Frame and Underbody: Specifications Chevrolet Spark M300

Frames, Subframes & Crossmembers 1 illustration

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Frame to Body Retaining Bolt170125 lb ft
Front Compartment Splash Shield Bolt980 lb in
Front Wheelhouse Liner Screw1.513 lb in
Rear Wheelhouse Liner Screw2.522 lb in
Torque Strut to Frame Retaining Bolt10074 lb ft
Torque Strut to Transmission Mounting Bracket Retaining8059 lb ft

Fastener Tightening Specifications

Scheme 1

Scheme 1: Front Compartment Splash Shield Replacement
Scheme 1: Front Compartment Splash Shield Replacement
CalloutComponent Name
1Front Compartment Splash Shield Retainer (Qty 2)
2Front Compartment Splash Shield Bolt CAUTION: Refer to Fastener Caution . Tighten 9 N.m (80 lb in)
3Front Compartment Splash Shield
CAUTION
Refer to Fastener Caution .

Front Compartment Splash Shield Replacement
