Conversion - English/Metric
| English | Multiply/ Divide by | Metric |
|---|---|---|
| In order to calculate English measurement, divide by the number in the center column. In order to calculate metric measurement, multiply by the number in the center column. | ||
| Length | ||
| In | 25.4 | Mm |
| Ft | 0.3048 | M |
| Yd | 0.9144 | |
| Mi | 1.609 | Km |
| Area | ||
| Sq in | 645.2 | Sq mm |
| 6.45 | Sq cm | |
| Sq ft | 0.0929 | Sq m |
| Sq yd | 0.8361 | |
| Volume | ||
| Cu in | 16,387.0 | Cu mm |
| 16.387 | Cu cm | |
| 0.0164 | L | |
| Qt | 0.9464 | |
| Gal | 3.7854 | |
| Cu yd | 0.764 | Cu m |
| Mass | ||
| Lb | 0.4536 | Kg |
| Ton | 907.18 | |
| 0.907 | Tonne (t) | |
| Force | ||
| Kg F | 9.807 | Newtons (N) |
| Oz F | 0.2780 | |
| Lb F | 4.448 | |
| Acceleration | ||
| Ft/s 2 | 0.3048 | M/s 2 |
| In/s 2 | 0.0254 | |
| Torque | ||
| Lb in | 0.11298 | N.m |
| Lb ft | 1.3558 | |
| Power | ||
| Hp | 0.745 | KW |
| Pressure (Stress) | ||
| Inches of H2O | 0.2488 | KPa |
| Lb/sq in | 6.895 | |
| Energy (Work) | ||
| Btu | 1055.0 | J (J= one Ws) |
| Lb ft | 1.3558 | |
| KW hour | 3,600,000.0 | |
| Light | ||
| Foot Candle | 10.764 | Lm/m 2 |
| Velocity | ||
| Mph | 1.6093 | Km/h |
| Temperature | ||
| (°F - 32) 5/9 | = | °C |
| °F | = | (9/5 °C + 32) |
| Fuel Performance | ||
| 235.215/mpg | = | 100 km/L |
Conversion - English/Metric
Equivalents - Decimal and Metric
| Fraction (in) | Decimal (in) | Metric (mm) |
|---|---|---|
| 1/64 | 0.015625 | 0.39688 |
| 1/32 | 0.03125 | 0.79375 |
| 3/64 | 0.046875 | 1.19062 |
| 1/16 | 0.0625 | 1.5875 |
| 5/64 | 0.078125 | 1.98437 |
| 3/32 | 0.09375 | 2.38125 |
| 7/64 | 0.109375 | 2.77812 |
| 1/8 | 0.125 | 3.175 |
| 9/64 | 0.140625 | 3.57187 |
| 5/32 | 0.15625 | 3.96875 |
| 11/64 | 0.171875 | 4.36562 |
| 3/16 | 0.1875 | 4.7625 |
| 13/64 | 0.203125 | 5.15937 |
| 7/32 | 0.21875 | 5.55625 |
| 15/64 | 0.234375 | 5.95312 |
| 1/4 | 0.25 | 6.35 |
| 17/64 | 0.265625 | 6.74687 |
| 9/32 | 0.28125 | 7.14375 |
| 19/64 | 0.296875 | 7.54062 |
| 5/16 | 0.3125 | 7.9375 |
| 21/64 | 0.328125 | 8.33437 |
| 11/32 | 0.34375 | 8.73125 |
| 23/64 | 0.359375 | 9.12812 |
| 3/8 | 0.375 | 9.525 |
| 25/64 | 0.390625 | 9.92187 |
| 13/32 | 0.40625 | 10.31875 |
| 27/64 | 0.421875 | 10.71562 |
| 7/16 | 0.4375 | 11.1125 |
| 29/64 | 0.453125 | 11.50937 |
| 15/32 | 0.46875 | 11.90625 |
| 31/64 | 0.484375 | 12.30312 |
| 1/2 | 0.5 | 12.7 |
| 33/64 | 0.515625 | 13.09687 |
| 17/32 | 0.53125 | 13.49375 |
| 35/64 | 0.546875 | 13.89062 |
| 9/16 | 0.5625 | 14.2875 |
| 37/64 | 0.578125 | 14.68437 |
| 19/32 | 0.59375 | 15.08125 |
| 39/64 | 0.609375 | 15.47812 |
| 5/8 | 0.625 | 15.875 |
| 41/64 | 0.640625 | 16.27187 |
| 21/32 | 0.65625 | 16.66875 |
| 43/64 | 0.671875 | 17.06562 |
| 11/16 | 0.6875 | 17.4625 |
| 45/64 | 0.703125 | 17.85937 |
| 23/32 | 0.71875 | 18.25625 |
| 47/64 | 0.734375 | 18.65312 |
| 3/4 | 0.75 | 19.05 |
| 49/64 | 0.765625 | 19.44687 |
| 25/32 | 0.78125 | 19.84375 |
| 51/64 | 0.796875 | 20.24062 |
| 13/16 | 0.8125 | 20.6375 |
| 53/64 | 0.828125 | 21.03437 |
| 27/32 | 0.84375 | 21.43125 |
| 55/64 | 0.859375 | 21.82812 |
| 7/8 | 0.875 | 22.225 |
| 57/64 | 0.890625 | 22.62187 |
| 29/32 | 0.90625 | 23.01875 |
| 59/64 | 0.921875 | 23.41562 |
| 15/16 | 0.9375 | 23.8125 |
| 61/64 | 0.953125 | 24.20937 |
| 31/32 | 0.96875 | 24.60625 |
| 63/64 | 0.984375 | 25.00312 |
| 1 | 1.0 | 25.4 |
Equivalents - Decimal and Metric
Abbreviations and Meanings
| Abbreviation | Meaning |
|---|---|
| A | |
| A | Ampere(s) |
| ABS | Antilock Brake System |
| A/C | Air Conditioning |
| AC | Alternating Current |
| ACC | Accessory, Automatic Climate Control |
| ACL | Air Cleaner |
| ACR4 | Air Conditioning Refrigerant, Recovery, Recycling, Recharging |
| AD | Automatic Disconnect |
| A/D | Analog to Digital |
| ADL | Automatic Door Lock |
| A/F | Air/Fuel Ratio |
| AH | Active Handling |
| AIR | Secondary Air Injection |
| ALC | Automatic Level Control, Automatic Lamp Control |
| AM/FM | Amplitude Modulation/Frequency Modulation |
| Ant | Antenna |
| AP | Accelerator Pedal |
| APCM | Accessory Power Control Module |
| API | American Petroleum Institute |
| APP | Accelerator Pedal Position |
| APT | Adjustable Part Throttle |
| ASM | Assembly, Accelerator and Servo Control Module |
| ASR | Acceleration Slip Regulation |
| A/T | Automatic Transmission/Transaxle |
| ATC | Automatic Transfer Case, Automatic Temperature Control |
| ATDC | After Top Dead Center |
| ATSLC | Automatic Transmission Shift Lock Control |
| Auto | Automatic |
| Avg | Average |
| A4WD | Automatic Four-Wheel Drive |
| AWG | American Wire Gage |
| B | |
| B+ | Battery Positive Voltage |
| BARO | Barometric Pressure |
| BATT | Battery |
| BBV | Brake Booster Vacuum |
| BCA | Bias Control Assembly |
| BCM | Body Control Module |
| BHP | Brake Horsepower |
| BLK | Black |
| BLU | Blue |
| BP | Back Pressure |
| BPCM | Battery Pack Control Module |
| BPMV | Brake Pressure Modulator Valve |
| BPP | Brake Pedal Position |
| BRN | Brown |
| BTDC | Before Top Dead Center |
| BTM | Battery Thermal Module |
| BTSI | Brake Transmission Shift Interlock |
| Btu | British Thermal Units |
| C | |
| °C | Degrees Celsius |
| CAC | Charge Air Cooler |
| CAFE | Corporate Average Fuel Economy |
| Cal | Calibration |
| Cam | Camshaft |
| CARB | California Air Resources Board |
| CC | Coast Clutch |
| Cm 3 | Cubic Centimeters |
| CCM | Convenience Charge Module, Chassis Control Module |
| CCOT | Cycling Clutch Orifice Tube |
| CCP | Climate Control Panel |
| CD | Compact Disc |
| CE | Commutator End |
| CEAB | Cold Engine Air Bleed |
| CEMF | Counter Electromotive Force |
| CEX | Cabin Exchanger |
| Cfm | Cubic Feet per Minute |
| Cg | Center of Gravity |
| CID | Cubic Inch Displacement |
| CKP | Crankshaft Position |
| CKT | Circuit |
| C/Ltr | Cigar Lighter |
| CL | Closed Loop |
| CLS | Coolant Level Switch |
| CMC | Compressor Motor Controller |
| CMP | Camshaft Position |
| CNG | Compressed Natural Gas |
| CO | Carbon Monoxide |
| CO2 | Carbon Dioxide |
| Coax | Coaxial |
| COMM | Communication |
| Conn | Connector |
| CPA | Connector Position Assurance |
| CPP | Clutch Pedal Position |
| CPS | Central Power Supply |
| CPU | Central Processing Unit |
| CRT | Cathode Ray Tube |
| CRTC | Cathode Ray Tube Controller |
| CS | Charging System |
| CSFI | Central Sequential Fuel Injection |
| CTP | Closed Throttle Position |
| Cu ft | Cubic Foot/Feet |
| Cu in | Cubic Inch/Inches |
| CV | Constant Velocity Joint |
| CVRSS | Continuously Variable Road Sensing Suspension |
| Cyl | Cylinder(s) |
| D | |
| DAB | Delayed Accessory Bus |
| DB | Decibels |
| DBA | Decibels on A-weighted Scale |
| DC | Direct Current, Duty Cycle |
| DCM | Door Control Module |
| DE | Drive End |
| DEC | Digital Electronic Controller |
| DERM | Diagnostic Energy Reserve Module |
| DI | Distributor Ignition |
| Dia | Diameter |
| DIC | Driver Information Center |
| Diff | Differential |
| DIM | Dash Integration Module |
| DK | Dark |
| DLC | Data Link Connector |
| DMCM | Drive Motor Control Module |
| DMM | Digital Multimeter |
| DMSDS | Drive Motor Speed and Direction Sensor |
| DMU | Drive Motor Unit |
| DOHC | Dual Overhead Camshafts |
| DPM | Driver Position Module |
| DR, Drvr | Driver |
| DRL | Daytime Running Lamps |
| DTC | Diagnostic Trouble Code |
| E | |
| EBCM | Electronic Brake Control Module |
| EBTCM | Electronic Brake and Traction Control Module |
| EC | Electrical Center, Engine Control |
| ECC | Electronic Climate Control |
| ECI | Extended Compressor at Idle |
| ECL | Engine Coolant Level |
| ECM | Engine Control Module, Electronic Control Module |
| ECS | Emission Control System |
| ECT | Engine Coolant Temperature |
| EEPROM | Electrically Erasable Programmable Read Only Memory |
| EEVIR | Evaporator Equalized Values in Receiver |
| EFE | Early Fuel Evaporation |
| EGR | Exhaust Gas Recirculation |
| EGR TVV | Exhaust Gas Recirculation Thermal Vacuum Valve |
| EHPS | Electro-Hydraulic Power Steering |
| EI | Electronic Ignition |
| ELAP | Elapsed |
| ELC | Electronic Level Control |
| E/M | English/Metric |
| EMF | Electromotive Force |
| EMI | Electromagnetic Interference |
| Eng | Engine |
| EOP | Engine Oil Pressure |
| EOT | Engine Oil Temperature |
| EPA | Environmental Protection Agency |
| EPR | Exhaust Pressure Regulator |
| EPROM | Erasable Programmable Read Only Memory |
| ESB | Expansion Spring Brake |
| ESC | Electronic Suspension Control |
| ESD | Electrostatic Discharge |
| ESN | Electronic Serial Number |
| ETC | Electronic Throttle Control, Electronic Temperature Control, Electronic Timing Control |
| ETCC | Electronic Touch Climate Control |
| ETR | Electronically Tuned Receiver |
| ETS | Enhanced Traction System |
| EVAP | Evaporative Emission |
| EVO | Electronic Variable Orifice |
| Exh | Exhaust |
| F | |
| °F | Degrees Fahrenheit |
| FC | Fan Control |
| FDC | Fuel Data Center |
| FED | Federal All United States except California |
| FEDS | Fuel Enable Data Stream |
| FEX | Front Exchanger |
| FF | Flexible Fuel |
| FFH | Fuel-Fired Heater |
| FI | Fuel Injection |
| FMVSS | Federal U.S. Motor Vehicle Safety Standards |
| FP | Fuel Pump |
| Ft | Foot/Feet |
| FT | Fuel Trim |
| F4WD | Full Time Four-Wheel Drive |
| 4WAL | Four-Wheel Antilock |
| 4WD | Four-Wheel Drive |
| FW | Flat Wire |
| FWD | Front Wheel Drive, Forward |
| G | |
| G | Grams, Gravitational Acceleration |
| GA | Gage, Gauge |
| Gal | Gallon |
| Gas | Gasoline |
| GCW | Gross Combination Weight |
| Gen | Generator |
| GL | Gear Lubricant |
| GM | General Motors |
| GM SPO | General Motors Service Parts Operations |
| Gnd | Ground |
| Gpm | Gallons per Minute |
| GRN | Green |
| GRY | Gray |
| GVWR | Gross Vehicle Weight Rating |
| H | |
| H | Hydrogen |
| H2O | Water |
| Harn | Harness |
| HC | Hydrocarbons |
| H/CMPR | High Compression |
| HD | Heavy Duty |
| HDC | Heavy Duty Cooling |
| Hex | Hexagon, Hexadecimal |
| Hg | Mercury |
| Hi Alt | High Altitude |
| HO2S | Heated Oxygen Sensor |
| Hp | Horsepower |
| HPL | High Pressure Liquid |
| HPS | High Performance System |
| HPV | High Pressure Vapor |
| HPVS | Heat Pump Ventilation System |
| Htd | Heated |
| HTR | Heater |
| HUD | Head-up Display |
| HVAC | Heater-Ventilation-Air Conditioning |
| HVACM | Heater-Vent-Air Conditioning Module |
| HVIL | High Voltage Interlock Loop |
| HVM | Heater Vent Module |
| Hz | Hertz |
| I | |
| IAC | Idle Air Control |
| IAT | Intake Air Temperature |
| IC | Integrated Circuit, Ignition Control |
| ICCS | Integrated Chassis Control System |
| ICM | Ignition Control Module |
| ID | Identification, Inside Diameter |
| IDI | Integrated Direct Ignition |
| IGBT | Insulated Gate Bi-Polar Transistor |
| Ign | Ignition |
| ILC | Idle Load Compensator |
| In | Inch/Inches |
| INJ | Injection |
| Inst | Instantaneous, Instant |
| IP | Instrument Panel |
| IPC | Instrument Panel Cluster |
| IPM | Instrument Panel Module |
| I/PEC | Instrument Panel Electrical Center |
| ISC | Idle Speed Control |
| ISO | International Standards Organization |
| ISS | Input Speed Shaft, Input Shaft Speed |
| K | |
| KAM | Keep Alive Memory |
| KDD | Keyboard Display Driver |
| Kg | Kilogram |
| KHz | Kilohertz |
| Km | Kilometer |
| Km/h | Kilometers per Hour |
| Km/l | Kilometers per Liter |
| KPa | Kilopascals |
| KS | Knock Sensor |
| KV | Kilovolts |
| L | |
| L | Liter |
| L4 | Four Cylinder Engine, In-Line |
| L6 | Six-Cylinder Engine, In-Line |
| Lb | Pound |
| Lb ft | Pound Feet Torque |
| Lb in | Pound Inch Torque |
| LCD | Liquid Crystal Display |
| LDCL | Left Door Closed Locking |
| LDCM | Left Door Control Module |
| LDM | Lamp Driver Module |
| LED | Light Emitting Diode |
| LEV | Low Emissions Vehicle |
| LF | Left Front |
| Lm | Lumens |
| LR | Left Rear |
| LT | Left |
| LT | Light |
| LT | Long Term |
| LTPI | Low Tire Pressure Indicator |
| LTPWS | Low Tire Pressure Warning System |
| M | |
| MAF | Mass Air Flow |
| Man | Manual |
| MAP | Manifold Absolute Pressure |
| MAT | Manifold Absolute Temperature |
| Max | Maximum |
| M/C | Mixture Control |
| MDP | Manifold Differential Pressure |
| MFI | Multiport Fuel Injection |
| Mi | Miles |
| MIL | Malfunction Indicator Lamp |
| Min | Minimum |
| MIN | Mobile Identification Number |
| ML | Milliliter |
| Mm | Millimeter |
| Mpg | Miles per Gallon |
| Mph | Miles per Hour |
| Ms | Millisecond |
| MST | Manifold Surface Temperature |
| MSVA | Magnetic Steering Variable Assist, Magnasteer® |
| M/T | Manual Transmission/Transaxle |
| MV | Megavolt |
| MV | Millivolt |
| N | |
| NAES | North American Export Sales |
| NC | Normally Closed |
| NEG | Negative |
| Neu | Neutral |
| NI | Neutral Idle |
| NiMH | Nickel Metal Hydride |
| NLGI | National Lubricating Grease Institute |
| N.m | Newton-meter Torque |
| NO | Normally Open |
| NOx | Oxides of Nitrogen |
| NPTC | National Pipe Thread Coarse |
| NPTF | National Pipe Thread Fine |
| NOVRAM | Non-Volatile Random Access Memory |
| O | |
| O2 | Oxygen |
| O2S | Oxygen Sensor |
| OBD | On-Board Diagnostics |
| OBD II | On-Board Diagnostics Second Generation |
| OC | Oxidation Converter Catalytic |
| OCS | Opportunity Charge Station |
| OD | Outside Diameter |
| ODM | Output Drive Module |
| ODO | Odometer |
| OE | Original Equipment |
| OEM | Original Equipment Manufacturer |
| OHC | Overhead Camshaft |
| Ohms | Ohm |
| OL | Open Loop, Out of Limits |
| ORC | Oxidation Reduction Converter Catalytic |
| ORN | Orange |
| ORVR | On-Board Refueling Vapor Recovery |
| OSS | Output Shaft Speed |
| Oz | Ounce(s) |
| P | |
| PAG | Polyalkylene Glycol |
| PAIR | Pulsed Secondary Air Injection |
| PASS, PSGR | Passenger |
| PASS-Key® | Personalized Automotive Security System |
| P/B | Power Brakes |
| PC | Pressure Control |
| PCB | Printed Circuit Board |
| PCM | Powertrain Control Module |
| PCS | Pressure Control Solenoid |
| PCV | Positive Crankcase Ventilation |
| PEB | Power Electronics Bay |
| PID | Parameter Identification |
| PIM | Power Inverter Module |
| PM | Permanent Magnet Generator |
| P/N | Part Number |
| PNK | Pink |
| PNP | Park/Neutral Position |
| PRNDL | Park, Reverse, Neutral, Drive, Low |
| POA | Pilot Operated Absolute Valve |
| POS | Positive, Position |
| POT | Potentiometer Variable Resistor |
| PPL | Purple |
| Ppm | Parts per Million |
| PROM | Programmable Read Only Memory |
| P/S, PS | Power Steering |
| PSCM | Power Steering Control Module, Passenger Seat Control Module |
| PSD | Power Sliding Door |
| PSP | Power Steering Pressure |
| Psi | Pounds per Square Inch |
| Psia | Pounds per Square Inch Absolute |
| Psig | Pounds per Square Inch Gauge |
| Pt | Pint |
| PTC | Positive Temperature Coefficient |
| PWM | Pulse Width Modulated |
| Q | |
| QDM | Quad Driver Module |
| Qt | Quart(s) |
| R | |
| R-12 | Refrigerant-12 |
| R-134a | Refrigerant-134a |
| RAM | Random Access Memory, Non-permanent memory device, memory contents are lost when power is removed. |
| RAP | Retained Accessory Power |
| RAV | Remote Activation Verification |
| RCDLR | Remote Control Door Lock Receiver |
| RDCM | Right Door Control Module |
| Ref | Reference |
| Rev | Reverse |
| REX | Rear Exchanger |
| RIM | Rear Integration Module |
| RF | Right Front, Radio Frequency |
| RFA | Remote Function Actuation |
| RFI | Radio Frequency Interference |
| RH | Right Hand |
| RKE | Remote Keyless Entry |
| Rly | Relay |
| ROM | Read Only Memory, Permanent memory device, memory contents are retained when power is removed. |
| RPM | Revolutions per Minute Engine Speed |
| RPO | Regular Production Option |
| RR | Right Rear |
| RSS | Road Sensing Suspension |
| RTD | Real Time Damping |
| RT | Right |
| RTV | Room Temperature Vulcanizing Sealer |
| RWAL | Rear Wheel Antilock |
| RWD | Rear Wheel Drive |
| S | |
| S | Second(s) |
| SAE | Society of Automotive Engineers |
| SC | Supercharger |
| SCB | Supercharger Bypass |
| SCM | Seat Control Module |
| SDM | Sensing and Diagnostic Module |
| SEO | Special Equipment Option |
| SFI | Sequential Multiport Fuel Injection |
| SI | System International Modern Version of Metric System |
| SIAB | Side Impact Air Bag |
| SIR | Supplemental Inflatable Restraint |
| SLA | Short/Long Arm Suspension |
| Sol | Solenoid |
| SO2 | Sulfur Dioxide |
| SP | Splice Pack |
| S/P | Series/Parallel |
| SPO | Service Parts Operations |
| SPS | Service Programming System, Speed Signal |
| Sq ft, ft 2 | Square Foot/Feet |
| Sq in, in 2 | Square Inch/Inches |
| SRC | Service Ride Control |
| SRI | Service Reminder Indicator |
| SRS | Supplemental Restraint System |
| SS | Shift Solenoid |
| ST | Scan Tool |
| STID | Station Identification Station ID |
| S4WD | Selectable Four-Wheel Drive |
| Sw | Switch |
| SWPS | Steering Wheel Position Sensor |
| Syn | Synchronizer |
| T | |
| TAC | Throttle Actuator Control |
| Tach | Tachometer |
| TAP | Transmission Adaptive Pressure, Throttle Adaptive Pressure |
| TBI | Throttle Body Fuel Injection |
| TC | Turbocharger, Transmission Control |
| TCC | Torque Converter Clutch |
| TCS | Traction Control System |
| TDC | Top Dead Center |
| TEMP | Temperature |
| Term | Terminal |
| TFP | Transmission Fluid Pressure |
| TFT | Transmission Fluid Temperature |
| THM | Turbo Hydro-Matic |
| TIM | Tire Inflation Monitoring, Tire Inflation Module |
| TOC | Transmission Oil Cooler |
| TP | Throttle Position |
| TPA | Terminal Positive Assurance |
| TPM | Tire Pressure Monitoring, Tire Pressure Monitor |
| TR | Transmission Range |
| TRANS | Transmission/Transaxle |
| TT | Tell Tail Warning Lamp |
| TV | Throttle Valve |
| TVRS | Television and Radio Suppression |
| TVV | Thermal Vacuum Valve |
| TWC | Three Way Converter Catalytic |
| TWC+OC | Three Way + Oxidation Converter Catalytic |
| TXV | Thermal Expansion Valve |
| U | |
| UART | Universal Asynchronous Receiver Transmitter |
| U/H | Underhood |
| U/HEC | Underhood Electrical Center |
| U-joint | Universal Joint |
| UTD | Universal Theft Deterrent |
| UV | Ultraviolet |
| V | |
| V | Volt(s), Voltage |
| V6 | Six-Cylinder Engine, V-Type |
| V8 | Eight-Cylinder Engine, V-Type |
| Vac | Vacuum |
| VAC | Vehicle Access Code |
| VATS | Vehicle Anti-Theft System |
| VCIM | Vehicle Communication Interface Mode |
| VCM | Vehicle Control Module |
| V dif | Voltage Difference |
| VDOT | Variable Displacement Orifice Tube |
| VDV | Vacuum Delay Valve |
| Vel | Velocity |
| VES | Variable Effort Steering |
| VF | Vacuum Fluorescent |
| VIO | Violet |
| VIN | Vehicle Identification Number |
| VLR | Voltage Loop Reserve |
| VMV | Vacuum Modulator Valve |
| VR | Voltage Regulator |
| V ref | Voltage Reference |
| VSES | Vehicle Stability Enhancement System |
| VSS | Vehicle Speed Sensor |
| W | |
| W/ | With |
| W/B | Wheel Base |
| WHL | Wheel |
| WHT | White |
| W/o | Without |
| WOT | Wide Open Throttle |
| W/P | Water Pump |
| W/S | Windshield |
| WSS | Wheel Speed Sensor |
| WU-OC | Warm Up Oxidation Converter Catalytic |
| WU-TWC | Warm Up Three-Way Converter Catalytic |
| X | |
| X-valve | Expansion Valve |
| Y | |
| Yd | Yard(s) |
| YEL | Yellow |
Abbreviations and Meanings
Key Identification and Usage
The keys are double sided and reversible. The master key and the valet key contain transponders that are read by the theft deterrent system when the keys are used in the ignition. The keys have 10 cuts positions (1) with 4 different depths (2).
Scheme 1
The keys that are furnished with the vehicle are
- The master key, that contains a transponder (3). This key will operate all of the locks on the vehicle.
- The valet key, that contains a transponder (3). This key will operate the door locks and the ignition lock only.
- The emergency key, that does not contain a transponder. This key will operate the door locks, and the IP storage compartment lock only. This key is only intended for emergency use.
Lock Cylinder Tumbler Operation
Each of the four cut depths on the key has corresponding tumblers (sometimes referred to as plates or wafers). The tumbler depth number is stamped on the tumblers for identification. The IP storage compartment lock cylinder also requires a retainer tumbler. The retainer tumbler is not moved by the key, its function is to retain the IP storage compartment lock cylinder in the lock assembly.
