COMPONENT LOCATIONS
| Component | Location |
|---|---|
| Convenience Center-I/P Harness | Under LH Side Of I/P, On Bulkhead. (Scheme 44)& (Scheme 45). |
| Data Link Connector (DLC) | Below Left Side Of I/P |
| Door Lock Motor, LH Front | Inside Door, Near Free Edge Latch |
| Door Lock Motor, LH Rear | Inside Door, Near Free Edge Latch |
| Door Lock Motor, RH Front | Inside Door, Near Free Edge Latch |
| Door Lock Motor, RH Rear | Inside Door, Near Free Edge Latch |
| Door Lock Motor, RH Rear Cargo Door | Inside Door, Lower Portion, Near Free Edge |
| Door Lock Relay. | Under Center Portion Of I/P, Near RKE Module. (Scheme 47) |
| Door Lock Switch, LH Front | On Door Trim Panel |
| Door Lock RH Front | On Door Trim Panel |
| Fuse Block-I/P Harness. | Lower LH Side Of I/P. (Scheme 41) |
| Remote Keyless Entry Module | Under Center Portion Of I/P. (Scheme 42) |
| C208 | Inside LH "A" Pillar, Lower Portion. (Scheme 48) |
| C209 | Inside LH "A" Pillar, Lower Portion. (Scheme 48) |
| C210 | At Convenience Center. (Scheme 44) |
| C213 | Inside RH "A" Pillar, Lower Portion. (Scheme 48) |
| C222 | At Convenience Center. (Scheme 45) |
| C299 | Behind RH Side Of I/P, Above HVAC Evaporator Housing. (Scheme 43) |
| C301 | LH Front Kick Panel. (Scheme 45) |
| C302 | LH Front Kick Panel. (Scheme 45) |
| C497 | RH "B" Pillar. (Scheme 46) |
| C499 | RH "B" Pillar. (Scheme 46) |
| G200 | Behind LH Side Of I/P, Below Fuse Block |
| S204 | I/P Harness, About 4 cm Left Of Steering Column Connector Breakout |
| S213 | I/P Harness About 16 cm Right Of Fuse Block Breakout |
| S213 (Crew Cab, VIN F) | I/P Harness About 16 cm Right Of Breakout For LH Door Jamb Switch |
| S213 (Diesel) | I/P Harness About 16 cm Right Of Headlamp Dimmer Switch Breakout |
| S246 (Crew Cab) | Crossbody Harness, 42 cm Left Of LH Door Breakout |
| S246 (Utility, Pickup, Extended Cab) | Crossbody Harness, 6 cm Right Of Rear Body Breakout |
| S251 (Utility, Crew Cab, Pickup, Extended Cab) | Crossbody Harness, 6 cm Left Of LH Seat Breakout |
| S255 (Suburban, Crew Cab, Pickup, Extended Cab) | Crossbody Harness, 12 cm Right Of I/P Harness Breakout |
| S257 | Crossbody Harness, 14 cm Right Of Door Lock Relay Breakout |
| S258 | Crossbody Harness, 6 cm Right Of Door Lock Relay Breakout |
| S261 | Crossbody Harness, 5 cm Right Of LH Seat Breakout |
| S265 (Suburban) | Crossbody Harness, 6 cm Left Of LH Door Breakout |
| S265 (Utility) | Crossbody Harness, 26 cm Right Of I/P Harness Breakout |
COMPONENT LOCATIONS
Scheme 41
Scheme 42
Scheme 43
Locating Convenience Center & C210. Scheme 44
Scheme 45
Scheme 46
Scheme 47
Scheme 48
Scheme 49
- Ground pin "G" of the Data Link Connector (DLC). The receiver will respond by locking and unlocking doors within 2 seconds. (Scheme 49)
- Press any button of the first transmitter to be programmed.
- The control module will respond by locking/unlocking doors and activating rear window release.
- Press any button of the second transmitter to be programmed (if used).
- The control module will respond by locking/unlocking doors and activating the rear window release.
- Remove the ground applied to the reprogramming connector.
- Transmitter operation is verified by locking and unlocking the doors and activating the rear window release.
