Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Assist Step Body Mounting Bolts | 90 N.m | 66 lb ft |
| Assist Step Center Bracket Bolt | 45 N.m | 33 lb ft |
| Body Mounting Bolt | 85 N.m | 63 lb ft |
| Crossmember - Front Engine Bolts | 120 N.m | 88 lb ft |
| Engine Protection Shield to Frame Rail Bolts | 20 N.m | 25 lb ft |
| Frame Brace to Frame Bolts | 50 N.m | 37 lb ft |
| Tow Hook to Frame Rail Bolts | 85 N.m | 63 lb ft |
| Trailer Hitch to Frame Bolts | 125 N.m | 92 lb ft |
| Transmission Mount to Support Bolts | 40 N.m | 30 lb ft |
| Transmission Support to Frame Bolts | 95 N.m | 70 lb ft |
Fastener Tightening Specifications
Three-Dimensional Measurements
Three-dimensional measurements are provided in the absences of dimension information from your equipment supplier. Universal three-dimensional measuring equipment is required to use these numbers. You may need to adjust the height dimensions to match the datum height of your equipment. Only the width dimensions can be used to measure point-to-point. All holes, slots and fasteners are measured to the center.
Scheme 1
| Location | Description | Length | Width | Height |
|---|---|---|---|---|
| 1 | Datum Line | 0 | 0 | 0 |
| 2 | Center Line | 0 | 0 | 0 |
| 3 | Zero Line 17 mm hole | 0 | 522 mm | 382 mm |
| A | 13 mm Tow Hook Hole | 1441 mm | 387 mm | 562 mm |
| B | 32 mm Hole | 1327 mm | 411 mm | 552 mm |
| C | 27 x 18 Slot | 2457 mm | 523 mm | 609 mm |
| D | 20 x 18 Slot | 3887 mm | 496 mm | 773 mm |
| 2WD shown; 4WD dimensions are the same, graphics similar. All dimensions are measured in millimeters, from a zero line, center line, and a common datum. All dimensions are symmetrical, unless otherwise specified. | ||||
Dimensions - Frame (1500 Ext. Cab Short Box 2WD/4WD)
