Configurable Customer Control System: Other Chevrolet Tahoe III

Memory Modules 1 illustration ~346 words

Reference Information

Schematic Reference

Steering Wheel Secondary/Configurable Control Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Steering Wheel Controls Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(ref-364488-S04114729552010063000000)
  2. «Connector Repairs»(ref-364488-S23771656832010063000000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-364488-S16423338542010063000000)
  4. «Wiring Repairs»(ref-364488-S17530456672010063000000)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

Ignition ON, observe the scan tool BCM SWC Bank 1 Status parameter. The reading should be idle and change between SW1-SW7 when pushing the appropriate switch.

Repair Procedures

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Steering Wheel Control Switch Assembly Replacement»(ref-364505-S10930342292010063000000)
  2. «Control Module References»(ref-364489-S22329914082010063000000) for BCM replacement, setup, and programming

Schematic Reference

Steering Wheel Secondary/Configurable Control Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Steering Wheel Controls Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(ref-364488-S04114729552010063000000)
  2. «Connector Repairs»(ref-364488-S23771656832010063000000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-364488-S16423338542010063000000)
  4. «Wiring Repairs»(ref-364488-S17530456672010063000000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, observe the scan tool BCM SWC Bank 1 Status parameter. The reading should be idle and change between SW1-SW7 when pushing the appropriate switch.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Steering Wheel Control Switch Assembly Replacement»(ref-364505-S10930342292010063000000)
  2. «Control Module References»(ref-364489-S22329914082010063000000) for BCM replacement, setup, and programming

Symptoms - Secondary and Configurable Customer Controls

IMPORTANTPerform the Diagnostic System Check - Vehicle before using the Symptom Tables in order to verify that all of the following conditions are true: There are no DTCs set. The control modules can communicate via the serial data link. Review the system operation in order to familiarize yourself with the system functions. Refer to Steering Wheel Controls Description and Operation .

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Schematic Reference

Steering Wheel Secondary/Configurable Control Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Steering Wheel Controls Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(ref-364488-S04114729552010063000000)
  2. «Connector Repairs»(ref-364488-S23771656832010063000000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-364488-S16423338542010063000000)
  4. «Wiring Repairs»(ref-364488-S17530456672010063000000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, observe the scan tool BCM SWC Bank 1 Status parameter. The reading should be idle and change between SW1-SW7 when pushing the appropriate switch.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Steering Wheel Control Switch Assembly Replacement»(ref-364505-S10930342292010063000000)
  2. «Control Module References»(ref-364489-S22329914082010063000000) for BCM replacement, setup, and programming

Scheme 4

Scheme 4: Steering Wheel Control Switch Assembly Replacement
Scheme 4: Steering Wheel Control Switch Assembly Replacement
CalloutComponent Name
WARNING: Refer to SIR Warning . Preliminary Procedure Disable the supplemental inflatable restraint (SIR) system. Refer to SIR Disabling and Enabling . Remove the horn switch. Refer to Steering Wheel Horn Switch Replacement .
1Steering Wheel Trim Cover (Qty: 2) Procedure: Remove the 4 horn contact screws.
2Steering Wheel Control Switch Assembly Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tip: Quantity may vary with vehicle options. Tighten: 1 N.m (9 lb in)
3Steering Wheel Control Switch Assembly (Qty: 2) Tip: Quantity may vary with vehicle options. Ensure the steering wheel control switch(es) are properly seated to the steering wheel shroud during installation.
WARNING
Refer to SIR Warning .
CAUTION
Refer to Fastener Caution .
