Cruise Control Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(ref-542498-S42729642072013041600000)
  2. «Connector Repairs»(ref-542498-S10348064002013041600000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-542498-S27468711012013041600000)
  4. «Wiring Repairs»(ref-542498-S06256207262013041600000)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

  1. Ignition ON.
  2. Verify that no DTCs are set, except DTC P0571. If any other DTC is set, except DTC P0571 Refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(ref-542476-S32003136202013041600000) . If only DTC P0571 is set
  3. Replace the K20 Engine Control Module.
  4. Verify DTC P0571 does not set when operating the vehicle within the conditions for running the DTC. If the DTC sets Replace the K 9 Body Control Module. If the DTC does not set
  5. All OK.

Repair Instructions

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for BCM or ECM replacement, programming and setup.

Schematic Reference

Cruise Control Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Cruise Control Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(ref-542498-S42729642072013041600000)
  2. «Connector Repairs»(ref-542498-S10348064002013041600000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-542498-S27468711012013041600000)
  4. «Wiring Repairs»(ref-542498-S06256207262013041600000)

Scan Tool Reference

Control Module References for scan tool information

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for BCM or ECM programming, replacement, and setup

Schematic Reference

Cruise Control Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Cruise Control Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(ref-542498-S42729642072013041600000)
  2. «Connector Repairs»(ref-542498-S10348064002013041600000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-542498-S27468711012013041600000)
  4. «Wiring Repairs»(ref-542498-S06256207262013041600000)

DTC Type Reference

Powertrain Diagnostic Trouble Code (DTC) Type Definitions

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify that no DTCs are set, except DTC P0575. If any other DTC is set, except DTC P0575 Refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(ref-542476-S32003136202013041600000) . If only DTC P0575 is set
  3. Replace the K9 Body Control Module.
  4. Verify DTC P0575 does not set when operating the vehicle within the Conditions for Running the DTC. If the DTC sets Replace the K20 Engine Control Module. If the DTC does not set
  5. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for BCM or ECM programming, replacement, and setup.

Schematic Reference

Cruise Control Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Cruise Control Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(ref-542498-S42729642072013041600000)
  2. «Connector Repairs»(ref-542498-S10348064002013041600000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-542498-S27468711012013041600000)
  4. «Wiring Repairs»(ref-542498-S06256207262013041600000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify that no DTCs are set, except DTC P0703. If any other DTC is set, except DTC P0703 Refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(ref-542476-S32003136202013041600000) . If only DTC P0703 is set
  3. Replace the K9 Body Control Module.
  4. Verify DTC P0703 does not set when operating the vehicle within the conditions for running the DTC. If the DTC sets Replace the K20 Engine Control Module. If the DTC does not set
  5. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for BCM or ECM programming, replacement, and setup.

Symptoms - Cruise Control

Note. The following steps must be completed before using the symptom tables.

  1. Before using the symptom diagnostic table, perform the «Diagnostic System Check - Vehicle»(ref-542476-S03610919532013041600000) in order to verify the following conditions: There are no DTCs set. The module can communicate via the serial data.
  2. Review the system operation in order to understand the system functions. Refer to «Cruise Control Description and Operation»(ref-542517-S37268935272013041600000) .

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Schematic Reference

Cruise Control Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Cruise Control Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(ref-542498-S42729642072013041600000)
  2. «Connector Repairs»(ref-542498-S10348064002013041600000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-542498-S27468711012013041600000)
  4. «Wiring Repairs»(ref-542498-S06256207262013041600000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify the cruise control indicator turns ON and OFF when commanding the All Indicators ON and OFF with a scan tool. If the indicator does not turn ON and OFF Replace the P16 Instrument Cluster. If the indicator turns ON and OFF
  3. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for instrument cluster replacement, programming and setup.

Schematic Reference

Cruise Control Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Cruise Control Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(ref-542498-S42729642072013041600000)
  2. «Connector Repairs»(ref-542498-S10348064002013041600000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-542498-S27468711012013041600000)
  4. «Wiring Repairs»(ref-542498-S06256207262013041600000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify the scan tool ECM Cruise Control Switch Status parameter changes between Off and On, Resume and Set when switching between each position on the cruise control switch. If the parameter does not change Refer to «Circuit/System Testing»(ref-542517-S17299713412013041600000) . If the parameter changes
  3. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for BCM replacement, programming and setup.

Scheme 2

Scheme 2: Cruise Control Switch Replacement
CalloutComponent Name
Preliminary Procedure Remove the steering wheel inflatable restraint module. Refer to Airbag Steering Wheel Module Replacement .
1Steering Wheel Lower Cover
2Steering Wheel Lower Cover Fastener (Qty: 2)
3Cruise Control Switch Assembly Procedure Disconnect the electrical connector.

Cruise Control Switch Replacement

Cruise Control Engaged

The Cruise Control System will engage and adjust vehicle speeds, based on the activation of the following cruise control switches, which are located on the steering wheel

  1. On/Off
  2. + RES
  3. SET

To engage the Cruise Control System, ensure that the vehicle speed is above 40.2 km/h (25 mph), turn the cruise On/Off switch ON and momentarily press the - SET switch. The ECM will engage the Cruise Control System and record the vehicle speed. The ECM sends a serial data message to the instrument panel cluster (IPC) in order to illuminate the Cruise Engaged indicator in the IPC. Refer to the vehicle owner's manual for the location and operation of the cruise control On/Off indicators and driver information center (DIC) messages.

Pressing the accelerator pedal while the Cruise Control System is engaged, allows the driver to override the Cruise Control System in order to accelerate the vehicle beyond the current set vehicle speed. When the accelerator pedal is released, the vehicle will decelerate and resume the current set vehicle speed.

The driver can also override the current set vehicle speed via the - SET switch and the + RES switch. When the Cruise Control System is engaged, pressing and holding the - SET switch will allow the vehicle to decelerate from the current set vehicle speed without deactivating the Cruise Control System. When the - SET switch is released, the ECM will record the vehicle speed and maintain the vehicle speed as the new set vehicle speed. When the Cruise Control System is engaged, momentarily pressing the - SET switch will allow the vehicle to decelerate at 1.6 km/h (1 mph) increments for each time that the - SET is momentarily pressed, with a minimum vehicle speed of 38 km/h (24 mph).

Pressing and holding the + RES switch, when the Cruise Control System is engaged, will allow the vehicle to accelerate to a greater vehicle speed than the current set vehicle speed. When the + RES switch is released, the ECM will record the vehicle speed and maintain the vehicle speed as the new set vehicle speed. When the Cruise Control System is engaged, momentarily pressing the + RES switch will allow the vehicle to accelerate at 1.6 km/h (1 mph) increments for each time that the + RES switch is momentarily pressed. Momentarily activating the + RES switch will recall the previous vehicle speed, after the cruise control system has been disengaged by pressing the brake pedal, or CANCEL switch.

Cruise Control Disengaged

The engine control module (ECM) disengages the cruise control operation based on the signals from the following switches

  1. The brake pedal position (BPP) sensor
  2. The On/Off switch
  3. The cruise control cancel switch

The Cruise Control System will disengage when the brake pedal is applied. The body control module (BCM) monitors the BPP sensor via the BPP sensor signal circuit as the voltage signal increases while the pedal reaches the fully applied position. The ECM monitors the BPP signal through a discrete input and a serial data message signal from the BCM indicating the brake status. When either signal indicates the brake pedal is applied, the ECM will disengage the cruise control system.

The Cruise Control System will also disengage when the cruise control on/off switch is switched OFF, or the cruise control cancel switch is activated. The body control module (BCM) determines when the cruise control cancel switch is activated. When the normally open cancel switch is closed, the BCM detects the predetermined voltage signal on the cruise control function switch circuit. The vehicle speed stored in the memory of the engine control module will be erased when the cruise control On/Off switch is turned OFF, or the ignition switch is turned OFF. The BCM sends a serial data message to the ECM in order to disengage the cruise control system. When the Cruise Control System has been disengaged, the ECM sends a serial message to the instrument panel cluster (IPC) in order to turn OFF the Cruise Engaged indicator.

Every time the Cruise Control System is disengaged, the ECM will keep track of the reason for system disengagement. The last 8 disengagement reasons will be recorded within the ECM memory. The scan tool will display the last 8 Cruise Disengage History parameters, in which one out of approximately 50 possible reasons will be displayed in each of these 8 parameters. For the disengagement reason to be displayed within the scan tool parameter the Cruise Control System is active and disengagement is requested.

When engagement of the system is requested but an engagement inhibit is present, the most recent inhibit reason is recorded in the ECM history. The scan tool will display the most recent inhibit reason, in which one out of approximately 50 possible reasons will be displayed.

Cruise Control Inhibited

The engine control module (ECM) inhibits the cruise control operation when any of the following conditions exist

  1. The ECM has not detected a brake pedal activation from the body control module (BCM) this ignition cycle.
  2. A Cruise Control System DTC has been set.
  3. The vehicle speed is less than 38.6 km/h (24 mph).
  4. The vehicle speed is too high.
  5. The vehicle is in PARK, REVERSE, NEUTRAL, or 1st gear.
  6. The engine RPM is low.
  7. The engine RPM is high.
  8. The system voltage is not between 9 volts and 16 volts.
  9. The Antilock Brake System (ABS)/Traction Control System (TCS) is active for more than 0.5 seconds.

Cruise Control Inhibit Reasons

This is a general list of inhibit reasons. Not every inhibit reason is applicable to all vehicles. Refer to the scan tool inhibit reason list for the last 8 reasons that have been recorded during the current ignition cycle.

Scan Tool NameDescriptionLong Description
BRAKEBrake pedal applyBrake Pedal was applied.
PEDAL INITIALIZEBrake before cruiseThe brake pedal has not been seen as applied prior to driver request to engage cruise with set switch. A brake pedal apply must be seen before allowing cruise engagement during each key cycle. On a vehicle equipped with a manual transmission, a clutch pedal apply may satisfy the brake pedal apply criteria.
CANCELCancel switch activeCancel Switch was depressed.
CLUTCHClutch switch activeClutch Pedal was applied.
COAST DISENGAGECoast disengageCruise control is in coast mode with the Set/Coast switch depressed and is requesting no throttle
COAST SPEED LOWCoast below low speed inhibitSet / Coast switch was depressed. Vehicle slowed below minimum cruise operating speed.
TAC INHIBITETC prevents cruise operationElectronic Throttle Control has detected a failure in the throttle control hardware
ACCEL RATEHigh accelerationVehicle acceleration rate is too high.
DECEL RATEHigh decelerationVehicle deceleration rate is too high.
HIGH SPEEDVehicle speed exceeds high speed thresholdVehicle speed has exceeded maximum cruise operating speed
ILLEGAL MODEIllegal cruise modeCruise control mode is incorrect based on switch states.
LOW SPEEDVehicle speed drops below low speed thresholdVehicle speed dropped below the cruise control minimum operating speed. May be due to hilly terrain and low vehicle speed. Manual transmission gear selection and engine torque may contribute to this disengagement reason.
NONENoneThis disengagement reason may be displayed after a dead battery repair or module replacement.
CRUISE SW. OFFOn/Off switch in Off stateCruise On/Off switch turned Off
OVER SET SPEEDOver scheduleVehicle speed has exceeded driver selected set speed by more than an allowable amount. This may occur while driving down a significant grade or driver overriding cruise while performing a passing maneuver.
S/C ON SPEED HIOver schedule tap-downSet/Coast switch selected, vehicle speed is above set speed and does not decrease. May be due to traveling down hill
ECM INHIBITPCM/ECM inhibit (RAM corruption)ECM internal communication error
SIMUL S/C-R/ASET and RESUME switches simultaneously activeSet/Coast and Resume Accelerate switches pressed simultaneously
TCSTraction control activeTraction Control was Active
UNDER SET SPEEDUnder scheduleVehicle speed is below cruise control set speed by more than an allowable amount
DLC OVERRIDEALDLScan Tool plugged into ALDL connector
MEMORY DTCMemory FailureControl module memory failure detected.
ENG RUN TIMEEngine run time not elapsedEngine has not been running long enough, typically five seconds.
ENGINE SPEEDEngine speed too low or too highEngine RPM too low (near stall) or too high (near engine RPM fuel shutoff).
DTC SETMalfunction in PCM/ECM (DTC active)DTC is active or in history that inhibits cruise control operation.
RPM LIMITInjectors Disabled (Engine overspeed fuel cut-off active)Engine RPM limiter active with fuel cut off active.
FIRST GEAR1st GearTransmission is engaged in 1st gear
APP OVERRIDEPedal greater than cruise (override)Driver has overridden cruise control set speed with accelerator pedal for greater than an allowable time.
LOW VOLTAGEVoltage below low voltage thresholdIgnition Voltage Low at ECM (typically 9 volts)
LOST FWD GEARTransmission in neutral. Reverse or parkGear selector not in forward gear
MPH LIMITMPH Limited Fuel (Vehicle overspeed fuel cut-off active)Vehicle overspeed protection active with fuel cut off active
SW. INVALIDAnalog cruise switch input out of rangeCruise switch voltage signal in invalid range
HIGH VOLTAGEVoltage above high voltage thresholdIgnition Voltage High at ECM (typically 18 volts)
D WHL SPD LOWUn-driven Whl speed GreaterNon Driven wheel speed greater than driven wheel speed
D WHL SPD HIDriven Whl Spd Greater (wheel slip detection)Driven wheel speed greater than Non Driven wheel speed (slip detection)
CRUISE S/WSequence of completion checksCruise control software execution error has occurred.
CRUISE SW DATASerial data fault (Cruise switch serial communication fault)Cruise switch serial data fault is active or communication has been lost with module sending cruise switch states
ECT OVERTEMPEngine metal overtemp activeEngine over temperature. Overheated.
VSESVehicle stability activeVehicle Stability Control was active
AXLE RANGERear Axle LowRear axle in low range
TRANS DTCTrans Gear FaultTransmission DTC is active or in history that inhibits cruise control operation
BPP DATADTC P0703 active or maximum time elapsed without receiving valid Brake Pedal Position signal.Serial data fault is active or communication has been lost with module sending brake pedal apply state
BPP DTCBrake Pedal Position signal invalidBrake Pedal Apply Circuit fault has been detected.
PARK BRAKEPark Brake Switch signal ActiveParking Brake Applied
ACC INHIBITAdaptive Cruise Control InhibitedAdaptive Cruise Control Inhibited
ACC BRAKE INOPAdaptive Cruise Control Automatic Braking FailedAdaptive Cruise Control Automatic Braking Inoperative
ACC OPTIONAdaptive Cruise Control option mismatchCruise control type (adaptive cruise or conventional cruise) mismatched between ECM and BCM.
ACC DATASerial data fault for Adaptive Cruise Control Throttle Control and Brake Control signals sent by Adaptive Cruise Control moduleAdaptive Cruise Control Module serial data fault is active or communication has been lost between ACC module and ECM.
PTO ACTIVEPower Take Off ActivePower Take Off is active.
ECM RESETECM Running ResetECM Running Reset occurred
Ram DTCProcessor Integrity Fault (Ram corruption)ECM software error has occurred
BPP Not LearnedBrake Apply Sensor Home Position Not LearnedBrake Pedal Position Sensor Released Position Not Learned.
Accel TimeRate Limiting FaultCruise torque request rate limiting active too long
4WD Low4WD LowTransfer case in low range
M/T Gear ChangedManual transmission out of gear with no clutch pedal applyManual transmission shifted to Neutral without clutch pedal being applied.
Brk Ped PressBrake Pedal Driver Applied Pressure DetectedA Brake Pedal Apply has been detected based on brake pedal pressure as measured by the EBCM.
SL/W Sys OnSpeed Limiter / Warning On/Off switch turned onDriver has turned on the Speed Limiter/Warning on/off switch. Cruise is disabled / inhibited and cruise on/off switch will be set to OFF.
Calc Eng TorqueCalculated TorqueEngine torque calculation is incorrect.
Cruise Brk InopBrake System MalfunctionEBCM has detected a failure that does not allow automatic braking to be performed.
Auto Brk DataAutomatic Braking Engine Torque Request Signal Communication MalfunctionECM to EBCM serial data fault is active or communication has been lost between ECM and EBCM.
