Arrows and Symbols
This service manual uses various symbols in order to describe different service operations.
Scheme 2
| Callout | Component Name |
|---|---|
| 1 | Front of Vehicle |
| 2 | View Detail |
| 2 | View Detail |
| 3 | Ambient Air Mixed with Another Gas or Indicate Temperature Change |
| 4 | Motion or Direction |
| 5 | View Angle |
| 6 | Dimension (1:2) |
| 7 | Ambient/Clean Air Flow or Cool Air Flow |
| 8 | Lubrication Point- Oil or Fluid |
| 9 | Task Related |
| 10 | Sectioning (1:3) |
| 11 | Gas Other Than Ambient Air or Hot Air Flow |
| 12 | Lubrication Point- Grease or Jelly |
| 13 | Multidirectional Arrow |
Acronyms and Units
| Acronym | Meaning | Definition |
|---|---|---|
| 2WD | Two-Wheel Drive | Indicates that a vehicle has 2 driven wheels OR that a 4WD vehicle uses only 2 wheels for propulsion. So it can be the description of a vehicle configuration OR the operational mode of the drivetrain. |
| 4WD | Four-Wheel Drive | Four-wheeled vehicle with a drivetrain that allows all four wheels to receive power from the engine simultaneously which provides better control on various surfaces. Can be used to describe the configuration of the vehicle OR as the operational mode of the drivetrain. 4WD vehicles usually can turn 2 wheels off to be in a 2WD mode. See also AWD. |
| A/C | Air Conditioning | The cooling and dehumidification of indoor air for thermal comfort. |
| A/D | Analog to Digital | Used in context of converting electrical analog signals to digital signals. |
| ABS | Antilock Braking System | System on motor vehicles which prevents the wheels from locking while braking which helps the driver maintain control in heavy braking conditions. |
| AC | Alternating Current | An electrical current whose magnitude and direction vary cyclically. |
| AM | Amplitude Modulation | Method of impressing data onto an alternating-current (AC) carrier waveform. |
| APP | Accelerator Pedal Position | A pedal that controls the throttle valve. |
| AWD | All-Wheel Drive | All-wheel-drive systems are designed to function on all types of surfaces, both on- and off-road, and most of them cannot be switched off. This can also be called full-time four wheel drive. See also 4WD. |
| AWG | American Wire Gauge | American wire gauge is a standardized wire gauge system used since 1857 predominantly in the United States for the diameters of round, solid, nonferrous, electrically conducting wire. E.g. a wire of AWG10 has a diameter of 2.588mm, AWG20 corresponds to a diameter of 0.812mm. |
| B+ | Battery Positive Voltage | The electrical potential on the positive terminal of the battery. |
| BARO | Barometric Pressure | Atmospheric pressure as measured by a barometer. |
| BCM | Body Control Module | This module supplies vehicle occupants with visual and audible information and controls various vehicle functions |
| BECM | Battery Energy Control Module | Control module used to regulate the battery voltage. |
| BPP | Brake Pedal Position | Position of the foot pedal that moves a piston in the master brake cylinder. |
| CAN | Controller Area Network | Serial data connection between control modules by Bosch |
| CCM | Chassis Control Module | The module that controls various vehicle functions on the Chassis, like Engine/Trans Mount, Active Grille Air Shutter, Load Leveling, etc |
| CD | Compact Disc | A small optical disk on which data such as music, text, or graphic images is digitally encoded. |
| CNG | Compressed Natural Gas | This a substitute for gasoline or diesel fuel. It is made by compressing natural gas (which is mainly composed by methane (CH4), in a percentage range of 70% to 98%) |
| CO | Carbon Monoxide | This is a product of the incomplete combustion of carbon-containing compounds, at room temperature this is a gas. It consists of one carbon atom covalently bonded to one oxygen atom. |
| CO2 | Carbon Dioxide | Chemical compound composed of two oxygen atoms covalently bonded to a single carbon atom. |
| CPA | Connector Position Assurance | Part of an electrical connector that prevents the connector from moving out of its socket. Usually needs to be pressed to unlock the connector when disconnecting it. |
| CPP | Clutch Pedal Position | A lever operated with the foot that controls the coupling that connects or disconnects driving and driven parts of a driving mechanism. |
| CV | Constant Velocity | Used in conjunction with CV joints, which connect two shafts at an angle while both shafts always have the same rotational speed without variations. |
| CVT | Continuously Variable Transmission | A transmission in which the ratio of the rotational speeds of two shafts, as the input shaft and output shaft of a vehicle or other machine, can be varied continuously within a given range, providing an infinite number of possible ratios which improves fuel economy. |
| D | Drive | D on the transmission gear selector lever. |
| DAB | Digital Audio Broadcast | Technology for broadcasting of audio using digital radio (carries information via digital signal) transmission. |
| DC | Direct Current | Continuous current, constant flow of electric charge. |
| DLC | Data Link Connector | This is an electronic connector typically located underneath the driver's side dashboard, just above the pedals. The connector has 16 pins. |
| DMM | Digital Multimeter | Electronic measuring instrument that combines several functions in one unit. The most basic instruments include an ammeter, voltmeter, and ohmmeter. |
| DOHC | Dual Overhead Camshaft | Dual overhead camshafts (DOHC) are higher performance engines, they produce more power, and can run at higher speeds because they allow an engine to have four valves per cylinder. Each camshaft operates two of the valves, one camshaft handles the intake valves, and one handles the exhaust valves |
| DPF | Diesel Particulate Filter | Device designed to remove diesel particulate matter or soot from the exhaust gas of a diesel engine. |
| DRL | Daytime Running Lamps | White lights mounted on the front of an automobile that automatically switch on when the key is turned and are intended for daytime use, to increase the visibility of the automobile. |
| DSCC | Distance Sensing Cruise Control | A type of cruise control that automatically maintains the distance between vehicles. |
| DSP | Digital Signal Processor | A specialized microprocessor designed specifically for digital signal processing, generally in real-time computing. |
| DTC | Diagnostic Trouble Code | An electronic signal stored in an automotive computer, indicating the presence of a fault detected by that computer. |
| DVD | DVD | A popular optical disc storage media format the size of a CD. Used mainly for movies but also for data. DVD has no spelled out version (officially it does not mean Digital Video Disc or Digital Versatile Disc, it just means DVD). |
| EBCM | Electronic Brake Control Module | This module contains a microprocessor and software for antilock braking system operation. |
| ECM | Engine Control Module | This electronic module works with a vehicle's sensors and engine control devices to insure that the engine operates at maximum efficiency and performance. It performs three vital functions. Receives electronic signals from engine sensors. Analyzes the data and makes an engine performance decision (based on the pre-set parameters within the unit). Sends an "output command" to an actuator that adjusts engine performance. |
| ECT | Engine Coolant Temperature | A measure of how hot or cold the fluid which flows through the engine in order to prevent its overheating, transferring the heat produced by the device to other devices that utilize or dissipate it. |
| EEPROM | Electrically Erasable Programmable Read-Only Memory | A non-volatile storage chip used in computers and other devices to store small amounts of volatile data, e.g. calibration tables or device configuration. |
| EGR | Exhaust Gas Recirculation | Is an NOx (nitrogen oxide and nitrogen dioxide) reduction technique used in most gasoline and diesel engines. EGR works by recirculating a portion of an engine's exhaust gas back to the engine cylinders. |
| EMI | Electromagnetic Interference | Electromagnetic interference (also called radio frequency interference) is a disturbance that affects an electrical circuit due to either electromagnetic conduction or electromagnetic radiation emitted from an external source. |
| ESD | Electrostatic Discharge | The sudden and momentary electric current that flows between two objects at different electrical potentials. |
| EV | Electric Vehicle | A category of vehicles that only have an electric drive system. |
| EVAP | Evaporative Emission | A system that controls the fuel fumes in the fuel tank. |
| FM | Frequency Modulation | In telecommunication this is a way to convey information over a carrier wave by varying its frequency. |
| FWD | Front-Wheel Drive | A form of engine/transmission layout used in motor vehicles, where the engine drives the front wheels only. |
| GMLAN | General Motors Local Area Network | A local-area network is a computer network covering a small geographic area, like a home or vehicle. This specific type of LAN connects several controllers inside the vehicle and was developed by General Motors. |
| GPS | Global Positioning System | Satellite-based navigation system made up of a network of 24 satellites placed into orbit by the U.S. Department of Defense. |
| GSM | Global System for Mobile Communications | Globally accepted standard for digital cellular communication. |
| GVW | Gross Vehicle Weight | Maximum total weight of a road vehicle or trailer that is loaded, including the weight of the vehicle itself plus fuel, passengers, cargo, and trailer tongue weight. |
| HD | Heavy Duty | Robust design to accommodate large work loads. |
| HID | High Intensity Discharge | A type of light that produces a bright light by using gas filled bulbs. (gas is usually mercury, metal halide, and high-pressure sodium) Uses very little battery power and is a very "cool" light. |
| HO2S | Heated Oxygen Sensor | Heated oxygen sensors have an internal heater circuit that brings the sensor up to operating temperature more quickly than an unheated sensor. An oxygen sensor must be hot (about 600-650°F) before it will generate a voltage signal. The hot exhaust from the engine will provide enough heat to bring an O2 sensor up to operating temperature. |
| HVAC | Heating Ventilation Air Conditioning | This system is sometimes referred to as climate control. Ventilation air ducts installed throughout a vehicle that supply conditioned air to a room through rectangular or round outlet vents. |
| I 2 C | Inter-Integrated Circuit | Serial data connection between Integrated Circuits (microchips) inside a control module invented by Phillips |
| IAT | Intake Air Temperature | Temperature of the air entering intake air flow system of the engine. |
| ICE | Internal Combustion Engine | An engine in which the combustion of fuel and an oxidizer (typically air) occurs in a confined space called a combustion chamber. |
| ID | Identification | Number or Code that identifies a component or control module. Can be written on the part or be transmitted on a bus or via radio. |
| ISP | Internet Service Provider | A company that furnishes corporations and individual consumers with various services, mainly access to the Internet. |
| ISS | Input Shaft Speed | Rotational speed of the input shaft of a transmission. |
| LAN | Local Area Network | Standard network connection PC's. |
| LCD | Liquid Crystal Display | A thin, flat display device made up of any number of color or monochrome pixels arrayed in front of a light source or reflector. |
| LED | Light Emitting Diode | Small light bulbs that fit easily into an electrical circuit they do not have a filament that will burn out, and they do not get especially hot. They are illuminated solely by the movement of electrons in a semiconductor material. |
| LIN | Local Interconnect Network | Computer networking bus system used within automotive network architectures. Similar to CAN, but cheaper and less powerful. |
| LPG | Liquefied Petroleum Gas | A mixture of mainly propane and butane, produced commercially and stored under pressure to keep it in a liquid state. |
| MAF | Mass Air Flow | The amount of air drawn into the engine |
| MAP | Manifold Absolute Pressure | Pressure in the engine intake system after the throttle valve referenced to a perfect vacuum. |
| MDI | Multiple Diagnostics Interface | A device used by GM dealers that enables a PC to communicate with the control modules in a vehicle. |
| MIL | Malfunction Indicator Lamp | An indicator of the internal status of a car engine. |
| MOST | Media Oriented Systems Transport | Serial communication bus to transmit audio and video information. |
| N | Neutral | A state of the transmission in which it is not engaged. |
| NiMH | Nickel Metal Hydride | A type of rechargeable battery that uses a hydrogen absorbing alloy for the negative electrode. |
| NOx | Nitrogen Oxides | Refers to any of the following oxygen compounds of nitrogen or a mixture of them. Nitric Oxide, Nitrogen dioxide, Nitrous Oxide, Dinitrogen trioxide, Dinitrogen tetroxide, Dinitrogen pentoxide. |
| O2 | Oxygen | A colorless, odorless, tasteless, gaseous chemical element with the chemical symbol O and atomic number 8. |
| O2S | Oxygen Sensor | An electronic device that measures the proportion of oxygen (O2) in the gas or liquid being analyzed. |
| OBD | On-Board Diagnostic | A generic term referring to a vehicle's self-diagnostic and reporting capability. |
| OEM | Original Equipment Manufacturer | A producer that provides a product to its customers, who proceed to modify or bundle it before distributing it to their customers. |
| OSS | Output Shaft Speed | Rotational speed of the output shaft of a transmission. |
| P | Park | A state in which the transmission is set so one can leave the vehicle. |
| PCB | Printed Circuit Board | A thin plate on which chips and other electronic components are placed. |
| PCM | Powertrain Control Module | A control module that features the functions of both, the engine and the transmission control module. |
| PCMCIA | Personal Computer Memory Card Industry Association | An international standards body and trade association with over 100 member companies that was founded in 1989 to establish standards for Integrated Circuit cards and to promote interchangeability among mobile computers where ruggedness, low power, and small size were critical. |
| PIN | Personal Identification Number | A secret numeric password shared between a user and a system that can be used to authenticate the user to the system. |
| PPE | Personal Protective Equipment | Protective clothing, helmets, goggles, or other garment designed to protect the wearer's body from injury. |
| PRNDL | Park, Reverse, Neutral, Drive, Low | Park, Reverse, Neutral, Drive, Low (automatic transmission positions). |
| PTC | Positive Temperature Coefficient | Refers to materials that experience an increase in electrical resistance when their temperature is raised. |
| PTO | Power Take-Off | A splined driveshaft, usually on a tractor or truck that can be used to provide power to an attachment or separate machine. This mechanism allows implements to draw energy from the tractor's engine. |
| PVC | Polyvinyl Chloride | A thermoplastic copolymer. |
| PWM | Pulse Width Modulation | Square shaped type of signal that carries the information in the ratio between on and off times. |
| R | Reverse | Rearward: directed or moving toward the rear |
| RAM | Random Access Memory | A type of computer data storage. It today takes the form of integrated circuits that allow the stored data to be accessed in any order. |
| RCT | Radiator Coolant Temperature | This is the heat intensity of the radiator coolant measured in degrees. The radiator is a part of the cooling system that removes the engine heat. Coolant is a mixture of water and antifreeze (ethylene glycol) which lowers the freezing point of the water in the coolant system, this fluid also picks up heat from the engine and transfers it to the air. |
| RDS | Radio Data System | A standard from the European Broadcasting Union for sending small amounts of digital information using conventional FM radio broadcasts. |
| RF | Radio Frequency | A frequency or rate of oscillation within the range of about 3 Hz and 300 GHz. This range corresponds to frequency of alternating current electrical signals used to produce and detect radio waves. |
| ROM | Read-Only Memory | A class of storage media used in computers and other electronic devices. Data stored in ROM cannot be modified. |
| RPO | Regular Production Option | A three digit/letter code given to parts, assemblies, and systems originally installed on the vehicle. These RPO codes designate options and are assigned by General Motors. |
| RSA | Rear Seat Audio | An auxiliary set of controls that operate the main audio system from the rear seat. Rear passengers can also operate a different media source than the front passengers. |
| RWD | Rear-Wheel Drive | A common engine/transmission layout in which the engine is in the front of the vehicle, but the front mid-engine, rear mid-engine and rear engine layouts are also used. |
| SCV | Speed Controlled Volume | The volume control is set for a desired sound level in the vehicle as the vehicle increases its speed, the sound level is adjusted. |
| SDM | Sensing and Diagnostic Module | The name given to air bag modules used in General Motors vehicles. |
| SIM | Subscriber Identity Module | Part of a removable smart card Integrated Circuit Card. This is used for mobile cellular telephone devices such as mobile computers and mobile phones. SIM cards securely store the service-subscriber key used to identify a subscriber. The SIM card allows users to change phones by simply removing the SIM card from one mobile phone and inserting it into another mobile phone or broadband telephony device. |
| SIR | Supplemental Inflatable Restraint | Technical term for the air bag. Air bag is a stretchable membrane, which inflates during an automobile accident to provide cushioning to the passenger's head and torso to prevent injury to the passengers. |
| SPI | Serial Peripheral Interface | This is an interface that enables the serial (one bit at a time) exchange of data between two devices. An SPI operates in full duplex mode. This means that data can be transferred in both directions at the same time. It is a standard bus technology like CAN or I2C. |
| SPS | Service Programming System | System that enables repair facilities to update the software in control modules. |
| SUV | Sport Utility Vehicle | A passenger vehicle which combines the towing capacity of a pickup truck with the passenger-carrying space of a minivan. |
| SVS | Service Vehicle Soon | Indicator lamp or symbol for a malfunction related to a vehicle component or system. |
| TA | Traffic Announcement | Message spoken on radio regarding the movement of vehicles or pedestrians through an area or along a route. The buttons on radios that enable this announcements are also often labeled TA. |
| TAC | Throttle Actuator Control | A motor which moves the engine throttle plate or valve, controlled by the engine control module. A throttle plate limits the amount of air entering a internal combustion gasoline engine. |
| TAP | Transmission Adaptive Pressure | The transmission control module learns each component's characteristics and adjusts fluid pressure accordingly. |
| TCC | Torque Converter Clutch | Resides in a torque converter to connect an engine to an automatic transmission. The clutch is applied when conditions are correct to achieve a 1:1 ratio of engine crankshaft to transmission input shaft. |
| TCM | Transmission Control Module | A module that controls electronic automatic transmissions. It uses sensors from the vehicle as well as data provided by the Engine Control Module to calculate how and when to change gears in the vehicle for optimum performance, fuel economy and shift quality. |
| TDC | Top Dead Center | The piston is in its highest position relative to the combustion chamber. |
| TIS | Techline Information System | The PC-based global dealership diagnostic software that provides the technician the ability to reference the most recent service information via the service department's computer. |
| TPA | Terminal Position Assurance | An additional locking mechanism inside an electric connector that holds the pins in place. |
| TV | Television | A telecommunication system for broadcasting and receiving moving pictures and sound over a distance. |
| USB | Universal Serial Bus | A type of communication bus connection between a computer and a peripheral device. |
| VCI | Vehicle Communications Interface | A diagnostic tool that communicates to modules of multiple communication protocols in a vehicle by converting vehicle serial data into PC serial data communication. |
| VIN | Vehicle Identification Number | Used by manufacturers to uniquely identify motor vehicles using 17 characters. |
| VSCM | Vehicle Stability Control Module | This module uses information from several sensors to detect a loss of vehicle traction, then works with the antilock brake system to apply individual brakes to help keep the vehicle on its intended path. |
| VSS | Vehicle Speed Sensor | Sends data regarding how fast the car is traveling at the moment of driving. It is designed to be able to record the rate at which the vehicle's crankshaft is spinning. |
| WOT | Wide Open Throttle | When the throttle blade or valve is at its maximum open position, allowing maximum air to enter an internal combustion gasoline engine. |
| WLAN | Wireless Local Area Network | Standard to transmit digital data via radio frequency. |
| XM | XM (Satellite Radio) | XM Satellite Radio Holdings (XM) is one of two satellite radio services in the United States and Canada. XM provides pay-for-service radio, analogous to cable television. Its service includes 73 different music channels, 39 news, sports, talk, and entertainment channels, 21 regional traffic and weather channels and 23 play-by-play sports channels (2008). |
| XML | Extensible Markup Language | A markup language that defines a set of rules for encoding documents in a format that is both human-readable and machine-readable. |
Acronyms
| Unit | Meaning | Definition |
|---|---|---|
| M 2 | Square Meter | Area |
| A | Ampere | Electrical |
| Ah | Ampere Hour | Electrical |
| C | Coulomb | Electrical |
| DBm | Decibel Meter | Electrical |
| DBmV | Decibel Millivolt | Electrical |
| MV/DIV | Millivolts per Division | Electrical |
| MV/s | Millivolts per Second | Electrical |
| Ohms | Ohm | Electrical |
| V | Volt | Electrical |
| V/DIV | Volts per Division | Electrical |
| V/ms | Volts per Millisecond | Electrical |
| W | Watt | Electrical |
| Mm 3 /stroke | Cubic Millimeters per Stroke | Flow |
| Gal/h | Gallons per Hour | Flow |
| G/s | Grams per second | Flow |
| G/stroke | Grams per Stroke | Flow |
| Kg/100km | Kilograms per 100 Kilometer | Flow |
| Kg/h | Kilograms per Hour | Flow |
| Km/L | Kilometer/liter | Flow |
| L/100km | Liters per 100 Kilometers | Flow |
| L/h | Liters per Hour | Flow |
| L/min | Liters per Minute | Flow |
| MPG | Miles per Gallon | Flow |
| Mg/s | Milligrams per Second | Flow |
| Mg/stroke | Milligrams per stroke | Flow |
| Ft | Feet | Length |
| In | Inch | Length |
| M | Meter | Length |
| Mi | Mile | Length |
| Bar | Bar | Mechanical |
| Bar/min | Bars per Minute | Mechanical |
| In. H2O | Inches of Water | Mechanical |
| In. H2O/s | Inches of Water per second | Mechanical |
| KPa/s | Kilopascals per Second | Mechanical |
| N | Newton | Mechanical |
| Newton Meter | Mechanical | |
| Pa | Pascal | Mechanical |
| Pa/s | Pascals per Second | Mechanical |
| Lb ft | Pound Foot | Mechanical |
| PSI | Pound-Force per Square Inch | Mechanical |
| Counts | Counts | Misc. |
| Cycles | Cycles | Misc. |
| DB | Decibel | Misc. |
| ° | Degree | Misc. |
| °C | Degree Centigrade | Misc. |
| °CA | Degree Crankshaft Angle | Misc. |
| °F | Degree Fahrenheit | Misc. |
| °/s | Degree per Second | Misc. |
| Hz | Hertz | Misc. |
| Kbit/s | Kilobit per second | Misc. |
| Lx | Lux | Misc. |
| Ppm | Parts per Million | Misc. |
| % | Percent | Misc. |
| %/min | Percents per Minute | Misc. |
| %/sec | Percents per Second | Misc. |
| Pulses | Pulses | Misc. |
| 1 | Ratio | Misc. |
| RPM | Revolutions per Minute | Misc. |
| Steps | Steps | Misc. |
| W/m 2 | Watts per Square Meter | Misc. |
| G | G (Acceleration) | Movement |
| Km/h | Kilometers per Hour | Movement |
| M/s | Meters per Second | Movement |
| M/s 3 | Meters per Second Cubed | Movement |
| M/s 2 | Meters per Second Squared | Movement |
| MPH | Miles per Hour | Movement |
| Mm/s | Millimeters per Second | Movement |
| D | Day | Time |
| H | Hour | Time |
| Hh:mm:ss | Hour:Minute:Second | Time |
| Ms/DIV | Milliseconds per Division | Time |
| Min | Minute | Time |
| S | Second | Time |
| S/DIV | Seconds per Division | Time |
| Yy-mm-dd | Year-Month-Day (2 digits) | Time |
| Yyyy-mm-dd | Year-Month-Day (4 digits, preferred) | Time |
| M 3 | Cubic Meter | Volume |
| Gal | Gallon | Volume |
| L | Liter | Volume |
| ML | Milliliters | Volume |
| US gal | US Gallon | Volume |
| US pt | US Pint | Volume |
| US qt | US Quart | Volume |
| Kg | Kilogram | Weight |
Units
Customer Concern Verification Sheets
The GM Customer Concern Verification Sheets have been designed to improve communications between the service customer and the technician. The more clearly the technician understands the concern and its symptoms, the more likely the concern will be fixed right the first time.
Scheme 3
The vehicle identification number (VIN) plate (1) is the legal identifier of the vehicle. The VIN plate is located on the upper left corner of the instrument panel (I/P) and can be seen through the windshield from the outside of the vehicle.
Scheme 4
Stamping in the rear floor panel (1) under the center of rear seat.
| Position | Definition | Character | Description |
|---|---|---|---|
| 1 | Country of Origin | K | Korea |
| 2 | Manufacturer | L | General Motors Daewoo Auto and Technology Company |
| 3 | Trade Name | A 1 2 3 4 5 | Daewoo Chevrolet Pontiac Holden Buick Suzuki |
| 4 | Car Line | M | M300 |
| 5 | Transmission | F A | FWD, MT FWD, AT |
| 6-7 | Body Style | 48 | 4-Door Hatchback, 4 Windows |
| 8 | Engine Type | 1 V H Z X 9 | 1.0L DOHC 1.19L DOHC 1.0L DOHC Diesel 1.0L DOHC LPG 1.0L DOHC Diesel (India) 1.2L DOHC |
| 9 | VIN Check Digit | Varies | Calculated Check Digit |
| 10 | Model Year | A B C D E F G | 2010 2011 2012 2013 2014 2015 2016 |
| 11 | Plant Location | K | Kunsan, South Korea |
| 12-17 | Production Sequence Number | Production Sequence Number |
Vehicle Identification Number (VIN) System Type
Scheme 5
The engine number is stamped on the block under the number 4 exhaust manifold.
Scheme 6
Scheme 7
The vehicle identification number (VIN) plate is attached to the top of the front panel support.
Scheme 8
| Callout | Component Name |
|---|---|
| 1 | Manufacturer Name |
| 2 | Whole Vehicle Type Approval Number |
| 3 | VIN (Vehicle Identification Number) |
| 4 | GVW |
| 5 | Combination Weight (GVW + Braked Trailer Weight) |
| 6 | Maximum Permissible Axle Weight - Front |
| 7 | Maximum Permissible Axle Weight - Rear |
| 8 | Body Color |
Scheme 9
The tire placard label is located on the driver door and displays the following assessments
- Tire size
- Tire pressure Front Rear Various loading conditions
RPO Code List
The following table provides the description of the Regular Production Option (RPO) codes that are available on the vehicle. The vehicle's RPO list is printed on the Service Parts Identification Label.
| RPO | Description |
|---|---|
| 01C | Trim Color Seat - Light Titanium |
| 01O | Trim Color Seat - V DK Pewter |
| 01R | Trim Color Seat - Moroccan Blue |
| 02Q | Trim Color Seat - Rose |
| 1AQ | Trim Color Door Panel - V DK Pewter |
| 2BH | Molding Door Interior - Jade Black |
| 2BI | Molding Door Interior - Super Red |
| 2BJ | Molding Door Interior - Moroccan Blue |
| 2BK | Molding Door Interior - V DK Pewter |
| 2BV | Molding Door Interior - Switchblade Silver Metallic |
| 2GB | Radio - AM/FM Stereo, Seek, CD, ETR, Fader, MP3, USB |
| 30F | Steering Wheel Color - Jet Black |
| 37F | Steering Wheel Color - Polar Silver |
| 4AQ | Interior Trim - V DK Pewter |
| 5MB | Panel - Trim, Right Rear Compartment, Side |
| 5MC | Panel - Trim, Load Compartment, Side |
| A32 | Window - Power Operated, Front Door |
| A50 | Seat - Front Bucket |
| A60 | Lock Control Right Rear Compartment - Lid, Tailgate, Key Activated |
| A91 | Lock Control Right Rear Compartment - Tailgate, Remote Controlled Electronic Open/Close |
| AAR | Restraint - Knee, Bolster, Foam Type |
| AE3 | Window - Power Operated, Front and Rear Door |
| AFA | Interior Trim Config - 1 |
| AFB | Interior Trim Config - 2 |
| AFC | Interior Trim Config - 3 |
| AFD | Interior Trim Config - 4 |
| AFE | Interior Trim Config - 5 |
| AFF | Interior Trim Config - 6 |
| AFG | Interior Trim Config - 7 |
| AFH | Interior Trim Config - 8 |
| AFI | Interior Trim Config - 9 |
| AFJ | Interior Trim Config - 10 |
| AH9 | Adjuster Front Seat - Manual, 2 Way, Driver |
| AIA | Restraint - Seat, Passenger, RETR, 3 Point |
| AIB | Restraint - Seat, Passenger, RETR, 3 Point, Load Limit |
| AID | Restraint - Seat, Passenger, RETR, 3 Point, Deluxe |
| AIF | Restraint - Seat, Driver, RETR, 3 Point, Load Limit |
| AIG | Restraint - Seat, Driver, RETR, 3 Point |
| AJ3 | Restraint System - Seat, Inflatable, Driver, Front |
| AJ7 | Restraint System - Seat, Inflatable, Driver and Passenger, Front and Seat Side |
| AK5 | Restraint System - Seat, Inflatable, Driver and Passenger Front |
| AM4 | Seat Rear - Split Back, Folding, Custom |
| AM7 | Seat Rear - Folding |
| AM9 | Seat Rear - Split Back, Folding |
| AMA | Seat Rear - Split Back, Folding, Headrest |
| AME | Lock Control - Side Door, Emergency Unlock, Automatic |
| APW | Window - Power, Not Desired |
| AQ2 | Net - Convenience, Package |
| AQ4 | Seat Right Rear |
| AR1 | Restraint System - (- Delete) |
| AT3 | Restraint Provisions - Child, Rear Seat, Anchorage, Reinforced |
| AT7 | Restraint System Rear - Seat, SHLDR, RETR, 3 Point, 3 SHLDR |
| ATZ | Seat Rear - Not Installed |
| AU3 | Lock Control - Side Door, Electronic |
| AU4 | Lock Control - Side Door, Electronic, Automatic |
| AV5 | Seat - Front Bucket, High Back |
| AWB | Restraint System Rear - Seat, LH and RH/ELR and CTR/2 Point |
| AWS | Restraint - Seat Belt Tensioner, Passenger |
| AWT | Restraint - Seat Belt Tensioner, Driver |
| AY0 | Restraint System - Seat, Inflatable, Driver and Passenger Front, Seat Side, Roof Side |
| AYF | Restraint System - Seat, Inflatable, Driver and Passenger Front, Front Seat Side & RR Seat side, Roof Side, Knee |
| B30 | Covering Floor - Carpet |
| B37 | Covering - Floor Mat, Front and Rear, Auxiliary |
| B56 | Molding Rocker - Body Color |
| B7S | Tray - Interior, Rear, Parcel, Pull String |
| BA8 | Compartment - Stowage, Front Seat, Passenger |
| DLU | Mirror I/S Front Van - Sunshade, Driver, without Mirror, Passenger, with Mirror and Cover |
| DLV | Mirror I/S Front Van - Sunshade, Driver and Passenger, with Mirror and Cover |
| DLW | Mirror O/S - LH and RH, Remote Control, Electric, Manual Folding, Heated |
| DP5 | Mirror Provisions - Housing, Molded with Color |
| DQ9 | Mirror Provisions - Color |
| DQB | Mirror I/S R/V - without Tilt |
| DT4 | Ashtray - Cigarette Lighter |
| DVD | Cluster Color - INST, Polar Silver |
| DVE | Cluster Color - INST, Jet Black |
| E17 | Bumper - 2.5 mph |
| E22 | Handle - Assist, Rear |
| E27 | Handle - Assist, Passenger |
| E2U | Ornamentation - Lettering, "LS" |
| E7Y | Fire Extinguisher - 2 kg |
| E91 | Pocket - Front Seat Back, Passenger |
| EBN | Trim Seat - Cloth, Bonn |
| EBO | Trim Seat - Cloth, Curve |
| EBP | Trim Seat - PU Leather, Purisme-Embo |
| ELH | Pocket - Front Seat, Passenger, Side |
| ERI | Equipment - Battery Saver |
| F81 | Ratio - Transaxle Final Drive 4.71 |
| FCP | Trim Door - Polypropylene |
| FE4 | Suspension System - Special Ride and Handling |
| FV5 | Ratio - Transaxle Final Drive 4.19 |
| FX2 | Ratio - Transaxle Final Drive 3.91 |
| FX3 | Ride And Handling - Automatic Electronic Controlled |
| GAN | Primary Color - Exterior, Switchblade Silver Met (G) 636R |
| GAR | Primary Color - Exterior, Carbon Flash Met (G) 501Q |
| GAZ | Primary Color - Exterior, Olympic White (G) 8624 |
| GBA | Primary Color - Exterior, Black (G) 8555 |
| GCT | Primary Color - Exterior, Moroccan Blue Met (G) |
| GCW | Primary Color - Exterior, Misty Lake Met (G) |
| GEL | Primary Color - Exterior, Dynamic Orange Met 728R |
| GGE | Primary Color - Exterior, Super Red (G) 717R |
| GJS | Primary Color - Exterior, Ice Teal Met (729R) |
| GJT | Primary Color - Exterior, Green Cocktail Met (726R) |
| GJU | Primary Color - Exterior, Coconut Champagne Met (727R) |
| GKE | Primary Color - Linen Beige Met |
| GME | Ornamentation - Exterior, "GM" Mark of Excellence |
| GYJ | Parts Package - Van |
| HDN | Ornamentation - Emblem, "Holden" |
| J41 | Brake System - Power, Front Disc, Rear Drum, Cast Iron |
| JM0 | Booster - Brake, Single |
| JM4 | Brake System - Power, Front Disc, Rear Drum, Cast Iron, Antilock, Front and Right Rear Wheel |
| JM7 | Booster - Brake, Hydraulic, HI Performance |
| K06 | Fan - Electric Cooling |
| K12 | Filter - Air, Pollutant |
| K97 | Generator - 80 Amp |
| KL7 | Conversion - Propane Gas (LP Gas) |
| KRB | Fuel Rating - Octane No. 83 |
| KRC | Fuel Rating - Octane No. 87 |
| KRD | Fuel Rating - Octane No. 91 |
| KRE | Fuel Rating - Octane No. 95 |
| LC5 | Engine - Gas, 4 CYL, 1.19 L, MFI, L4, DOHC |
| LCP | Engine - Propane Gas, 4 CYL, 1.0 L, MFI, DOHC |
| LHD | Vehicle Drive - Left Hand Drive |
| LMT | Engine - Gas, 4 CYL, L4, 1.0 L, MFI, DOHC, Iron, GMDAT |
| LMU | Engine - Gas, 4 CYL, L4, 1.2 L, MFI, DOHC, GMDAT |
| LEB | Engine - Diesel, 3 CYL, 1.0 L, CRI, DOHC, FGT, 39KW, INDIA |
| LL0 | Engine - Gas, 4 CYL, L4, 1.2 L, MFI, DOHC, FAM A/B, DCVCP, GEN2 |
| MFL | Transmission - Automatic 4 Speed, Jatco, JF405E |
| MNG | Transmission - Automatic 4 Speed, Aisin, 80-40LE |
| MFM | Transmission - Manual 5 Speed, Y4M HD, 1ST 3.539, 5th 0.781 |
| MX2 | Transmission - Manual 5 Speed, Y4M HD, 1ST 3.539, 5th 0.756 |
| N33 | Steering Column - Tilt Type |
| N40 | Steering - Power, Non-Variable Ratio |
| N45 | Steering Wheel - 3 Spokes |
| N51 | Steering - Manual |
| NE9 | Emission System - EEC 09 |
| NQ5 | Cap - Transmission Controlled Lever, Cap Console, Polar Silver |
| NQB | Control - Steering Wheel, Leather Wrapped (GMDAT) |
| NQT | Emission System - Open Loop, Leaded (GMDAT) |
| NQU | Emission System - Korean, ULEV |
| NT3 | Emission System - EEC 00 |
| NT4 | Emission System - EEC 05 |
| NWU | Tailpipe - Downward Deflecting |
| Q8E | Jack - Mechanical, with Tools |
| QI0 | Model Conversion - Interior, Trim Level 0 |
| QI1 | Model Conversion - Interior, Trim Level 1 |
| QI2 | Model Conversion - Interior, Trim Level 2 |
| RHD | Vehicle Drive - Right Hand Drive |
| SMR | Ornamentation - Lettering "Groove" |
| SMS | Ornamentation - Lettering "Jazz" |
| SMT | Ornamentation - Lettering "Pop" |
| T2Y | Provisions - Seat, Child |
| T3U | Lamp - Front Fog |
| T3X | Lamp System - Daytime Running, Regular Intensity Low Beam |
| T3Y | Lamp - Front Fog, Projection Type |
| T44 | Alarm - Overspeed Warning, Acoustical |
| T56 | Spoiler - Rear, Roof, Sport |
| T79 | Lamp - Fog, Rear |
| T89 | Lamp - Tail and Stop, Export |
| T90 | Lamp - Signaling and Marker, Export |
| T94 | Headlamps Control - LH Rule of the Road |
| TB1 | Lamp - Tail and Stop, Korea |
| TB8 | Headlamps Control - RH Rule of the Road |
| TBI | Plant Code - Talegaon, India |
| TD1 | Reflector - Safety Triangle |
| TDY | Ornamentation - Lettering, "Chevrolet" |
| TFC | Alarm - Seat Belt Warning, Passenger |
| TH5 | Height Adjustment - Safety Belt, Front Seat |
| TL6 | Grille - Radiator, Black |
| TN9 | Battery - LN1, FLA, 12V, 50AH, 375 ENCCA |
| TR6 | Headlamps Control - Leveling System, Manual |
| TS6 | Lamp - Stop, High Level |
| TTQ | Spoiler - Rear, Roof, Sport, Enlarged |
| TUQ | Lighter - Cigarette, without Illumination |
| TYS | Sales Package - Korea Electric Power |
| U04 | Horn - Single Note |
| U05 | Horn - Dual |
| U18 | Speedometer - Instrument, Kilometer |
| U25 | Lamp - Interior, Rear Compartment, Courtesy |
| U71 | Antenna - Roof, Radio |
| U74 | Antenna - Radio - Delete |
| U92 | Antenna - Roof, Radio, GPS, Phone |
| UAD | Speaker System - 2, Front, Base |
| UAL | Audio Control - Data System, Mode |
| UC1 | Speedometer - Instrument, Miles |
| UCH | Radio - AM/FM Stereo, Seek, CD, ETR, Fader, MP3 |
| UD7 | Sensor Indicator - Rear Parking Assist |
| UDB | Display Instrument - Driver Info Enhanced (Segmented) |
| UDG | Display Instrument - Trip Odometer (Segmented) |
| UDZ | Display - Trip Computer |
| UH0 | Indicator - Seat Belt Warning, LH |
| UH1 | Indicator - Seat Belt Warning, RH |
| UH5 | Indicator - Seat Belt Warning, Rear Seat |
| UK3 | Control - Steering Wheel, Accessory |
| UK5 | Radio - AM/FM Stereo, Seek/Scan, Automatic Reverse Cassette, ETR |
| UM7 | Radio - AM/FM Stereo, Seek/Scan, Clock, ETR |
| UQ4 | Speaker System - 4, Base |
| UQ9 | Speaker System - (- Delete) |
| UTJ | Theft Deterrent - Electrical, Unauthorized Entry |
| UV8 | Telephone - Provisions for Mobile |
| UW6 | Speaker System - 6, Custom |
| UY0 | Battery - LN0, FLA, 12V, 40AH, 300 ENCCA |
| UZM | Radio - AM/FM Stereo, CD-ROM, MP3/WMA, Navigator, RDS, SD Slot, USB, Wireless Interface |
| V22 | Grille - Radiator, Chrome |
| V48 | Coolant - Engine Maximum Protection |
| V54 | Luggage Carrier - Roof, Painted |
| V87 | Vehicle Statement - Gulf States Organization |
| VA8 | Language Label - Spanish |
| VD8 | Provisions - First Aid Kit |
| VEE | Bumper Front - Body Color, Front and Rear |
| VH4 | Mud Flaps |
| VHU | Bumper Front - Sport |
| VHY | Protector - Body Sheet Metal, High Corrosion Preventive |
| VIX | Plate - Vehicle Identification - Visual (GMDAT) |
| VIY | Plate - Vehicle Identification - Asterisk (*) Mark (GMDAT) |
| VJY | Protector - Body Sheet Metal, Low Corrosion Preventive |
| VK8 | Holder - Eyeglasses |
| VL4 | License Plate Front - Front Mounting Package, EEC |
| VMA | License Plate Front - Front Mounting Package, Korea |
| VNU | VIN Format - U.S. Type |
| VNV | VIN Format - Korea Type |
| VNW | VIN Format - EU (ISO) Type |
| VXP | Panel Center - Instrument, V DK Pewter, Acrylic Paint |
| VXQ | Panel Center - Instrument, Dark Argent, Metallic Paint |
| VXR | Panel Center - Instrument, Cyclone, Aqua Graphic Film |
| W2V | Ornamentation - Lettering, VAR - Delete |
| WAM | Ornamentation - Name Plate "Matiz" |
| WAS | Ornamentation - Name Plate "Spark" |
| WCM | Ornamentation - Lettering "LT" |
| WF7 | Ornamentation - Name Plate "Barina Spark" |
| WG3 | Ornamentation - Name Plate "Spark 300" |
| WU5 | Switch - I/P LP Dimmer |
| XA6 | Label - EEC Compliance |
| XL4 | Chassis - Protection Kit, Engine Compartment |
| XX7 | Radio - Provisions, Installation, VAR 3 |
| Y9Y | Ornamentation - Decal "Chevrolet" |
| ZY0 | Warranty - 50, 000 km, 2 N.mears |
| ZY9 | Warranty - 100, 000 km, 3 N.mears |
Metric Fasteners
This vehicle provides fastener dimensions using the metric system. Most metric fasteners are approximate in diameter to equivalent English fasteners. Make replacements using fasteners of the same nominal diameter, thread pitch, and strength.
A number marking identifies the OE metric fasteners except cross-recess head screws. The number also indicates the strength of the fastener material. A Posidrive® or Type 1A cross-recess identifies a metric cross-recess screw. For best results, use a Type 1A cross-recess screwdriver, or equivalent, in Posidrive® recess head screws.
GM Engineering Standards and North American Industries have adopted a portion of the ISO-defined standard metric fastener sizes. The purpose was to reduce the number of fastener sizes used while retaining the best thread qualities in each thread size. For example, the metric M6.0 X 1 screw, with nearly the same diameter and 25.4 threads per inch replaced the English 1/4-20 and 1/4-28 screws. The thread pitch is midway between the English coarse and fine thread pitches.
Scheme 10
| Callout | Component Name |
|---|---|
| 1 | English Bolt, Grade 2 (Strength Class) |
| 2 | English Bolt, Grade 5 (Strength Class) |
| 3 | English Bolt, Grade 7 (Strength Class) |
| 4 | English Bolt, Grade 8 (Strength Class) |
| 5 | Metric Nut, Strength Class 9 |
| 6 | Metric Bolts, Strength Class Increases as Numbers Increase |
The most commonly used metric fastener strength property classes are 9.8 and 10.9. The class identification is embossed on the head of each bolt. The English, inch strength classes range from grade 2 to grade 8. Radial lines are embossed on the head of each bolt in order to identify the strength class. The number of lines on the head of the bolt is 2 lines less than the actual grade. For example, a grade 8 bolt will have 6 radial lines on the bolt head. Some metric nuts are marked with a single digit strength identification number on the nut face.
The correct fasteners are available through GM SPO. Many metric fasteners available in the aftermarket parts channels are designed to metric standards of countries other than the United States, and may exhibit the following
- Lower strength
- No numbered head marking system
- Wrong thread pitch
The metric fasteners on GM products are designed to new, international standards. The following are the common sizes and pitches, except for special applications
- M6.0 X 1
- M8 X 1.25
- M10 X 1.5
- M12 X 1.75
- M14 X 2.00
- M16 X 2.00
Thread Inserts
General Purpose Thread Repair Kits.
These kits are available commercially.
Repair Procedure
- Determine the size, the pitch, and the depth of the damaged thread. If necessary, adjust the stop collars on the cutting tool and tap to the required depth.
- Drill out the damaged threads. Clean out any chips.
- Lubricate the tap with light engine oil. Tap the hole. Clean the threads.
- Thread the thread insert onto the mandrel of the installer. Engage the tang of the insert onto the end of the mandrel.
- Lubricate the insert with light engine oil, except when installing in aluminum and install the insert.
- If the tang of the insert does not break off when backing out the installer, break the tang off with a drift.
Ignition Lock Cylinder
- Tumbler spring (2) and tumbler (3) to be assembled into cylinder (1)-In this case start with the tumbler near the cylinder head and work through until the last tumbler at the cylinder ground. Use the key as tool by pushing it in step by step to hold the already assembled tumblers in place.
- Slide piece (4) to be assembled into the pocket in cylinder (1).
- Apply grease on the cylinder diameter.
- Assemble the rotor case (5) and sub-assembly.
- Remove the key.
- Install the C-ring (6) to the bottom of the cylinder.
Front Side Door Lock Cylinder
- Tumbler spring (2) and tumbler (3) to be assembled into cylinder (1)-In this case start with the tumbler near the cylinder head and work through until the last tumbler at the cylinder ground. Use the key as tool by pushing it in step by step to hold the already assembled tumblers in place.
- Apply grease on the cylinder diameter.
- Assemble the rotor case (5) and sub-assembly.
- Remove the key.
- Install the return spring (5) and lever (6).
- Install the E-ring (6) to the bottom of the cylinder.
- Install and stake the rotor case cover (8) onto the head of the rotor case (5) by crimping the cover material in 2 places into the pockets around the head of the rotor case.
Liftgate Lock Cylinder
- Tumbler spring (2) and tumbler (3) to be assembled into cylinder (1)-In this case start with the tumbler near the cylinder head and work through until the last tumbler at the cylinder ground. Use the key as tool by pushing it in step by step to hold the already assembled tumblers in place.
- Apply grease on the cylinder diameter.
- Assemble the rotor case (5) and sub-assembly.
- Remove the key.
- Install the return spring (5) and lever (6).
- Install the E-ring (6) to the bottom of the cylinder.
- Install and stake the rotor case cover (8) onto the head of the rotor case (5) by crimping the cover material in 2 places into the pockets around the head of the rotor case.
Lifting and Jacking the Vehicle
Note. The use of a LOW PROFILE LIFT ARMS SYSTEM may be required to avoid unwanted contact with the vehicle body and structure depending on lifting equipment used. Refer to the manufacturer recommendation for their applications of low profile lift arms system for their lifting equipment.
Scheme 11
| WARNING | To avoid any vehicle damage, serious personal injury or death when major components are removed from the vehicle and the vehicle is supported by a hoist, support the vehicle with jack stands at the opposite end from which the components are being removed and strap the vehicle to the hoist. |
| WARNING | To avoid any vehicle damage, serious personal injury or death, always use the jackstands to support the vehicle when lifting the vehicle with a jack. |
| CAUTION | Perform the following steps before beginning any vehicle lifting or jacking procedure: Remove or secure all of the vehicle contents in order to avoid any shifting or any movement that may occur during the vehicle lifting or jacking procedure. The lifting equipment or the jacking equipment weight rating must meet or exceed the weight of the vehicle and any vehicle contents. The lifting equipment or the jacking equipment must meet the operational standards of the lifting equipment or jacking equipment manufacturer. Perform the vehicle lifting or jacking procedure on a clean, hard, dry, level surface. Perform the vehicle lifting or jacking procedure only at the identified lift points. DO NOT allow the lifting equipment or jacking equipment to contact any other vehicle components. Failure to perform the previous steps could result in damage to the lifting equipment or the jacking equipment, the vehicle, and/or the vehicle contents. |
Vehicle Lifting- Frame Contact Lift
Front Lift Pads
When lifting the vehicle with a frame-contact lift, place the front lift pads on the rocker outer panel weld flange, as shown.
Rear Lift Pads
When lifting the vehicle with a frame-contact lift, place the rear lift pads on the rocker outer panel weld flange, as shown.
Vehicle Jacking
| CAUTION | When you are jacking the vehicle at the front locations, be certain that the jack or the jack lift pad does not contact the front fascia, front fascia air dam, or the front fenders. If such contact occurs, vehicle damage may result. When jacking at selected front locations additional clearance may be required for the jacking points. |
Note. When you are lifting a vehicle with a service jack, block the wheels at the opposite end from which you are lifting. Use jack stands to provide additional support.
When using a service jack under the front of the vehicle use one of the following locations
Front of Vehicle
Place the service jack pad in the same location as shown for the front lift pads.
Rear of Vehicle
Note. Place jackstands ONLY under strong and stable vehicle structures.
Place the service jack pad in the same location as shown for the rear lift pads.
