Keyless Entry System and Remote Functions: Other Chevrolet Sonic I

Reference Information

Schematic Reference

Remote Function Schematics

Component Connector End Views

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Keyless Entry System Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-542498-S42729642072013041600000)
2. «Connector Repairs»(ref-542498-S10348064002013041600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-542498-S27468711012013041600000)
4. «Wiring Repairs»(ref-542498-S06256207262013041600000)

Scan Tool Reference

Control Module References for scan tool information

Repair Instructions

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for body control module or remote control door lock receiver replacement, programming, and setup.

Schematic Reference

Remote Function Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Keyless Entry System Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-542498-S42729642072013041600000)
2. «Connector Repairs»(ref-542498-S10348064002013041600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-542498-S27468711012013041600000)
4. «Wiring Repairs»(ref-542498-S06256207262013041600000)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

1. Verify that the transmitter is a correct transmitter for the vehicle. This can be accomplished by comparing the part number printed on the transmitter to the appropriate part number in the parts catalog. If the transmitter is incorrect Replace the transmitter. If the transmitter is correct
2. Program the transmitter. Refer to «Key with Integrated Transmitter Programming»(ref-542495-S21645226632013041600000) .
3. Verify the transmitter has successfully completed the programming procedure. If the transmitter does not program successfully Replace the transmitter. If the transmitter programs successfully
4. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Key with Integrated Transmitter Programming

Schematic Reference

Remote Function Schematics

Component Connector End Views

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Keyless Entry System Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-542498-S42729642072013041600000)
2. «Connector Repairs»(ref-542498-S10348064002013041600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-542498-S27468711012013041600000)
4. «Wiring Repairs»(ref-542498-S06256207262013041600000)

Scan Tool Reference

Control Module References for scan tool information

1. With a valid and learned transmitter, press and release a button on the transmitter.
2. Verify that DTC B3106 is not set. If DTC B3106 is set Replace the K77 Remote Control Door Lock Receiver. If DTC B3106 is not set
3. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for remote control door lock receiver replacement, programming, and setup.

Schematic Reference

Remote Function Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Keyless Entry System Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-542498-S42729642072013041600000)
2. «Connector Repairs»(ref-542498-S10348064002013041600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-542498-S27468711012013041600000)
4. «Wiring Repairs»(ref-542498-S06256207262013041600000)

Scan Tool Reference

Control Module References for scan tool information

1. Verify none of the DTCs listed below are set: DTC B3109 DTC B3110 DTC B3111 DTC B3112 DTC B3113 If any of the DTCs are set Replace the battery in the appropriate keyless entry transmitter and operate the transmitter three consecutive times. Verify the DTC does not set. If the DTC sets, replace the keyless entry transmitter. If the DTC does not set All OK. If none of the DTCs are set
2. All OK.

Schematic Reference

Remote Function Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Keyless Entry System Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-542498-S42729642072013041600000)
2. «Connector Repairs»(ref-542498-S10348064002013041600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-542498-S27468711012013041600000)
4. «Wiring Repairs»(ref-542498-S06256207262013041600000)

Scan Tool Reference

Control Module References for scan tool information

1. Verify none of the DTCs listed below are set: DTC B310D DTC B310E DTC B310F If any of the DTCs are set Replace the battery in the appropriate keyless entry transmitter and operate the transmitter three consecutive times. Verify the DTC does not set. If the DTC sets, replace the keyless entry transmitter. If the DTC does not set All OK. If none of the DTCs are set
2. All OK.

Symptoms - Remote Functions

Note. The following steps must be completed before using the symptom tables.

1. Perform «Diagnostic System Check - Vehicle»(ref-542476-S03610919532013041600000) before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
2. Review the system operation in order to familiarize yourself with the system functions. Refer to «Keyless Entry System Description and Operation»(ref-542497-S08884202792013041600000) .

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Schematic Reference

Remote Function Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Keyless Entry System Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-542498-S42729642072013041600000)
2. «Connector Repairs»(ref-542498-S10348064002013041600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-542498-S27468711012013041600000)
4. «Wiring Repairs»(ref-542498-S06256207262013041600000)

Scan Tool Reference

Control Module References for scan tool information

Special Tools

EL 43241 Keyless Entry Tester

1. Verify that the vehicle key is correct for the vehicle. This can be accomplished by comparing the part number printed on the key to the appropriate part number in the parts catalog. If the vehicle key is incorrect Replace the vehicle key. If the vehicle key is correct
2. Operate the transmitter while observing the scan tool Key Fob Function parameter for the appropriate transmitter.
3. Verify the scan tool Key Fob Function parameter corresponds with the function selected on the transmitter. If the Key Fob Function parameter does not correspond with the transmitter selection NOTE: Before replacing the transmitter, inspect the transmitter battery contacts for any corrosion or damage. If no corrosion or damage is found, replace the transmitter battery and retest before replacing the transmitter. Replace the vehicle key. Operate the new transmitter while observing the scan tool Key Fob Function parameter for the transmitter. Verify the scan tool Key Fob Function parameter correspond with the function selected on the transmitter. If the Key Fob Function parameter does not correspond with the transmitter selection, replace the K9 Body Control Module If the Key Fob Function parameter corresponds with the transmitter selection All OK. If the Key Fob Function parameter corresponds with the transmitter selection
4. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

1. «Key with Integrated Transmitter Programming»(ref-542495-S21645226632013041600000)
2. «Control Module References»(ref-542499-S01936129122013041600000) for body control module replacement, programming, and setup

Schematic Reference

Remote Function Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Keyless Entry System Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-542498-S42729642072013041600000)
2. «Connector Repairs»(ref-542498-S10348064002013041600000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-542498-S27468711012013041600000)
4. «Wiring Repairs»(ref-542498-S06256207262013041600000)

Scan Tool Reference

Control Module References for scan tool information

1. Verify that the keyless entry functions operate with all available keyless entry transmitters. If any keyless entry functions do not operate properly Refer to «Keyless Entry System Malfunction»(ref-542497-S42215547832013041600000) . If all keyless entry functions operate properly
2. Verify that no Diagnostic Status History or Start Disable items are present in the scan tool BCM Remote Start Diagnostic Status History and the ECM Remote Vehicle Start Disable History parameters. If remote vehicle start disable history items are present Refer to the appropriate subsection in which the malfunction occurred. If remote vehicle start disable history items are not present
3. Verify all scan tool BCM Content Theft Trigger History parameters display None. If any BCM Content Theft Trigger History parameter does not display None Refer to «Content Theft Deterrent Malfunction»(ref-542515-S41489097092013041600000) . If all BCM Content Theft Trigger History parameters display None
4. All OK.

Scheme 36

Remote Control Door Lock Receiver Replacement

Keyless Entry Transmitters

Note. When the vehicle key is in the ignition, keyless entry functions from all keyless entry transmitter are disabled.

The keyless entry transmitters are used to perform various entry functions while away from the immediate are of the vehicle. Keyless entry functions may work at up to 20 m (65 ft) away from the vehicle. Ambient conditions may affect the performance of the keyless entry transmitter and reduce the range at which keyless entry functions operate. Up to eight transmitters may be programmed to a single vehicle. The keyless entry transmitter is an integral part of the vehicle key.

OnStar® Remote Link (if equipped)

A vehicle operator may have the ability to perform some of the keyless entry functions using applications on personal devices such as a smart phone. Unwanted or inadvertent door lock/unlock activation may be requested by the OnStar® Remote Link app. It is possible that a customer may be unaware of account usage, result in an unwanted or phantom door lock/unlock. If normal system diagnosis does results in an inability to verify the customer's concern, contact Technical Assistance Center (TAC).

Body Control Module (BCM)

The BCM is a multifunction module that operates the keyless entry system. When an radio frequency message is received from a keyless entry transmitter, the BCM interprets this signal and performs the specific function, i.e. door lock, door unlock, or vehicle locate.

Remote Control Door Lock Receiver

The Remote Control Door Lock Receiver acts as an antenna for the keyless entry system and communicates with the BCM through a dedicated serial data link. When a button is pressed on a keyless entry transmitter, the Remote Control Door Lock Receiver receives this signal and sends the request to the BCM. The BCM interprets the signal and performs the specific function, i.e. door lock, door unlock, or vehicle locate.

Unlock Doors

Momentarily press the transmitter UNLOCK button in order to perform the following functions

1. Unlock only the driver door or all doors and liftgate (if equipped); this is customized through the DIC.
2. Illuminate the interior lamps for a determined length of time or until the ignition is turned ON.
3. Flash the exterior lights; this is customized through the DIC.
4. Disarm the content theft deterrent system, if equipped.
5. Deactivate the content theft deterrent system when in the alarm mode.

Lock All Doors

Press the transmitter LOCK button to perform the following functions

1. Lock all vehicle doors.
2. Immediately turn OFF the interior lamps.
3. Flash the exterior lights and/or sound the horn; this is customized through the DIC.
4. Arm the content theft deterrent system.

Trunk Release, if equipped

Press the trunk release button on the transmitter to open the trunk.

Power Liftgate, if equipped

Press and hold the power liftgate button to perform the following functions

1. Open or close the liftgate using the power liftgate function.
2. Flash the tail lamps.
3. Sound the interior power liftgate chime.

Vehicle Locator/Panic Alarm

A single press of the panic button performs the following functions. Some functions may be dependent on personalization settings

1. Pulse the horn three times.
2. Flash the exterior lamps three times.

A press and hold of the panic button performs the following functions

1. Illuminate the interior lamps.
2. Pulse the horn and flash the exterior lamps for 30 seconds or until the following conditions occur: The panic button is pressed. The ignition switch is turned to the RUN position with a valid key.

Remote Vehicle Start, if equipped

The remote vehicle start function allows engine starting while not in the vehicle. It also allows the vehicle HVAC system and other vehicle systems to enable, providing a comfortable vehicle upon entry. The remote vehicle start sequence begins by pressing and releasing the lock button and then pressing and holding the remote vehicle start buttons on the keyless entry transmitter. The turn signal lamps will illuminate to indicate the vehicle has received the remote start request. Each time an remote vehicle start is performed, the vehicle doors are locked, however they may then be unlocked/locked with the transmitter or vehicle key at any time. Once activated, the engine is allowed to run for 10 minutes. The remote vehicle start time may be extended by an additional 10 minutes by again pressing and releasing the lock button and then pressing and holding the remote vehicle start buttons on the transmitter. This feature is called a remote vehicle start continue and allows a maximum of 20 minutes of engine running. If the remote vehicle start continue is performed at seven minutes into the initial 10 minute time-out, a total of 17 minutes of engine running would occur. The remote vehicle start event may be suspended at any time by pressing only the remote vehicle start button on the transmitter or by entering the vehicle and pressing the hazard lamp switch.

In between ignition cycles, only two remote vehicle start events may occur or be attempted. Once two events or attempts have been made, future remote vehicle start events will be suspended until the vehicle is started using the ignition.

Enable/Disable Remote Vehicle Start

Using the driver information center, remote vehicle start may be enabled or disabled as a part of vehicle personalization. Refer to the vehicle owners manual for more information.

Hood Ajar Switch

The hood switch provides status of the hood to the BCM for remote vehicle start purposes. The switch is integrated into the hood latch assembly.

Keyless Entry Personalization

Vehicle lock/unlock functions and remote vehicle start remote vehicle start settings may be personalized. For functional descriptions and personalization instructions, refer to the vehicle owners manual.
