Electronic Suspension System - Automatic Level Control: Specifications Chevrolet Tahoe II

Electronic Suspension 3 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Air Compressor to Frame Nuts15 N.m11 lb ft
Air Line Tube Repair Nut8 N.m70 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Automatic Level Control Suspension Schematics
Scheme 1: Automatic Level Control Suspension Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3: Automatic Level Control Suspension Component Views
Scheme 3: Automatic Level Control Suspension Component Views
CalloutComponent Name
1Rear Crossmember Frame
2Automatic Level Control Compressor
