Lighting System: Removal & Installation Chevrolet Spark M300

Exterior Lights 4 illustrations ~274 words

Removal Procedure

  1. Remove the instrument panel lower airbag bracket. Refer to .
  2. Remove the intermediate steering shaft (1). Refer to «Intermediate Steering Shaft Replacement»(ref-544463-S19269318582013042400000) .
  3. Disconnect the brake pedal position sensor electrical connector.
  4. Remove the brake pedal position sensor bracket bolts (1).
  5. Remove the brake pedal position sensor and bracket assembly.
  6. Remove the brake pedal position sensor bolt (1).
  7. Remove the brake pedal position sensor (2) from the bracket.

Installation Procedure

  1. Install the brake pedal position sensor bolt (1) through the bracket and to the brake pedal position sensor (2)..
  2. Tighten the brake pedal position sensor bolt to 3 (27 lb in)
  3. Install the brake pedal position sensor and bracket assembly to the brake and accelerator pedal assembly.
  4. Install the brake pedal position sensor bracket bolts (1) and tighten to 3 (27 lb in).
  5. Connect the brake pedal position sensor electrical connector.
  6. Install the intermediate steering shaft (1). Refer to «Intermediate Steering Shaft Replacement»(ref-544463-S19269318582013042400000) .
  7. Install the instrument panel lower airbag bracket. Refer to .
  8. Calibrate the brake pedal position sensor. Refer to «Brake Pedal Position Sensor Calibration»(ref-544462-S06735997502013042400000) .

Scheme 12

Scheme 12: Hazard Warning Switch Replacement
Scheme 12: Hazard Warning Switch Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel center molding. Refer to Instrument Panel Center Molding Replacement
1Hazard Warning Switch Procedure Disconnect the electrical connector. Squeeze tabs on switch to unsnap from housing bracket.

Hazard Warning Switch Replacement

Scheme 13

Scheme 13: Center Courtesy Lamp Replacement
Scheme 13: Center Courtesy Lamp Replacement
CalloutComponent Name
Preliminary Procedure Remove the center courtesy lamp lens. Refer to .
1Center Courtesy Lamp Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution .
2Center Courtesy Lamp Procedure Disconnect the electrical connections.
CAUTION
Refer to Fastener Caution .

Center Courtesy Lamp Replacement

Scheme 14

Scheme 14: Headlamp Replacement
Scheme 14: Headlamp Replacement
CalloutComponent Name
Preliminary Procedure Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement .
1Headlamp Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2Headlamp Assembly Procedure Pull the headlamp assembly forward far enough to access the electrical connection. Disconnect the headlamp electrical connector from the forward lamp harness connector. Remove the headlamp assembly. Aim the headlamps after installation. Refer to Headlamp Aiming .
CAUTION
Refer to Fastener Caution .

Headlamp Replacement

Scheme 15

Scheme 15: Headlamp Bulb Replacement
Scheme 15: Headlamp Bulb Replacement
CalloutComponent Name
1Headlamp Bulb WARNING: Refer to . Procedure Disconnect electrical connector. Rotate the headlamp bulb counterclockwise to remove from the headlamp.
WARNING
Refer to .

Headlamp Bulb Replacement

  1. Remove the headlamp. Refer to «Headlamp Replacement»(ref-544462-S23698973852013042400000) .
  2. There are 2 replacement brackets (1) on each headlamp.
  3. For bracket, 1 remove the screws (1) and bracket 1 (2).
  4. For bracket 2, cut the bracket along the marked line (1).
  1. For bracket 1, install the bracket (1) with the specified attachments.
  2. For bracket 2, install the bracket (2) with the specified attachments.
  3. Install the headlamp. Refer to «Headlamp Replacement»(ref-544462-S23698973852013042400000) .
