Wiper System & Washer System: Specifications Chevrolet Tahoe II

Wiper/washer Systems 7 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Plenum Reinforcement Panel Bolts9 N.m80 lb in
Washer Solvent Container Bolts9 N.m80 lb in
Wiper Arm to the Shaft Nut30 N.m22 lb ft
Wiper Motor Assembly Bolts8 N.m71 lb in
Wiper Motor Cover Screws2.6 N.m23 lb in
Wiper Transmission to the Vehicle Bolts9 N.m80 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Wiper/Washer System Schematics
Scheme 1: Wiper/Washer System Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3: Wiper/Washer System Component Views
Scheme 3: Wiper/Washer System Component Views
CalloutComponent Name
1Windshield Wiper Motor Module Electrical Connector
2Cruise Control Module (CCM) Connector
3Plenum Panel
4Cruise Control Module
5P100
6Dash Panel
7Cap For Connector, Without Cruise Control
8Cruise Control Module (CCM) Connector
9Harness Pass Through
10Windshield Wiper Motor Module

Scheme 4

Scheme 4
Scheme 4
CalloutComponent Name
1Forward Lamp Harness
2Windshield Washer Reservoir
3Windshield Washer Fluid Pump Connector
4Washer Fluid Level Sensor Connector
5Radiator Support

Scheme 5

Scheme 5
Scheme 5
CalloutComponent Name
1Hazard Button
2High Beams/Cruise/Wiper/Washer
3Cruise Control Switches
4Tilt Steering Actuator
5Inflatable Restraint Harness
6C201 Inline Connector

Scheme 6

Scheme 6
Scheme 6
CalloutComponent Name
1Air Deflector Housing
2Rear Wiper/Washer Switch
3Fog Lamp Switch

Scheme 7

Scheme 7
Scheme 7
CalloutComponent Name
1Rear Window Liftgate Harness
2Liftgate
3Window Wiper Module-Rear
