CASTER SPECIFICATION TABLE
Measure ride height. see scheme 8 Use ride height measurement (measurement "BC") with the following table to find the proper caster setting for vehicle.
Scheme 1
Scheme 1: CASTER SPECIFICATION TABLE
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Astro & Safari |
| Tie Rod Adjustment Sleeve Clamp Bolts | 14 (19) |
| Upper Control Arm Nuts (1) | 75-90 (100-122) |
| Wheel Lug Nuts | 90 (122) |
| "C" & "K" Series |
| Upper Control Arm Nuts (1) | 75-90 (100-122) |
| Tie Rod Adjustment Sleeve Clamp Bolts | 14 (19) |
| Wheel Lug Nuts |
| Dual Rear Wheels | 125 (170) |
| Single Wheels | 105 (142) |
| "G", "P", "R" & "V" Series |
| Tie Rod Adjustment Sleeve Clamp Bolts |
| "V" Series | 40 (54) |
| All Others | 14 (19) |
| Upper Control Arm Nuts |
| G10/25 & R10/15 | 70 (95) |
| All Others | 105 (142) |
| Wheel Lug Nuts |
| G10/25 & R10/15 | 100 (136) |
| V10/15 (Aluminum) | 100 (136) |
| V10/15 (Steel) | 90 (122) |
| G30/35 & R/V 20/35 |
| Single Wheels | 120 (163) |
| Dual Wheels | 140 (190) |
| "P" Series |
| Single Wheels | 120 (163) |
| Dual Wheels (8 Studs) | 140 (190) |
| Dual Wheels (10 Studs) | (2) 175 (240) |
| Lumina APV, Silhouette & Trans Sport |
| Strut-to-Knuckle Bolts | 148 (201) |
| Tie Rod Lock Nut | 45 (61) |
| Wheel Lug Nuts | 100 (136) |
| "S" & "T" Series |
| Tie Rod Adjustment Sleeve Clamp Bolts | 14 (19) |
| Upper Control Arm Nuts |
| "S" Series | 65 (88) |
| "T" Series | 70 (95) |
| Wheel Lug Nuts |
| Aluminum | 90 (122) |
| Steel | 73 (99) |
| (1) Adjustment Kit (G.M. 15538596) must be used on "C" & "K" Series vehicles. (2) Tighten in 2 steps. Initially tighten all studs to 140 ft. lbs. (190 N.m) and then tighten all studs to 175 ft. lbs. (240 N.m). |
| (1) | Adjustment Kit (G.M. 15538596) must be used on "C" & "K" Series vehicles. |
| (2) | Tighten in 2 steps. Initially tighten all studs to 140 ft. lbs. (190 N.m) and then tighten all studs to 175 ft. lbs. (240 N.m). |
