Lighting System: Overhaul — Chevrolet Silverado Classic 3500 (2007-2007)

Lighting System: Overhaul Chevrolet Silverado Classic 3500

Exterior Lights 3 illustrations ~164 words

Door Latch Assembly (Door Jamb Switch) - Left Rear - C2 (Crew Cab Only)

Connector Part Information OEM: 15366025 Service: 15306406 Description: 4-Way F GT 150 Series Sealed 3.2 X 4.0 (BK)
Terminal Part Information Terminal/Tray: 15326267/19 Core/Insulation Crimp: Pins B - E/4 Core/Insulation Crimp: Pins D - E/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)

Door Latch Assembly (Door Jamb Switch) Connector Part Information - Left Rear - C2 (Crew Cab Only)

Pin	Wire Color	Circuit No.	Function
A			Not Available
B	L-BU/BK	747	Left Rear Door Ajar Switch Signal
C			Not Available
D	BK	1150	Ground

Door Latch Assembly (Door Jamb Switch) Connector Terminal Identification - Left Rear - C2 (Crew Cab Only)

Scheme 56: Door Latch Assembly (Door Jamb Switch) - Passenger - C2

Connector Part Information OEM: 15366027 Service: 15306417 Description: 4-Way F GT 150 Series Sealed 3.2 X 4.0 (BK)
Terminal Part Information Terminal/Tray: 15326267/19 Core/Insulation Crimp: E/4 Release Tool/Test Probe: 15315247/J-35616-2A (GY)

Door Latch Assembly (Door Jamb Switch) Connector Part Information - Passenger - C2

Pin	Wire Color	Circuit No.	Function
A	D-GN	1178	Right Front Door Switch Low Reference (w/YE9)
A	BK	1050	Ground (w/o YE9)
B			Not Available
C	BK/WH	746	Right Front Door Ajar Switch Signal
D			Not Available

Door Latch Assembly (Door Jamb Switch) Connector Terminal Identification - Passenger - C2

Connector Part Information OEM: 15366025 Service: 15306406 Description: 4-Way F GT 150 Series Sealed 3.2 X 4.0 (BK)
Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit

Door Latch Assembly (Door Jamb Switch) Connector Part Information - Right Rear - C2 (Crew Cab Only)

Pin	Wire Color	Circuit No.	Function
A			Not Available
B	L-GN/BK	748	Right Rear Door Ajar Switch Signal
C			Not Available
D	BK	1250	Ground

Door Latch Assembly (Door Jamb Switch) Connector Terminal Identification - Right Rear - C2 (Crew Cab Only)

Scheme 57: Emergency Vehicle Roof Lamp Relay (5Y0)

Connector Part Information OEM: 12129716 Service: 15306045 Description: 4-Way F Metri-Pack 150 Series Sealed (GY)
Terminal Part Information Pins: 30, 85, 86 Terminal/Tray: 12110847/4 Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: 15315247/J-35616-4A (PU) Pins: 87 Terminal/Tray: 12110853/4 Core/Insulation Crimp: F/5 Release Tool/Test Probe: 15315247/J-35616-4A (PU)

Emergency Vehicle Roof Lamp Relay (5Y0) Connector Part Information

Pin	Wire Color	Circuit No.	Function
30	RD	242	Battery Positive Voltage
85	WH	111	Hazard Switch Signal
86	BK	1850	Ground
87	BN	27	Hazard Flasher Signal

Emergency Vehicle Roof Lamp Relay Connector Terminal Identification (5Y0)

Scheme 58: Fog Lamp - Left Front

Connector Part Information OEM: 12059183 Service: 12101898 Description: 2-Way F Metri-Pack 280 Series Sealed (BK)
Terminal Part Information Terminal/Tray: 12077411/2 Core/Insulation Crimp: 2/5 Release Tool/Test Probe: 12094430/J-35616-4A (PU)

Fog Lamp Connector Part Information - Left Front

Pin	Wire Color	Circuit No.	Function
A	PU	34	Fog Lamps Supply Voltage
B	BK	150	Ground

Fog Lamp Connector Terminal Identification - Left Front
