Generator Battery Temperature Sensor Location
| Sensor 1 | Location 2 |
|---|---|
| Hybrid Batt Mod 1 Temperature | Hybrid Battery Module 1 |
| Hybrid Batt Mod 2 Temperature | Hybrid Battery Module 14 |
| Hybrid Batt Mod 3 Temperature | Hybrid Battery Module 27 |
| Hybrid Batt Mod 4 Temperature | Hybrid Battery Module 40 |
| Hybrid Batt Outlet Air Temperature | Air Inlet Duct near hybrid battery fan |
| Hybrid Batt Inlet Air Temperature | Clipped above Hybrid Battery Module 3 |
| 1 Scan tool parameter name 2 Battery 1 is located next to cooling fan assembly. Battery 40 is located next to drive motor generator battery control module. | |
Hybrid Battery Temperature Sensor Location
Special Tools
Illustration Tool Number / Description EL 48900 HEV Safety Kit J 46143 Cooling System Adapter J 24460-01 Cooling System Pressure Tester J 38185 Hose Clamp Pliers
