Seat Belt System: Specifications Chevrolet Silverado 3500

Restraints Control Systems 3 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Center Front Seat Belt Bolt53 N.m39 lb ft
Center Front Seat Belt Buckle Bolt53 N.m39 lb ft
Center Rear Seat Belt Anchor Bolt52 N.m38 lb ft
Center Rear Seat Belt Retractor Bolt52 N.m38 lb ft
Front Seat Belt Buckle Nut53 N.m39 lb ft
Front Seat Retractor Bolt53 N.m39 lb ft
Front Seat Upper Anchor Bolt53 N.m39 lb ft
Outboard Seat Belt Anchor Nut53 N.m39 lb ft
Rear Seat Belt Buckle Bolt53 N.m39 lb ft
Rear Seat Belt Latch Cover Screw2 N.m18 lb in
Rear Seat Belt Retractor Bolts53 N.m39 lb ft
Rear Seat Belt to Body Bolt55 N.m41 lb ft
Retractor Tower Screw2 N.m18 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Seat Belt Schematics
Scheme 1: Seat Belt Schematics

Scheme 2

Scheme 2: Seat Belt Component Views
Scheme 2: Seat Belt Component Views
CalloutComponent Name
1Seat Belt Buckle
2Seat Belt Switch Connector

Scheme 3

Scheme 3
Scheme 3
CalloutComponent Name
1Seat Belt Buckle
2Seat Belt Switch Connector (AL0)
