Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Horn Bolt | 9 N.m | 80 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Horn Schematics
Scheme 2
Scheme 2: Horn Component Views
| Callout | Component Name |
|---|
| 1 | Steering Wheel Control Switch Assembly - Upper Left |
| 2 | Passlock Sensor Connector |
| 3 | Ignition Key Alarm Switch |
| 4 | Ignition Lock Cylinder Control Actuator |
| 5 | Ignition Lock Cylinder Control Actuator Connector |
| 6 | Ignition Switch |
| 7 | Ignition Key Cylinder |
| 8 | Steering Wheel Control Switch Assembly - Upper Right |
| 9 | Horn Switch |
| 10 | Steering Wheel Control Switch Assembly - Lower Right |
| 11 | C277 |
| 12 | Steering Wheel Control Switch Assembly - Lower Left |
| 13 | Turn Signal/Multifunction Switch |
Scheme 3
| Callout | Component Name |
|---|
| 1 | Radiator Support |
| 2 | Horn - Right |
| 3 | Horn - Left |
Scheme 4
| Connector Part Information OEM: 12052644 Service: See Catalog Description: 2-Way F Metri-Pack 150 Series Sealed (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
Horn - Right Connector & Terminal Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | BK | 150 | Ground |
| B | D-GN | 1329 | Horn Fuse Supply Voltage |
Horn - Right Connector Terminal Identification
Horn - Left
| Connector Part Information OEM: 12052644 Service: See Catalog Description: 2-Way F Metri-Pack 150 Series Sealed (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
Horn - Left Connector & Terminal Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | BK | 150 | Ground |
| B | D-GN | 1329 | Horn Fuse Supply Voltage |
Horn - Left Connector Terminal Identification
