| Metric | English |
| Air Cleaner Outlet Duct Clamp | 4 N.m | 35 lb in |
| Air Conditioning (A/C) Compressor Bolt (6.6L) | 50 N.m | 37 lb ft |
| Air Inlet Tube Nut (6.6L) | 25 N.m | 18 lb ft |
| Auxiliary Water Pump Bracket Nut | 9 N.m | 80 lb in |
| Bypass Pipe to Water Pump Bolt (6.6L) | 21 N.m | 16 lb ft |
| Charged Air Cooler Duct Clamp (6.6L) | 6 N.m | 53 lb in |
| Coolant Air Bleed Pipe Cover Bolt (4.8L, 5.3L, and 6.0L) | 12 N.m | 106 lb in |
| Coolant Air Bleed Pipe Stud/Bolt (4.8L, 5.3L, and 6.0L) | 12 N.m | 106 lb in |
| Coolant Heater (4.8L, 5.3L, and 6.0L) | 50 N.m | 37 lb ft |
| Coolant Heater (8.1L) | 60 N.m | 47 lb ft |
| Coolant Heater Bolt (4.3L) | 2 N.m | 18 lb in |
| Coolant Heater Bolt (6.6L) | 2 N.m | 18 lb in |
| Coolant Heater Cord Bolt | 8 N.m | 71 lb in |
| Coolant Outlet Pipe Clip Bolt (6.6L) | 9 N.m | 80 lb in |
| Cooling Fan Motor Bolt | 10 N.m | 89 lb in |
| Engine Block Coolant Drain Plug | 60 N.m | 44 lb ft |
| Engine Cooling Fan Shroud Bolt | 8 N.m | 71 lb in |
| Engine Shield Bolt | 20 N.m | 15 lb ft |
| Exhaust Gas Recirculation (EGR) Coolant Pipe Bolt (6.6L) | 21 N.m | 16 lb ft |
| Exhaust Manifold Pipe Nut (4.8L, 5.3L, and 6.0L) | 50 N.m | 37 lb ft |
| Fan Clutch Bolt | 23 N.m | 17 lb ft |
| Fan Clutch Nut | 56 N.m | 41 lb ft |
| Fan Pulley Bolt/Nut (6.6L) | 46 N.m | 34 lb ft |
| Fan Shroud Bolt | 9 N.m | 80 lb in |
| Fuel Line Bracket Bolt (6.6L) | 21 N.m | 15 lb ft |
| Fuel Line to Fuel Injection Control Module Bolt (6.6L) | 35 N.m | 26 lb ft |
| Generator Bracket Bolt (6.6L and 8.1L) | 50 N.m | 37 lb ft |
| Generator Bracket Stud (8.1L) | 20 N.m | 15 lb ft |
| Generator Control Module (GCM) Brace Bolts | 25 N.m | 18 lb ft |
| Generator Control Module (GCM) Coolant Pump Bolts | 9 N.m | 80 lb in |
| Generator Control Module (GCM) Coolant Tank Bolts | 20 N.m | 15 lb ft |
| Generator Control Module (GCM) Coolant Tank Nuts | 9 N.m | 80 lb in |
| Generator Control Module (GCM) Cooling Fan Bolt | 9 N.m | 80 lb in |
| Generator Control Module (GCM) Radiator Bolt | 9 N.m | 80 lb in |
| Generator Positive Cable Nut (6.6L) | 9 N.m | 80 lb in |
| Heater Inlet Pipe to Fuel Filter Bolt (6.6L) | 21 N.m | 16 lb ft |
| Heater Inlet Pipe to Thermostat Bolt (6.6L) | 21 N.m | 16 lb ft |
| Heater Outlet Hose Bracket Bolt (6.6L) | 21 N.m | 16 lb ft |
| Hood Hinge Bolts | 25 N.m | 18 lb ft |
| Idler Pulley Bolt (6.6L) | 43 N.m | 32 lb ft |
| Intake Manifold Cover Clamp (6.6L) | 6 N.m | 53 lb in |
| Junction Block Bracket Bolt (6.6L) | 9 N.m | 80 lb in |
| Main Electrical Harness Bracket Bolt (6.6L) | 21 N.m | 15 lb ft |
| Main Engine Electrical Harness Connector Bolt (6.6L) | 10 N.m | 89 lb in |
| Oil Cooler Hose Adapter Bolt (6.0L) | 12 N.m | 106 lb in |
| Oil Cooler Hose Bracket Bolt (6.0L) | 25 N.m | 18 lb ft |
| Oil Cooler Hose Bracket Bolt (8.1L) | 50 N.m | 37 lb ft |
| Positive Crankcase Ventilation (PCV) Oil Separator Bracket Nut (6.6L) | 21 N.m | 16 lb ft |
| Power Steering Pump Bracket Bolt (6.6L) | 46 N.m | 34 lb ft |
| Radiator Bolt | 25 N.m | 18 lb ft |
| Starter/Generator Stator Coolant Inlet Pipe Bolt | 9 N.m | 80 lb in |
| Surge Tank Bolt/Nut | 9 N.m | 80 lb in |
| Thermal Bypass Fitting | 35 N.m | 26 lb ft |
| Thermal Bypass Hose Bolt | 10 N.m | 89 lb in |
| Thermostat Housing Bolt (4.8L, 5.3L, and 6.0L) | 15 N.m | 11 lb ft |
| Thermostat Housing Cover Bolt (6.6L) | 21 N.m | 16 lb ft |
| Thermostat Housing Crossover Bolt/Nut (6.6L) | 21 N.m | 16 lb ft |
| Transmission Control Module (TCM) Cover Bolt | 9 N.m | 80 lb in |
| Transmission Control Module (TCM) Electrical Connector Bolt | 8 N.m | 71 lb in |
| Turbocharger Coolant Bypass Valve (6.6L) | 60 N.m | 44 lb ft |
| Turbocharger Coolant Feed Pipe Bracket Bolt (6.6L) | 21 N.m | 16 lb ft |
| Turbocharger Coolant Feed Pipe Nut (6.6L) | 9 N.m | 80 lb in |
| Turbocharger Coolant Inlet Banjo Bolt (6.6L) | 25 N.m | 18 lb ft |
| Turbocharger Coolant Outlet Pipe Bolt/Nut (6.6L) | 9 N.m | 80 lb in |
| Water Crossover Bolt (8.1L) | 50 N.m | 37 lb ft |
| Water Outlet Bolt (8.1L) | 30 N.m | 22 lb ft |
| Water Outlet Stud (4.3L) | 25 N.m | 18 lb ft |
| Water Outlet Tube Bolt (6.6L) | 21 N.m | 16 lb ft |
| Water Pump Bolt (4.3L) | 45 N.m | 33 lb ft |
| Water Pump Bolt (4.8L, 5.3L, and 6.0L) |
| First Pass | 15 N.m | 11 lb ft |
| Final Pass | 30 N.m | 22 lb ft |
| Water Pump Bolt (6.6L) | 21 N.m | 16 lb ft |
| Water Pump Bolt (8.1L) | 50 N.m | 37 lb ft |
| Water Pump Inlet Pipe Bolt (6.6L) | 21 N.m | 16 lb ft |
| Water Pump Pulley Bolt (4.3L) | 25 N.m | 18 lb ft |
| Water Pump to Oil Cooler Inlet Pipe Nut (6.6L) | 21 N.m | 16 lb ft |
| Wiring Harness Bracket to Thermostat Housing Bolt (6.6L) | 8 N.m | 71 lb in |
