5L(5)(6)
Neon(13)(4)
Sebring Convertible(7)(4)
Ford Motor Co.
Continental(9)(10)
Contour, Cougar & Mystique
2.0L Engine(7)(11)
2.5L Engine(7)(12)
Crown Victoria, Grand Marquis & Town Car(7)(13)
Escort(8)(10)
Focus(3)(4)
LS(13)(5)
Mustang(7)(13)
Sable & Taurus(8)(11)
General Motors
"C" Body(3)(14)
"E" & "K" Bodies(3)(14)
"F" Body(9)(4)
"G" Body(3)(14)
"H" Body(7)(12)
"J" Body(7)(12)
"M" Body(9)(4)
"N" Body(9)(4)
"S" Body(9)(4)
"V" Body(9)(4)
"W" Body(9)(4)
"Y" Body(3)(12)
Saturn "J" Body(9)(11)
Saturn "Z" Body(5)(5)
2001
DaimlerChrysler Corp.
Concorde, Intrepid, LHS & 300M
2.7L(3)(4)
3.2L & 3.5L(5)(6)
Neon(13)(4)
Sebring Convertible(7)(4)
Sebring Coupe & Stratus Coupe(1)(2)
Sebring Sedan & Stratus Sedan(7)(4)
Ford Motor Co.
Continental(9)(10)
Cougar
2.0L Engine(7)(11)
2.5L Engine(7)(12)
Crown Victoria, Grand Marquis & Town Car(7)(13)
Escort(8)(10)
Focus(3)(4)
LS(13)(5)
Mustang(7)(13)
Sable & Taurus(8)(11)
General Motors
"C" Body(3)(14)
"E" & "K" Bodies(3)(14)
"F" Body(9)(4)
"G" Body(3)(14)
"H" Body(7)(12)
"J" Body(7)(12)
"M" Body(9)(4)
"N" Body(9)(4)
"S" Body(9)(4)
"V" Body(9)(4)
"W" Body(9)(4)
"Y" Body(3)(12)
Saturn "J" Body(9)(11)
Saturn "Z" Body(5)(5)
(1) On high-side liquid line, between receiver-drier and evaporator. (2) On low-side hose between evaporator and compressor. (3) On high-side liquid line. (4) On low-side suction line. (5) On top of compressor manifold. (6) On compressor manifold, closest to compressor clutch. (7) On high-side line, between compressor and condenser. (8) On extension of high-side line, between condenser and evaporator. (9) On high-side line (or extension), near condenser. (10) On low-side line (or extension), near accumulator. (11) On low-side line, between evaporator and accumulator/receiver-drier. (12) On low-side line, between accumulator/receiver-drier and compressor. (13) On accumulator/receiver-drier. (14) On low-side line, between orifice tube and evaporator.
(1)On high-side liquid line, between receiver-drier and evaporator.
(2)On low-side hose between evaporator and compressor.
(3)On high-side liquid line.
(4)On low-side suction line.
(5)On top of compressor manifold.
(6)On compressor manifold, closest to compressor clutch.
(7)On high-side line, between compressor and condenser.
(8)On extension of high-side line, between condenser and evaporator.
(9)On high-side line (or extension), near condenser.
(10)On low-side line (or extension), near accumulator.
(11)On low-side line, between evaporator and accumulator/receiver-drier.
(12)On low-side line, between accumulator/receiver-drier and compressor.
(13)On accumulator/receiver-drier.
(14)On low-side line, between orifice tube and evaporator.

SERVICE VALVE LOCATIONS (CARS)

VehicleHighLow
2000
DaimlerChrysler Corp.
Caravan, Town & Country, & Voyager(1)(2)
Dakota(3)(4)
Durango(3)(4)
Ram Pickup(3)(5)
Ram Van/Wagon(6)(7)
Ford Motor Co.
"E" Series(6)(8)
Explorer, Mountaineer & Ranger(6)(9)
F150, Expedition & Navigator(6)(9)
Excursion, F250, F350 & Super Duty(6)(5)
Villager(10)(5)
Windstar(11)(9)
General Motors
"C" & "K" Series(4)(9)
"E" & "J" Series(9)(14)
"G" Series(12)(9)
"L" & "M" Series(12)(5)
"P" Series(13)(14)
"S" & "T" Series(15)(9)
"U" Series(1)(5)
Jeep
Cherokee(6)(16)
Grand Cherokee(17)(14)
Wrangler(17)(18)
2001
DaimlerChrysler Corp.
Caravan, Town & Country, & Voyager(1)(2)
Dakota(3)(4)
Durango(3)(4)
Ram Pickup(3)(5)
Ram Van & Ram Wagon(6)(7)
Ford Motor Co.
"E" Series(6)(8)
Escape(3)(5)
Explorer, Mountaineer & Ranger(6)(9)
F150, Expedition & Navigator(6)(9)
Excursion, F250, F350 & Super Duty(6)(5)
Villager(10)(5)
Windstar(11)(9)
General Motors
"C" & "K" Series(4)(9)
"E" & "J" Series(9)(14)
"G" Series(12)(9)
"L" & "M" Series(12)(5)
"P" Series(13)(14)
"S" & "T" Series(15)(9)
"U" Series(1)(5)
Jeep
Cherokee(6)(16)
Grand Cherokee(17)(14)
Wrangler(17)(18)
(1) On high-side line, near right frame rail. (Scheme 14) (2) On low-side line, near compressor. (Scheme 14) (3) On high-side line, between condenser and evaporator, near front of engine compartment. (4) On compressor manifold. (5) On low-side line, near accumulator. (6) On high-side line, between compressor and condenser, near front of engine compartment. (7) On low-side line extension, near receiver-drier, at front of engine compartment. (8) On low-side line from accumulator, near windshield washer reservoir. (9) On accumulator/receiver-drier. (10) On high-side line extension from compressor. (11) On high-side line, between compressor and condenser, near accumulator. (Scheme 15) (12) On high-side line between evaporator and condenser, near evaporator. (13) On high-side inlet line, at evaporator. (14) On low-side outlet line, at evaporator. (15) On high-side line. (16) On low-side (suction) line, between accumulator outlet and compressor. (17) Discharge line, near compressor. (18) On liquid line, near evaporator inlet, at rear of engine compartment.
(1)On high-side line, near right frame rail. (Scheme 14)
(2)On low-side line, near compressor. (Scheme 14)
(3)On high-side line, between condenser and evaporator, near front of engine compartment.
(4)On compressor manifold.
(5)On low-side line, near accumulator.
(6)On high-side line, between compressor and condenser, near front of engine compartment.
(7)On low-side line extension, near receiver-drier, at front of engine compartment.
(8)On low-side line from accumulator, near windshield washer reservoir.
(9)On accumulator/receiver-drier.
(10)On high-side line extension from compressor.
(11)On high-side line, between compressor and condenser, near accumulator. (Scheme 15)
(12)On high-side line between evaporator and condenser, near evaporator.
(13)On high-side inlet line, at evaporator.
(14)On low-side outlet line, at evaporator.
(15)On high-side line.
(16)On low-side (suction) line, between accumulator outlet and compressor.
(17)Discharge line, near compressor.
(18)On liquid line, near evaporator inlet, at rear of engine compartment.

SERVICE VALVE LOCATIONS (TRUCKS & VANS)

Scheme 14

Scheme 14

Scheme 15

Scheme 15
