SIR Identification Views
The SIR Identification Views shown below illustrate the approximate location of all SIR components available for the vehicle. This will assist in determining the appropriate SIR Disabling and Enabling for a given service procedure, refer to SIR Disabling and Enabling .
Scheme 5
| Callout | Component Name |
|---|---|
| 1 | Right Front Impact Sensor - Located under the hood at the front right side of the vehicle |
| 2 | Front Hood Assist Rod - A gas shock located under the front hood on the passenger side |
| 3 | Passenger Instrument Panel Air Bag - Located at the top right under the instrument panel |
| 4 | Right Roof Rail Air Bag - Located under the headliner, extending from the passenger front windshield pillar to the passenger rear windshield pillar |
| 5 | Right Front Side Impact Sensor - Located behind door panel on the passenger front door |
| 6 | Inflatable Restraint Sensing and Diagnostic Module - Located underneath the vehicle carpet under the center console |
| 7 | Passenger Seat Side Air Bag - Located on the seat back of passenger seat |
| 8 | Passenger Seat Belt Retractor Pretensioner - Located under the trim near the bottom of the center pillar on the passenger side of vehicle |
| 9 | Inflator Module for Right Roof Rail Air Bag - Located behind the garnish molding on the upper rear pillar |
| 10 | Rear Hood Assist Rod - A gas shock located under the rear truck lid on the passenger side |
| 11 | Rear Hood Assist Rod - A gas shock located under the rear truck lid on the driver side |
| 12 | Inflator Module for Left Roof Rail Air Bag - Located behind garnish molding on the upper rear pillar |
| 13 | Driver Seat Belt Retractor Pretensioner - Located under the trim near the bottom of the center pillar on the driver side of vehicle |
| 14 | Driver Seat Side Air Bag - Located on the seat back of driver seat |
| 15 | Left Front Side Impact Sensor - Located behind door panel on the driver front door |
| 16 | Left Roof Rail Air Bag - Located under the headliner, extending from the driver front windshield pillar to the driver rear windshield pillar |
| 17 | Driver Steering Wheel Air Bag - Located on the steering wheel |
| 18 | Front Hood Assist Rod - A gas shock located under the front hood on the driver side |
| 19 | Vehicle Battery - Located at the front left of the engine compartment |
| 20 | Left Front Impact Sensor - Located under the hood at the front left side of the vehicle |
Circuit/System Description
During a frontal crash of sufficient force the Inflatable Restraint Sensing and Diagnostic Module (SDM) will allow current to flow through the deployment loop in order to deploy the steering wheel air bag. The SDM performs continuous diagnostic tests on the deployment loops to check for proper circuit continuity and for shorts to ground or voltage. There are 2 shorting bars used within the steering wheel air bag coil connector which will short together both steering wheel air bag stage 1 high control circuit and steering wheel air bag stage 1 low control circuit and both steering wheel air bag stage 2 high control circuit and steering wheel air bag stage 2 low control circuit when the connector is disconnected. This will help to prevent unwanted deployment of the steering wheel air bag during servicing.
During a side or frontal crash of sufficient force the Inflatable Restraint Sensing and Diagnostic Module will allow current to flow through the deployment loop in order to deploy an air bag. There are 2 shorting bars used within the connector that will short together the control circuits, when the connector is disconnected. This will help to prevent unwanted deployment of the air bag or retractor pretensioner during servicing.
During a side or frontal crash of sufficient force the Inflatable Restraint Sensing and Diagnostic Module will allow current to flow through the deployment loop in order to deploy an air bag or pretensioner. There are 2 shorting bars which will short together control circuits, when the connector is disconnected. This will help to prevent unwanted deployment of the air bag or pretensioner during servicing.
During a side or frontal crash of sufficient force the Inflatable Restraint Sensing and Diagnostic Module will allow current to flow through the deployment loop in order to deploy an air bag or pretensioner. There are 2 shorting bars which will short together control circuits, when the connector is disconnected. This will help to prevent unwanted deployment of the air bag or pretensioner during servicing.
During a side or frontal crash of sufficient force the Inflatable Restraint Sensing and Diagnostic Module (SDM) will allow current to flow through the deployment loop in order to deploy an air bag. There are two shorting bars used within the connector that will short together the control circuits, when the connector is disconnected. This will help to prevent unwanted deployment of the air bag or retractor pretensioner during servicing.
During a side or frontal crash of sufficient force the Inflatable Restraint Sensing and Diagnostic Module (SDM) will allow current to flow through the deployment loop in order to deploy an air bag or pretensioner. There are 2 shorting bars which will short the control circuits together when the connector is disconnected. This will help to prevent unwanted deployment of the air bag or pretensioner during servicing.
The inflatable restraint sensing and diagnostic module (SDM) senses vehicle impacts and provides deployment signals to the air bags and anchor and/or retractor pretensioners when warranted. The inflatable restraint sensing and diagnostic module sets DTC B0052 after each command for deployment. DTC B0052 will latch and not clear after 3 commanded deployments by the inflatable restraint sensing and diagnostic module. Therefore the inflatable restraint sensing and diagnostic module has to be replaced.
The passenger presence module monitors the passenger presence sensor status continuously. Whenever the passenger presence sensor has an internal malfunction, the passenger presence module will set DTC B0074.
When the ignition is turned ON, the Inflatable Restraint Sensing and Diagnostic Module and the Passenger Presence Module perform tests to diagnose critical malfunctions. Upon a successful power-up mode the Inflatable Restraint Sensing and Diagnostic Module will illuminate both PASSENGER AIRBAG ON/OFF indicators located in the overhead center console. If the Inflatable Restraint Sensing and Diagnostic Module detects a fault in the Passenger Presence Module, it may disable the front passenger air bag deployment loop, set DTC B0081 00 or DTC B0081 3A and illuminate the AIRBAG indicator.
When the ignition is turned ON, the Inflatable Restraint Sensing and Diagnostic Module and the Passenger Presence Module perform tests to diagnose critical malfunctions. Upon a successful power-up mode the Inflatable Restraint Sensing and Diagnostic Module will illuminate both PASSENGER AIRBAG ON/OFF indicators. If the Inflatable Restraint Sensing and Diagnostic Module detects a fault in the Passenger Presence Module, it may disable the passenger instrument panel air bag deployment loop, set DTC B0081 and illuminate the AIRBAG indicator.
The impact sensors are equipped on vehicles to supplement the Supplemental Inflatable Restraint (SIR) System performance. The impact sensors are electronic and are not part of the deployment loops, but instead provide inputs to the Inflatable Restraint Sensing and Diagnostic Module. The impact sensors can assist in determining the severity of some frontal and side collisions. The Inflatable Restraint Sensing and Diagnostic Module uses the input from the impact sensors to assist in determining the severity of a collision further supporting air bag deployment. If the Inflatable Restraint Sensing and Diagnostic Module determines a deployment is warranted, the Inflatable Restraint Sensing and Diagnostic Module will cause current to flow through the deployment loops deploying the air bags.
The inflatable restraint sensing and diagnostic module (SDM) stores a primary data key, which is a 4-digit number. When the ignition is turned ON, the inflatable restraint sensing and diagnostic module compares this information to the information stored in the Body Control Module (BCM) via serial data. If there is a mismatch between the information stored in the inflatable restraint sensing and diagnostic module and Body Control Module, DTC B1001 will set.
The inflatable restraint sensing and diagnostic module monitors the number of safety components installed on the vehicle. When the ignition is turned ON, the inflatable restraint sensing and diagnostic module evaluates the number of safety components installed and compares it to the number of components the inflatable restraint sensing and diagnostic module expects to see on the vehicle with its current calibration. If there is a mismatch between detected components and the components programmed with the inflatable restraint sensing and diagnostic module calibration, DTC B1019 will set. The components (if equipped) that the inflatable restraint sensing and diagnostic module will detect include inflatable restraint deployment loops, impact sensors, passenger presence system components, seat position sensors, disable switches, and seat belt switches.
When the ignition is turned ON the driver air bag indicator will illuminate, and then turn OFF after the bulb check is complete. The inflatable restraint sensing and diagnostic module (SDM) performs diagnostic tests on the SIR system during the bulb check. If any malfunction exists the inflatable restraint sensing and diagnostic module will request the instrument cluster to illuminate the air bag indicator steady, via serial data. If a preexisting malfunction exists, the air bag indicator will illuminate steady immediately after the ignition is turned ON. If the ignition 1 voltage is outside of the normal operating voltage range of 9-16 V, the inflatable restraint sensing and diagnostic module will command the instrument cluster to illuminate the air bag indicator ON, even with no DTCs present, and then disable all deployment loops.
The passenger air bag ON/OFF indicators are used to notify the driver when the passenger presence system has enabled or disabled the passenger instrument panel air bag. When the ignition is turned ON, the ignition voltage is supplied to the passenger presence module. When the Inflatable Restraint Sensing and Diagnostic Module receives the appropriate serial data message from the passenger presence module the Inflatable Restraint Sensing and Diagnostic Module will then provide voltage to the appropriate indicator.
SIR System Overview
The supplemental inflatable restraint (SIR) system supplements the protection offered by the seat belts. The SIR system contains an inflatable restraint sensing and diagnostic module (SDM), air bags, seat belt pretensioners (anchor and retractor), and impact sensors. The SDM determines the severity of a collision with the assistance of side impact sensors located at strategic points on the vehicle. When the SDM detects a collision, the SDM will process the information provided by the sensors to further support air bag or pretensioner deployment. The SDM will deploy the air bags and pretensioners if it detects a collision of sufficient force. If the force of the impact is not sufficient to warrant air bag deployment, the SDM may still deploy the seat belt pretensioners. The SDM contains a sensing device that converts vehicle velocity changes to an electrical signal. The SDM compares these signals to values stored in memory. If the signals exceed a stored value, the SDM will determine the severity of the impact and either cause current to flow through the frontal deployment loops deploying the frontal air bags and pretensioners, or it will deploy the pretensioners only. The SDM continuously monitors the deployment loops for malfunctions and illuminates the AIR BAG indicator if a fault is detected. The SDM performs continuous diagnostic monitoring of the SIR system electrical components. Upon detection of a circuit malfunction, the SDM will set a DTC and inform the driver by illuminating the AIR BAG indicator. The steering column and knee bolsters are designed to absorb energy and compress during frontal collisions in order to limit leg movement and decrease the chance of injury to the driver and passenger.
