SERVICE VALVE LOCATIONS
For service valve locations, see SERVICE VALVE LOCATIONS (CARS) or SERVICE VALVE LOCATIONS (TRUCKS & VANS) table.
| (1) | On A/C pipe. (Scheme 7) |
| (2) | On suction hose. (Scheme 7) |
| (3) | On high side line, between compressor and condenser. |
| (4) | On low-side line, between evaporator and accumulator/receiver-drier. |
| (5) | On low-side line, between accumulator/receiver-drier and compressor. |
| (6) | On high pressure liquid line. |
| (7) | On evaporator to accumulator/drier suction line. |
| (8) | On accumulator. |
SERVICE VALVE LOCATIONS (CARS)
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
Scheme 31
Scheme 32
| Vehicle | High | Low | ||
|---|---|---|---|---|
| DaimlerChrysler Corp. | ||||
| Caravan, Town & Country, & Voyager | (Scheme 33) | (Scheme 33) | ||
| Dakota & Durango | ||||
| 4.7L | (1) | (2) | ||
| 5.9L | (1) | (3) | ||
| Ram Pickup | (4) | (5) | ||
| Ram Van & Ram Wagon | (Scheme 34) | (Scheme 34) | ||
| Ford Motor Co. | ||||
| Blackwood, Expedition & Navigator | (Scheme 35) | (Scheme 35) | ||
| "E" Series | (6) | (7) | ||
| Escape | (8) | (9) | ||
| Explorer & Mountaineer | (6) | (7) | ||
| Excursion, F-Series Super Duty | (Scheme 36) | (Scheme 36) | ||
| F-150 | (Scheme 37) | (Scheme 37) | ||
| Ranger | (Scheme 38) | (Scheme 38) | ||
| Villager | (6) | (7) | ||
| Windstar | (Scheme 39) | (Scheme 39) | ||
| General Motors | ||||
| Astro & Safari | (Scheme 40) | (Scheme 40) | ||
| Aztek, Montana, Rendezvous, Silhouette & Venture | (Scheme 41) | (Scheme 41) | ||
| Blazer, Jimmy Canadian, Sonoma & S-10 | (Scheme 42) | (Scheme 42) | ||
| Bravada, Envoy & Trailblazer | (Scheme 43) | (Scheme 43) | ||
| "C" & "K" Series | (Scheme 44) | (Scheme 44) | ||
| Express & Savana | (Scheme 45) | (Scheme 45) | ||
| Tracker | (Scheme 46) | (Scheme 46) | ||
| Vue | ||||
| 2.2L | (Scheme 47) | (Scheme 48) | ||
| 3.0L | (Scheme 47) | (Scheme 49) | ||
| Jeep | ||||
| Grand Cherokee | (10) | (11) | ||
| Liberty | (12) | (13) | ||
| Wrangler | (12) | (14) | ||
| (1) On liquid line between condenser and evaporator, near front of engine compartment. (2) On suction line between compressor and evaporator. (3) On compressor manifold, directly over suction port of compressor. (4) On liquid line at passenger side of engine compartment, near condenser. (5) On suction line, near accumulator. (6) On compressor manifold and tube assembly. (7) On suction accumulator/drier. (8) On condenser to evaporator line. (9) On A/C manifold and tube assembly. (10) On liquid line near receiver/drier. (11) On suction line near evaporator at rear of engine compartment. (12) On refrigerant line, near discharge port of compressor. (13) On liquid line at side of engine compartment, near condenser. (14) On liquid line at rear of engine compartment, near evaporator inlet tube. | ||||
| (1) | On liquid line between condenser and evaporator, near front of engine compartment. |
| (2) | On suction line between compressor and evaporator. |
| (3) | On compressor manifold, directly over suction port of compressor. |
| (4) | On liquid line at passenger side of engine compartment, near condenser. |
| (5) | On suction line, near accumulator. |
| (6) | On compressor manifold and tube assembly. |
| (7) | On suction accumulator/drier. |
| (8) | On condenser to evaporator line. |
| (9) | On A/C manifold and tube assembly. |
| (10) | On liquid line near receiver/drier. |
| (11) | On suction line near evaporator at rear of engine compartment. |
| (12) | On refrigerant line, near discharge port of compressor. |
| (13) | On liquid line at side of engine compartment, near condenser. |
| (14) | On liquid line at rear of engine compartment, near evaporator inlet tube. |
SERVICE VALVE LOCATIONS (TRUCKS & VANS)
