Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Rearview Mirror Screw | 2 N.m | 18 lb in |
| Outside Rearview Mirror Retaining Nut | 9 N.m | 80 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Inside Rearview Mirror Schematics
Scheme 2
Scheme 2: Outside Rearview Mirror Schematics
Scheme 3
Scheme 3: Mirror Component Views
| Callout | Component Name |
|---|
| 1 | Inside Rearview Mirror Connector |
| 2 | Inside Rearview Mirror |
Scheme 4
| Callout | Component Name |
|---|
| 1 | Ambient Air Temperature Sensor |
| 2 | Radiator Support |
Scheme 5
Scheme 5: Ambient Air Temperature Sensor (DF5)
| Connector Part Information OEM: 12052642 Service: 12101856 Description: 2-Way F Metri-Pack 150 Series Sealed (L-GN) |
|---|
| Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
Ambient Air Temperature Sensor (DF5) Connector & Terminal Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | D-GN/WH | 636 | Ambient Air Temperature Sensor Signal |
| B | BK/WH | 1704 | Low Reference |
Ambient Air Temperature Sensor (DF5) Connector Terminal Identification
Scheme 6
Scheme 6: Inside Rearview Mirror
| Connector Part Information OEM: 15324871 Service: 15306351 Description: 16-Way (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15355438/20 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-12 (BU) |
Inside Rearview Mirror Connector & Terminal Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1-2 | | | Not Used |
| 3 | D-BU | 2307 | Passenger Air Bag On Indicator Control (AY0) |
| 4 | D-GN | 2308 | Passenger Air Bag Off Indicator Control (AY0) |
| 5 | GY | 1690 | Automatic Day/Night Mirror Signal (DL3) |
| 6 | D-GN/WH | 636 | Ambient Air Temperature Sensor Signal (DF5) |
| 7 | BK/WH | 1704 | Low Reference (DF5) |
| 8 | BK | 1050 | Ground |
| 9 | L-GN | 24 | Backup Lamp Supply Voltage (DL3) |
| 10 | | | Not Used |
| 11 | D-GN/WH | 2514 | Keypad Signal (UE1) |
| 12 | L-GN/BK | 2515 | Keypad Supply Voltage (UE1) |
| 13 | YE | 1139 | Ignition 1 Voltage |
| 14 | YE/BK | 2516 | Keypad Green LED Signal (UE1) |
| 15 | BN/WH | 2517 | Keypad Red LED Signal (UE1) |
| 16 | PK | 1691 | Automatic Day/Night Mirror Low Reference (DF5) |
Inside Rearview Mirror Connector Terminal Identification
Scheme 7
Scheme 7: Rear Window Defogger Grid C1
| Connector Part Information OEM: 12092133 Service: 12167133 Description: 1-Way F Metri-Pack 630 Series Self Lock (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12103325/3 Core/Insulation Crimp: A/B Release Tool/Test Probe: 12094430/J-35616-42 (RD) |
Rear Window Defogger Grid C1 Connector & Terminal Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | PU | 293 | Rear Defogger Element Supply Voltage |
Rear Window Defogger Grid C1 Connector Terminal Identification
