Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Rear Heated Seat Switch Screws | 1.6 N.m | 14 lb in |
Fastener Tightening Specifications
Scheme 26
Scheme 26: Heated/Cooled Seat Schematics
Scheme 27
Scheme 28
Scheme 28: Heated/Cooled Seat Component Views
| Callout | Component Name |
|---|
| 1 | C321 |
| 2 | Memory Seat Module - C4 |
| 3 | Seat Adjuster Switch Connector - Driver |
| 4 | Memory Seat Module - C3 |
| 5 | Seat Adjuster Switch - Driver |
| 6 | Seat Bolster/Lumbar Switch Connector - Driver |
| 7 | Seat Adjuster Switch - Driver |
| 8 | Seat Bolster/Lumbar Switch - Driver |
| 9 | Seat Recline Position Sensor - Driver |
| 10 | Seat Recliner Motor - Driver |
| 11 | C305 |
| 12 | C323 |
| 13 | C325 |
| 14 | C322 |
| 15 | Seat Rear Vertical Motor Position Sensor - Driver |
| 16 | Seat Front Vertical Motor Position Sensor - Driver |
| 17 | Seat Rear Vertical Motor - Driver |
| 18 | Seat Front Vertical Motor - Driver |
| 19 | Memory Seat Module - C2 |
| 20 | Memory Seat Module - C1 |
| 21 | Seat Horizontal Motor - Driver |
| 22 | C320 |
| 23 | Seat Horizontal Motor Seat Position Sensor - Driver |
Scheme 29
| Callout | Component Name |
|---|
| 1 | Seat Bolster Motor - Driver |
| 2 | Seat Lumbar Motor/Position Sensor - Driver |
| 3 | Seat Lumbar Motor - Driver |
| 4 | Heated Seat Element - Driver Cushion |
| 5 | Seat Bolster Motor/Position Sensor - Driver |
| 6 | C324 |
| 7 | Seat Belt Switch Connector |
| 8 | Heated Seat Element - Driver Cushion Connector |
Scheme 30
| Callout | Component Name |
|---|
| 1 | Seat Horizontal Motor - Passenger |
| 2 | Seat Front Vertical Motor - Passenger |
| 3 | Seat Rear Vertical Motor - Passenger |
| 4 | C388 |
| 5 | C326 |
| 6 | C399 |
| 7 | Seat Recliner Motor - Passenger |
| 8 | Seat Bolster/Lumbar Switch - Passenger |
| 9 | Seat Adjuster Switch - Passenger |
| 10 | Seat Adjuster Switch Connector |
Scheme 31
| Callout | Component Name |
|---|
| 1 | Seat Bolster Motor - Passenger |
| 2 | Seat Lumbar Motor - Passenger |
| 3 | Heated Seat Element - Passenger Cushion Connector |
| 4 | C329 |
Scheme 32
| Callout | Component Name |
|---|
| 1 | Driver Door |
| 2 | Driver Door Module (DDM) |
| 3 | Outside Rearview Mirror - Driver |
| 4 | Window Motor - Driver |
| 5 | Speaker - LF Door |
| 6 | Memory/Heated Seat Switch Connector |
| 7 | Speaker - LF Tweeter (UQ3) |
| 8 | Door Courtesy Lamp - LF |
| 9 | Driver Door Panel |
| 10 | Memory/Heated Seat Switch |
| 11 | Door Latch Assembly - Driver |
Scheme 33
| Callout | Component Name |
|---|
| 1 | Passenger Door Module (PDM) |
| 2 | Passenger Door |
| 3 | Door Latch Assembly - Passenger |
| 4 | Heated Seat Switch - Passenger |
| 5 | Door Courtesy Lamp - RF |
| 6 | Speaker - RF Tweeter (UQ3) |
| 7 | Heated Seat Switch Connector |
| 8 | Speaker - RF Door |
| 9 | Window Motor - Passenger |
| 10 | Outside Rearview Mirror - Passenger |
Scheme 34
Scheme 34: Driver Door Module (DDM) - C5 (Memory/Heated Seat Switch)
| Connector Part Information OEM: 6383393-4 Service: See Catalog Description: 12-Way F AMP 0.64 mm Unsealed (GN) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Driver Door Module (DDM) - C5 (Memory/Heated Seat Switch) Connector & Terminal Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | WH/BK | | Medium Heat Indicator Control |
| 2 | YE | | Low Heat Indicator Control |
| 3 | GY | | Back Only Select |
| 4 | L-BU | | Memory/Heated Seat Backlight |
| 5 | PK | | Memory 2 Switch Signal |
| 6 | | | Not Used |
| 7 | GN | | High Heat Indicator Control |
| 8 | BK | | Back Only Indicator |
| 9 | BU | | Back and Cushion Select |
| 10 | RD | | Memory 1 Switch Signal |
| 11 | BN | | Memory/Heated Switch Supply Voltage |
| 12 | | | Not Used |
Driver Door Module (DDM) - C5 (Memory/Heated Seat Switch) Connector Terminal Identification
Scheme 35
Scheme 35: Heated Seat Element - Driver Cushion
| Connector Part Information OEM: 12064778 Service: 12126020 Description: 2-Way M Metri-Pack 150 Series (L-GN) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Heated Seat Element - Driver Cushion Connector & Terminal Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | BN | 2077 | Heated Seat Cushion Element Supply Voltage |
| B | BK | 2078 | Heated Seat Cushion Element Control |
Heated Seat Element - Driver Cushion Connector Terminal Identification
