Seat Belt Schematic Icons
Seat Belt Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR DISABLING AND ENABLING . Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs
Scheme 1
Scheme 2
| Callout | Component Name |
|---|---|
| 1 | Seat Belt Buckle |
| 2 | Seat Belt Switch Connector |
Scheme 3
| Callout | Component Name |
|---|---|
| 1 | Seat Belt Buckle |
| 2 | Seat Belt Switch Connector (AL0) |
Scheme 4
| Connector Part Information OEM: 12047663 Service: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Seat Belt Buckle-Driver Connector & Terminal Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | BK/WH | 238 | Driver Seat Belt Switch Signal |
| B | YE | 234 | Low Reference |
Seat Belt Buckle-Driver Terminal Identification
Operational and Functional Checks
| IMPORTANT | If the vehicle has been in a collision, refer to Repairs and Inspections Required After a Collision for additional information. |
Perform the following inspection from the driver seat
- Turn the ignition switch to the ON position. Verify proper operation of the seat belt reminder lamp with the belt buckled and with the belt unbuckled.
- Inspect the shoulder belt guide in order to ensure that the following conditions are met: The shoulder belt guide swivels freely in the rear seat position. The seat belt webbing is seated flatly in the guide slot. The seat belt webbing does not bind.
- Verify that the seat belt buckle faces inboard and is accessible.
- Verify that the seat belt retractor units are securely attached.
- Verify that the seat belt anchor bolts are secure.
- Fully extend the seat belt webbing. Verify that the seat belt webbing does not have any twists or tears.
- Allow the seat belt webbing to retract. Verify that the seat belt webbing returns freely and completely back into the retractor. If the seat belt webbing will not retract, refer to «Seat Belt Does Not Retract»(ref-277867-S35222735142008012100000) .
- Snap the seat belt latch plate into the buckle.
- Sharply tug on the seat belt latch plate and the buckle. Verify that the seat belt latch plate and the buckle remain locked when tugged.
- Push the button on the buckle: Verify that the seat belt latch plate releases easily from the buckle. Verify that the button returns to its original position.
Repeat the inspection procedure, steps 2-10, from the front passenger seat.
Test the function of the automatic locking child restraint feature
- To engage the automatic locking feature, pull the belt to the fully extended position. Allow the belt to retract to the proper position for the child seat and fasten the latch plate to the buckle. As the belt retracts, a ratcheting sound should be heard.
- To disengage the automatic locking feature, allow the belt to retract to the fully stowed position. Before the belt is completely stowed, the cinch feature will reset, the ratcheting sound will stop and the belt will extract freely.
Perform the following steps in order to inspect the center seat belts
- Verify that the center seat belts are accessible.
- Verify that the center seat belts have no twists or tears in the webbing.
- Snap the center seat belt latch plate into the buckle.
- Sharply tug on the seat belt latch plate and the buckle. Verify that the seat belt latch plate and the buckle remain locked when tugged.
- Push the button on the buckle: Verify that the seat belt latch plate releases easily from the buckle. Verify that the button returns to its original position.
Repeat the inspection procedure, steps 2-10, from the rear seats. The child restraint feature is located on the outboard position for the rear seat.
Repeat the center seat belt inspection procedure, steps 1-5, from the rear seat.
For information on removal of the rear seats cushions, refer to Rear Seat Replacement (60/40 Split) or Rear Seat Replacement (Extended Cab) or Rear Seat Replacement (Extended Cab w/4th Door) .
Circuit/System Description
The inflatable restraint sensing and diagnostic module (SDM) sends the status of the driver and passenger seat belt switch to the instrument panel cluster (IPC) via a serial data communication message. If the seat belt is unfastened, the SDM will send a message to the IPC to illuminate the fasten safety belt indicator for 72 seconds or until the seat belt is fastened.
