Removal Procedure
- Remove the front door trim panel upper extension. Refer to «Upper Extension Trim Panel Replacement»(ref-277840-S15690495822008012100000) .
- Remove the nuts that retain the outside mirror to the door.
- Remove the outside mirror from the door.
Installation Procedure
- Install the rearview mirror to the door, pressing the outside mirror into place.
- Install the nuts in order to retain the outside mirror to the door. Tighten: Tighten the outside rearview mirror retaining nuts to 9 N.m (80 lb in).
- Install the front door trim panel upper extension. Refer to «Upper Extension Trim Panel Replacement»(ref-277840-S15690495822008012100000) .
- Remove the trim panel upper extension. Refer to «Upper Extension Trim Panel Replacement»(ref-277840-S15690495822008012100000) .
- Remove the insulator, if equipped.
- Remove the front door trim panel. Refer to «Front Side Door Trim Panel Replacement»(ref-277840-S23501543032008012100000) .
- Remove the water deflector. Refer to «Front Side Door Water Deflector Replacement»(ref-277840-S19341828212008012100000) .
- Disconnect the mirror wiring harness from the door.
- Remove the nuts securing the outside mirror to the door.
- Remove the mirror from the door.
- Install the outside mirror to the door. Press the mirror into place.
- Install the nuts in order to secure the outside mirror to the door. Tighten: Tighten the outside mirror nuts to 9 N.m (80 lb in).
- Connect the mirror wiring harness to the door.
- Install the water deflector. Refer to «Front Side Door Water Deflector Replacement»(ref-277840-S19341828212008012100000) .
- Install the front door trim panel. Refer to «Front Side Door Trim Panel Replacement»(ref-277840-S23501543032008012100000) .
- Install the insulator, if equipped.
- Install the trim panel upper extension. Refer to «Upper Extension Trim Panel Replacement»(ref-277840-S15690495822008012100000) . IMPORTANT: After servicing the power-folding mirrors, it is necessary to ensure that they are set in the full locked position. The mirror housing must be fully retracted inboard and then extended to its outboard position to lock the mirror in place. Cycle the power folding mirrors 3 times using the mirror switch on the drivers side door panel in order to fully implement the detent feature of these mirrors. Failure to do this could cause the mirrors to fold inward when the vehicle is at highway speeds.
- Adjust the mirror face fully upward in order to access the mirror retaining tab (4).
- Position a flat-bladed tool between the back side of the mirror face and the mirror housing at the notch in the mirror face.
- Depress the tab (4) on the back of the mirror face outward using the flat-bladed tool, while sliding the mirror face upward.
- Slide the mirror face upward to release the mirror face from the mirror motor retaining tabs (1).
- With the mirror face in hand, disconnect the electrical connectors (2).
- Remove the mirror face from the mirror housing.
- Connect the electrical connectors (2) to the back of the mirror (3).
- Align the mirror motor retaining tabs (1) to the keyhole slots on the back of the mirror face.
- Insert the motor retaining tabs to the keyhole slots on the mirror face.
- Slide the mirror face downward until the retaining clip (4) latches.
- Adjust the mirror face ensuring the mirror motor tabs are fully engaged in the keyhole slots on the back of the mirror and the retaining tab (4) is engaged.
| CAUTION | When working with any type of glass or sheet metal with exposed or rough edges, wear approved safety glasses and gloves in order to reduce the chance of personal injury. |
Note. When servicing electrochromic glass that is broken, or if glass breaks during servicing, be cautious not to spill electrochromic fluid onto vehicle. Doing so will cause damage to the vehicle.
- Adjust mirror face as shown in picture to obtain access to mirror face retention clips (1).
- Position a flat-bladed tool between back side of mirror face and the adjuster mechanism as shown in picture.
- With a twisting motion of the flat bladed tool, separate the mirror face from the adjuster mechanism by releasing the mirror face retention clips (1).
- With mirror face in hand, disconnect the electrical connectors.
- Remove the mirror face from the mirror housing.
- Inspect the adjuster mechanism for damage.
- Inspect the components for any damage. Ensure that the mirror face has all the retention clips in place.
- Plug in the electrical connectors to the back of the mirror.
- Align the mirror face retention clips with the adjuster mechanism.
- Gently press the mirror back into the adjuster mechanism with the palm of the hand on the center of the glass until it locks into place.
- Inspect the operation of the mirror.
- Disconnect the electrical connector from the back of the mirror.
- Remove the wire cover.
- Adjust the mirror to the full upward position.
- Remove the base trim cover.
- Loosen the screw (3) in order to remove the mirror (2) from the button assembly (1).
- Slide the mirror assembly in an upward motion in order to remove.
- Position the center bottom of the mirror mount against the windshield at the top of the support button (1).
- Slide the base of the mirror onto the button.
- Make sure the mirror is firmly seated on the windshield button by pushing down on the base of the mirror. Tighten: Tighten the screw (3) to 1.8 N.m (16 lb in) in order to secure the mirror base to the button.
- Install the base trim cover.
- Connect the electrical connector.
- Install the wire cover.
- Reposition the mirror assembly.
- Refer to «Control Module References»(ref-277885-S04826892822008012100000) for programming and setup information.
Rearview Mirror Support Installation
Tools Required
- Inside Mirror Adhesive Kit GM P/N 1052369 (Canadian P/N 993362), or equivalent
- Safety Razor or Utility Knife
Scheme 8
- Determine the location of the mirror mounting base by marking the outside of the windshield with a marking pencil where the base was previously located. If it is not clear where the base was mounted, use the following steps to determine where the base should be installed: Using a measuring tape, measure the distance between the windshield pillars from the base of the shade line. Using a marking pencil, halfway between the windshield pillars, draw a centerline (1) on the windshield from the roof panel to the windshield base. Draw a perpendicular line intersecting the centerline (2) at that location. The top center of the mirror mounting base will be at the intersection of these lines.
- Scrape the inside windshield thoroughly with a safety razor or utility knife in order to remove all old adhesive.
- If reinstalling the original mounting base, place the mirror mounting base in a suitable holding device, such as a vise.
- Clean the mirror mounting base thoroughly with a safety razor or utility knife in order to remove all old adhesive.
- Clean the inside windshield and the mounting surface of the mirror mounting base thoroughly with a clean cloth saturated with naphtha or a 50/50 mixture (by volume) of clean water and isopropyl alcohol.
- Use Inside Mirror Adhesive Kit GM P/N 1052369 (Canadian P/N 993362), or equivalent, to apply a small amount of activator to the mounting surface of the mirror mounting base.
- Apply a small amount of activator to the windshield where the mounting base is to be installed.
- Allow the activator to dry 5 minutes.
- Apply 1 drop of adhesive to the center of the mirror mounting base.
- Immediately apply the mounting base to the windshield, ensuring that the mounting base aligns correctly to the marks made on the outside of the windshield.
- Hold the mounting base firmly in place for 1 minute.
- Allow the adhesive to set for 15 minutes.
- Install the mirror to the mirror mounting base and fasten, if necessary.
- Connect the electrical connector and install the wire cover, if equipped.
Power Mirror System Components
The power mirror system consists of the following components
- The driver door module-Class 2 module with integrated switches and requires programming when replaced
- The passenger door module-Class 2 module with integrated switches, requires programming when replaced and also contains the RFA receiver
- The power mirror direction switch-Integrated into DDM and is a 4-position momentary switch that provides a signal input to the DDM for up, down, left/extend and right/retract with a mirror switch activation
- The mirror select switch-Integrated into DDM and is a 3-position switch that allows the operator to select the left or right mirror and also a neutral/fold position
- The left outside power mirror-Contains both the vertical and horizontal mirror motors and is serviced as a complete mirror assembly
- The right outside power mirror-Contains both the vertical and horizontal mirror motors and is serviced as a complete mirror assembly
- The body control module-Class 2 module that requires programming when replaced, serves as the power mode master and is the main message handler
- The DDM 10A fuse-Located in the I/P fuse block and is hot at all times
- The PDM 10A fuse-Located in the I/P fuse block and is hot at all times
- The memory switch, if equipped with memory mirrors-Supplied power by the DDM and provides a voltage signal to the DDM upon a switch activation
- The horizontal and vertical position sensors, if equipped with memory mirrors-Supplied a 5-volt and low reference by the DDM/PDM and provide a variable voltage signal to the DDM/PDM that is proportional to mirror position
- The park neutral position switch, if equipped with memory mirrors-Provides transmission gear selection information to the PCM and is used for memory recall and mirror tilt in reverse functions
- The powertrain control module, if equipped with memory mirrors-Class 2 module that requires programming when replaced and provides Class 2 message indicating transmission gear selection
- The driver information center (DIC), if equipped with memory mirrors-Part of the instrument cluster which is a Class 2 module that requires programming when replaced and is used to personalize the memory recall and mirror tilt in reverse functions
- Fold motor in each of the outside mirrors, if equipped with power fold mirrors-Provides extend and retract movements of the mirror and is serviced as a complete mirror assembly
Each of the outside power mirrors contains 2 reversible motors to provide horizontal and vertical movement of the mirror glass. The vertical motor operates the up and down directions and the horizontal motor operates the left and right directions. If equipped with power folding mirrors, each outside power mirror will contain a reversible fold motor to operate the extend and retract functions. Each of the mirror motors are circuit breaker protected.
Power Mirror System Controls
The power mirror switch incorporates a 3-position mirror select switch and a 4-position mirror direction switch. The mirror select switch allows the operator to select the mirror to be moved by selecting the L position for the left power mirror, selecting the R position for the right power mirror or the center which is the neutral/fold position. The mirror direction switch is a 4-position switch that allows the operator to move the selected mirror up, down, left or right. The mirror direction switch also functions as the folding mirror switch. When the selector switch is in the neutral/fold position, activate the mirror direction switch to the left to extend the mirrors and right to retract the mirrors.
Power Mirror System Operation
The power mirror switch is integrated into the DDM. The left and right mirror positions of the select switch and 4 positions of the direction switch, when active, will provide a signal to the DDM. If the selector switch is placed in the L position and the up switch is depressed, 2 signals will be supplied to the DDM. The DDM upon receipt of these signals will provide battery voltage to the mirror motor left/up control circuit and ground to the mirror motor down control circuit and the mirror will move up. The remainder of the driver mirror functions operate in the same manner as described above except the DDM will supply battery voltage and ground to the appropriate control circuits for the direction selected. If the passenger mirror is selected and a direction switch is activated, the DDM sends a class 2 message to the PDM indicating that the passenger mirror was selected and the direction to be commanded. The PDM will then supply battery voltage and ground to the appropriate control circuits for the direction selected.
Memory Mirror System Controls
The DDM and PDM are capable of storing mirror positions and controlling the mirrors to these positions to the preferred settings of 2 different drivers. Each driver will be able to personalize the memory system by positioning the mirrors and seats to their preferred settings. Then press and hold the memory 1 or memory 2 button until an audible chime is heard and the current mirror positions will be stored into memory of the DDM and PDM. Seat position will be stored in the driver seat module (DSM). Once the mirror and seat positions have been stored into memory, a momentary memory 1 or memory 2 switch activation will supply the DDM a battery voltage signal. The DDM, upon receipt of the memory switch signal, with the transmission in park or neutral, will then drive the driver mirror to the corresponding stored memory position. The DDM will also send a class 2 message to the PDM and DSM indicating that a memory switch activation occurred. The PDM will then drive the passenger mirror and the DSM will drive the driver seat to the corresponding stored memory position. The memory system can also be controlled by any of the following if programmed using the driver information center (DIC) to enable/disable the features
- Auto exit/entry seat positioning
- Mirror and seat position recall on a keyless entry unlock activation
- Mirror and seat position recall on ignition key insertion
- Mirror tilt in reverse
For further information on programming and configuration, refer to Driver Personalization.
Memory Mirror System Operation
Mirror position is determined by both horizontal and vertical position sensors in each of the power mirrors. The DDM and PDM supplies a reference voltage and a low reference to these sensors and determines mirror position through the horizontal and vertical position signal circuits.
The memory switch receives power from the DDM through the battery supply voltage circuit and the DDM fuse. The DDM upon receipt of a memory switch signal input or an appropriate class 2 message from the BCM, the DDM and PDM will then supply battery voltage and ground to the appropriate power mirror motors through the mirror motor control circuits to move the mirrors to the predetermined positions.
Mirror Tilt in Reverse Controls
This feature is capable of tilting the left, right or both power mirrors when the transmission is placed in reverse to provide enhanced visibility during parking or backing maneuvers and is programmable through the Driver Information Center. This feature can be personalized to the needs of 2 different drivers. For further information, refer to the Vehicle Owners Manual.
Mirror Tilt in Reverse Operation
When the vehicle is placed in reverse and the appropriate class 2 message from the BCM is received by the DDM and PDM, the DDM and PDM will then supply battery voltage and ground to the appropriate power mirror motors through the mirror motor control circuits to move the mirrors to the predetermined positions. The positions that are stored can be altered by starting the engine, applying the brake, placing the vehicle in reverse and controlling both the left and right mirrors the desired positions and shifting the vehicle out of reverse. These new positions will be stored for the last memory recall that happened.
Folding Mirror System Controls
The folding mirror system requires signals from 2 separate switches. The mirror select switch must be in the neutral/fold position and the mirror direction switch must be activated to the left/extend or right/retract positions. Both switches are integrated into the DDM and provide direct signals.
Folding Mirror System Operation
Upon receipt of the required switch inputs the DDM will supply battery voltage and ground to the mirror fold motor control circuits to perform the requested extend or retract function. The DDM will also send a class 2 message to the PDM indicating the requested function. The PDM will supply battery voltage and ground to the mirror fold motor control circuits to perform the requested extend or retract function.
