Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Air Conditioning Compressor and Condenser Under Pipe Nut | 11 | 96 lb in |
| Air Conditioning Compressor and Condenser Upper Pipe Nut | 11 | 96 lb in |
| Block Heater Connecting Plug Holder Bolt | 8 | 71 lb in |
| Engine Coolant Fan Bolt | 3 | 27 lb in |
| Engine Coolant Thermostat Bolt | 10 | 89 lb in |
| Engine Coolant Thermostat Housing Bolt | 25 | 18 lb ft |
| Intake Manifold Bracket Bolt - Lower | 58 | 42 lb ft |
| Intake Manifold Bracket Bolt - Upper | 22 | 16 lb ft |
| Radiator Drain Cock | 2 | 18 lb in |
| Radiator Overflow Hose Bracket Nut | 9 | 80 lb in |
| Radiator Support Bracket Bolt | 22 | 16 lb ft |
| Radiator Support Mounting Bolt | 22 | 16 lb ft |
| Radiator Surge Tank Mounting Bolt | 8 | 71 lb ft |
| Water Pump Bolt | 25 | 18 lb ft |
