Brake Pedal Position Sensor Replacement
Note. Brake system does not use a brake switch, stoplight switch or brakelight switch. System uses a Brake Pedal Position Sensor to control these functions.
Removal Procedure
- Remove the instrument panel lower trim pad cover. Refer to «Instrument Panel Lower Trim Pad Cover Replacement (Without AAL)»(ref-542486-S24333336292013041600000) , «Instrument Panel Lower Trim Pad Cover Replacement (With AAL)»(ref-542486-S32313228862013041600000) .
- Disconnect the brake pedal position sensor electrical connector.
- Remove the brake pedal position sensor bolt (1).
- Remove the brake pedal position sensor.
Installation Procedure
- Install the brake pedal position sensor to the brake pedal bracket.
- Install the brake pedal position sensor bolt (1) and tighten to 3 N.m (27 lb in).
- Connect the brake pedal position sensor electrical connector.
- Calibrate the brake pedal position sensor. Refer to «Brake Pedal Position Sensor Calibration»(ref-542483-S01924819902013041600000) .
- Install the instrument panel lower trim pad cover. Refer to «Instrument Panel Lower Trim Pad Cover Replacement (Without AAL)»(ref-542486-S24333336292013041600000) , «Instrument Panel Lower Trim Pad Cover Replacement (With AAL)»(ref-542486-S32313228862013041600000) .
Scheme 12
Scheme 12: Headlamp Switch Replacement
| Callout | Component Name |
| Preliminary Procedure Remove the instrument panel lower trim pad cover. Refer to Instrument Panel Lower Trim Pad Cover Replacement (Without AAL) , Instrument Panel Lower Trim Pad Cover Replacement (With AAL) |
| 1 | Headlamp Switch Procedure Gently depress tabs to remove the switch assembly from the instrument panel lower cover. Disconnect the electrical connector. |
Headlamp Switch Replacement
Scheme 13
Scheme 13: Hazard Warning Switch Replacement
| Callout | Component Name |
| Preliminary Procedure Remove the heater and air conditioning control. Refer to Heater and Air Conditioning Control Replacement . |
| 1 | Hazard Warning Switch Bolts (Qty: 2) CAUTION: Refer to Fastener Caution . |
| 2 | Hazard Warning Switch Procedure Disconnect the electrical connector. |
| CAUTION |
| Refer to Fastener Caution . |
Hazard Warning Switch Replacement
Scheme 14
Scheme 14: Reading Lamp Replacement
| Callout | Component Name |
| Preliminary Procedure Remove the dome lamp bezel. Refer to Dome Lamp Bezel Replacement . |
| 1 | Reading lamp Procedures Release the clips retaining the reading lamp assembly to the bezel. Disconnect the electrical connections. |
Scheme 15
Scheme 15: Dome Lamp Bezel Replacement
| Callout | Component Name |
| 1 | Dome Lamp Bezel Cover Procedures Grasp the bezel cover and pull downward to remove from the lamp assembly. Disconnect the electrical connections, as necessary. |
| 2 | Dome Lamp Bezel Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution . |
| 3 | Dome Lamp Bezel Procedures Pull assembly downward to remove. Disconnect the electrical connections. |
| CAUTION |
| Refer to Fastener Caution . |
Dome Lamp Bezel Replacement
Scheme 16
Scheme 16: Windshield Header Courtesy Lamp Replacement
| Callout | Component Name |
| 1 | Windshield Header Courtesy Lamp Procedures Grasp the courtesy lamp assembly and pull downward to release the retainer clips securing the courtesy lamp assembly to the headliner. Disconnect the electrical connections. |
Windshield Header Courtesy Lamp Replacement
Scheme 17
Scheme 17: Dome Lamp Bulb Replacement
| Callout | Component Name |
| Preliminary Procedure Remove the windshield header courtesy lamp. Refer to Windshield Header Courtesy Lamp Replacement |
| 1 | Dome Lamp Bulb |
Dome Lamp Bulb Replacement
Scheme 18
Scheme 18: Headlamp Replacement
| Callout | Component Name |
| Preliminary Procedure Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement . |
| 1 | Headlamp Assembly Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in) |
| 2 | Headlamp Assembly Procedure Disconnect the electrical connector bulb harness and remove the headlamp assembly. Aim the headlamps after replacement. Refer to Headlamp Aiming . |
| CAUTION |
| Refer to Fastener Caution . |
Scheme 19
Scheme 19: Headlamp Bulb Replacement
| Callout | Component Name |
| Preliminary Procedure Open and support the hood assembly. |
| 1 | Accessory Bulb Cover (Qty: 2) |
| 2 | WARNING: Refer to Halogen Bulb Warning . Headlamp Bulb (Low Beam) Procedure Disconnect the electrical connector from the bulb socket. Rotate the bulb socket and remove from the headlamp housing. |
| 3 | Headlamp Bulb (High Beam) Procedure Disconnect the electrical connector from the bulb socket. Rotate the bulb socket a quarter turn and remove from the headlamp housing. |
| WARNING |
| Refer to Halogen Bulb Warning . |
Headlamp Bulb Replacement
Scheme 20
Scheme 20: Headlamp Housing Bracket Replacement
| Callout | Component Name |
| Preliminary Procedure Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement . |
| 1 | Headlamp Housing Bracket Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in) |
| 2 | Headlamp Housing Bracket Procedure Release the tabs on the housing bracket from the front bumper fascia and remove. |
| CAUTION |
| Refer to Fastener Caution . |
Headlamp Housing Bracket Replacement
Scheme 21
Scheme 21: Headlamp Bracket Replacement
| Callout | Component Name |
| Preliminary Procedure Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement . |
| 1 | Headlamp Bracket Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in) |
| 2 | Headlamp Bracket |
| CAUTION |
| Refer to Fastener Caution . |
Headlamp Bracket Replacement
