VIN LOCATION
The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.
VIN CODE ID EXPLANATION
Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.
VIN Code ID Explanation. Scheme 1
SEVERE & NORMAL SERVICE DEFINITIONS
Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions
Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions.
Severe Service
- Short Trips (4 Miles Or Less)
- Towing Or Heavily Loaded
- Severe Dust Conditions
- Hot Weather, Stop-And-Go Driving
- Extensive Idling Conditions (Taxi Or Delivery Type Service)
Normal Service
- Driven More Than 10 Miles Daily
- No Severe Service Operating Conditions
CAMSHAFT TIMING BELT
Replace the camshaft timing belt every 60,000 miles.
| CAUTION | Failure to replace a Faulty camshaft timing belt may result in serious engine damage. |
The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".
Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.
Belts or components should be inspected and replaced if any of the following conditions exist
- Cracks Or Tears In Belt Surface
- Missing, Damaged, Cracked Or Rounded Teeth
- Oil Contamination
- Damaged Or Faulty Tensioners
- Incorrect Tension Adjustment
Scheme 2
Scheme 3
Note. For more information regarding camshaft timing belt service refer to the 1.0L 3-CYL article in the ENGINES section.
Scheme 4
Note. For more information regarding lifting and hoisting refer to the JACKING & HOISTING article in the WHEEL ALIGNMENT section.
WHEEL TIGHTENING
All wheel lug nuts should be tightened to 44 ft. lbs. (60 N.m). If wheels are equipped with locking type lug nuts, ALWAYS position the "Keyed" nut opposite the valve stem.
TIRE INFLATION
Tire inflation specifications and recommended tire size can be found on the information decal located on the driver's door or door pillar.
BATTERY SPECIFICATIONS
| CAUTION | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section. |
All models use group 26-60 batteries.
AIR CONDITIONING MAINTENANCE
| WARNING | NEVER add A/C refrigerant to correct a non-cooling problem unless pressure gauges are connected to the system by a certified technician. Lack of cooling may be caused by a restriction, therefore adding refrigerant can cause a dangerous pressure rise. |
ANTI-LOCK BRAKE SYSTEM (If Equipped)
The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by improperly installed or high output radio transmitting equipment. Since this interference could cause the possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals.
On models equipped with anti-lock brake systems, ALWAYS observe the following cautions
- DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
- DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
- Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.
REPLACING BLOWN FUSES
Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.
BATTERY WARNING
| WARNING | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION section. |
CATALYTIC CONVERTER
| CAUTION | Continued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle. |
ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS
| WARNING | Many solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component. |
ENGINE OIL
| CAUTION | Never use non-detergent or straight mineral oil. |
FUEL SYSTEM SERVICE
| WARNING | Relieve fuel system pressure prior to servicing any fuel system component (fuel injection models). |
HALOGEN BULBS
Halogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs.
RADIATOR CAP
| CAUTION | Always disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot. |
RADIATOR FAN
When working near the radiator fan, always disconnect the fan motor lead or be sure to turn the ignition switch to the OFF position. The radiator fan is temperature-controlled and could start at any time, for up to 15 minutes even after engine is turned off.
TURBOCHARGED ENGINES
| CAUTION | NEVER "rev" a turbocharged engine before shutting it off, or turbocharger bearings may be damaged during run down. |
WARRANTY INFORMATION
| CAUTION | Always refer to customer's copy of warranty information for specific model application and/or coverage limitations. |
BUMPER-TO-BUMPER PLUS COVERAGE LIMITED WARRANTY
Everything is covered for 3 years or 50,000 miles, whichever occurs first. Warranty covers repairs to any vehicle components (tires excluded) which have proven defective in material and workmanship during normal use. Warranty repairs (parts and labor) will be made by the dealer at no charge using new or remanufactured. This warranty is subject to a 100 deductible for each repair visit after the first year or 12,000 miles, whichever occurs first. Maintenance items are only covered up to their first scheduled replacement interval.
CORROSION COVERAGE
Covers any body sheet metal panel that is perforated due to corrosion. Coverage is for 6 years or 100,000 miles, whichever occurs first.
EMISSIONS "DEFECT" & "PERFORMANCE" WARRANTIES (FEDERAL)
Defect Warranty ensures that vehicle meets applicable EPA regulations and that vehicle's emission control system is free from defects in materials and workmanship for a period of 5 years or 50,000 miles, whichever occurs first.
The Performance Warranty covers all costs of repairing or adjusting any components or parts as needed in order for the vehicle to pass a Federally required state or local emissions test.
Other emission control parts related to these components are covered by the Performance Warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered.
EMISSION "PERFORMANCE" WARRANTY (CALIFORNIA)
If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure that vehicle passes the inspection. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.
EMISSION "DEFECT" WARRANTY (CALIFORNIA)
If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.
Some emission-related parts are warranted for 7 years or 70,000 miles whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.
Scheme 5
Note. A 15-Amp A/C fuse is located on engine firewall. Cruise control is fitted with a 1-Amp in-line fuse.
- 1 - 10 Amp - Right Side Headlights
- 2 - 10 Amp - Left Side Headlights
- 3 - 15 Amp - Stoplights
- 4 - 15 Amp - Dome Light, High Beam Indicator, Door Warning, Horn
- 5 - 5 Amp - License Light, Instrument Panel Illumination
- 6 - 15 Amp - Right Side Marker & Park Lights
- 7 - 15 Amp - Left Side Marker & Park Lights
- 8 - 20 Amp - Ignition Coil, Distributor, Engine Computer, Radiator Fan, Fuel Gauge, Temperature Gauge, Warning Indicators
- 9 - 20 Amp - Heater Control
- 10 - 20 Amp - Rear Defogger
- 11 - 15 Amp - Front & Rear Wiper/Washer
- 12 - 10 Amp - Turn Signal Flasher, Back-Up Lights
- 13 - 15 Amp - Hazard Flasher
- 14 - 15 Amp - Radio, Cigarette Lighter
