Special Tools
GE-28431-6: Fluorescent Dye
For equivalent regional tools, refer to Special Tools .
J-8001: Dial Indicator Set
For equivalent regional tools, refer to Special Tools .
J-8001: Dial Indicator Set
For equivalent regional tools, refer to Special Tools .
J-22610: Keystone Clamp Pliers
For equivalent regional tools, refer to Special Tools .
J 44586 Power Steering Gear Oil Seal Remover/Installer. See Special Tools .
Scheme 14
| Callout | Component Name |
|---|---|
| Preliminary Procedure: Remove the engine shield. Refer to Engine Shield Replacement . | |
| 1 | Power Steering Gear Outlet Hose Clamp Procedure: Place drain pans under the vehicle as needed. |
| 2 | Power Steering Gear Inlet Hose Retaining Plate Bolt CAUTION: Refer to Fastener Caution . Tighten: 12 N.m (106 lb in) |
| 3 | Power Steering Gear Inlet Hose Retaining Plate |
| 4 | Power Steering Gear Outlet Hose CAUTION: Refer to Power Steering Hose Disconnected Caution . Procedure Disconnect the power steering gear outlet hose from the power steering fluid cooler. Pull the power steering gear outlet hose out of the steering gear. Keep all open connections in the power steering system clean and free of debris. Use the remover/installer J 44586 to replace the steering gear seals if necessary. See Special Tools . Fill and bleed the power steering system. Refer to Power Steering System Bleeding . Special Tools: J 44586 Power Steering Gear Oil Seal Remover/Installer. See Special Tools . |
| CAUTION |
|---|
| Refer to Fastener Caution . |
| CAUTION |
|---|
| Refer to Power Steering Hose Disconnected Caution . |
CH-49009 Inner Tie Rod Wrench. See Special Tools .
Illustration Tool Number/ Description CH-49009 Inner Tie Rod Wrench GE-28431-6 J-28431-6 Fluorescent Dye J-4245 Internal Snap Ring Pliers J-6219 Pitman Shaft Seal Installer J-6278 Bearing Remover and Installer J-8001 Dial Indicator Set J-22610 Keystone Clamp Pliers J-24319-B Steering Linkage and Tie Rod Puller J-25033-C Pulley Installer J-25034-C Pulley Remover J-39570 Chassis Ear J-44586 Power Steering Gear Oil Seal Remover/Installer J-44721 Power Steering Analyzer
