COMPONENT LOCATIONS
| Component | Location (Fig. No.) |
|---|---|
| Brake Pressure Modulator Valve (BPMV) | Driver Side Of Engine Compartment At Wheel House (Scheme 4) |
| Data Link Connector (DLC) | Under Driver Side Of Instrument Panel (Scheme 5) |
| Inflatable Restraint Diagnostic Energy Reserve Module (DERM) | Behind Center Of Instrument Panel |
| Powertrain Control Module (PCM - Gasoline) | Under Passenger Side Of Instrument Panel (Scheme 6) |
| Powertrain Control Module (PCM - Diesel) | Under Passenger Side Of Instrument Panel (Scheme 7) |
| Radio Receiver | Behind Center Of Instrument Panel (Scheme 8) |
| Remote Keyless Entry Module (RKEM) | Behind Center Of Instrument Panel |
| C100 | Driver Rear Of Engine Compartment At Bulkhead (Scheme 4) |
| C200 | Behind Passenger Side Of Instrument Panel, In Foam Wrap (Scheme 6) |
| C298 | Behind Driver Side Of Instrument Panel, Near Convenience Center (Scheme 9) |
| P101 | Passenger Rear Of Engine Compartment At Bulkhead |
| G103 (VIN H & K) | Driver Front Of Engine, Near Thermostat Housing (Scheme 10) |
| G103 (VIN N) | Driver Front Of Engine, Near Thermostat Housing (Scheme 11) |
| S103 | Engine Harness, Near Ignition Coil Breakout |
| S103 (VIN F) | Engine Harness, Near A/C High Pressure Switch |
| S103 (VIN P) | Engine Harness, Near Underhood Lamp Breakout |
| S103 (VIN Z, H, K & N) | Engine Harness, Near Generator Cable Breakout |
| S215 | Instrument Panel Harness, Near Instrument Panel Breakout |
| S227 | Instrument Panel Harness, Near Turn Signal Flasher Breakout |
