Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Inside Rearview Mirror Screw | 1.8 N.m | 16 lb in |
| Outside Rearview Mirror Mounting Bolt | 9 N.m | 80 lb in |
| Outside Rearview Mirror Motor Screw | 3 N.m | 27 lb in |
Fastener Tightening Specifications
Scheme 1
Symptoms - Mirrors
Note. The following steps must be completed before using the symptom tables.
- Perform the «Diagnostic System Check - Vehicle»(ref-544470-S31312478522013042400000) before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
- Review the system operation in order to familiarize yourself with the system functions. Refer to «Outside Mirror Description and Operation»(ref-544489-S37814905112013042400000) .
