Front Drive Axle: Component Locations Chevrolet Silverado 3500 HD

Special Tools

1. J 8092 Universal Driver Handle - 3/4 in - 10
2. J 2619-01 Slide Hammer
3. J 29369-1 Bushing and Bearing Remover. See «Special Tools»(ref-317243-S25031904232009060900000) .
4. J 29369-2 Bushing and Bearing Remover (2-3 inch). See «Special Tools»(ref-317243-S25031904232009060900000) .
5. J 36609 Axle Tube Bearing Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .
6. J 45225 Axle Seal Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .

Scheme 83

1. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-317166-S17709202752009060900000) .
2. Drain the differential carrier assembly. Refer to «Front Axle Lubricant Replacement»(ref-317243-S12435610052009060900000) .
3. Remove the right side seal and/or bearing by performing the following steps: Remove the inner axle shaft and housing assembly from the differential carrier case assembly. Refer to «Front Drive Axle Inner Shaft and Inner Shaft Housing Replacement (8.25 F4WD Axle)»(ref-317243-S13841514092009060900000) or «Front Drive Axle Inner Shaft and Inner Shaft Housing Replacement (8.25 S4WD and 9.25 Axles)»(ref-317243-S34216209412009060900000) . Remove the clutch fork assembly components and the inner axle shaft from the inner axle shaft housing. Refer to «Front Drive Axle Inner Shaft and Inner Shaft Housing Replacement (8.25 F4WD Axle)»(ref-317243-S13841514092009060900000) or «Front Drive Axle Inner Shaft and Inner Shaft Housing Replacement (8.25 S4WD and 9.25 Axles)»(ref-317243-S34216209412009060900000) . Install the inner axle shaft housing into a vise. Clamp only on the mounting flange of the inner axle shaft housing. Install the J 29369-1 , 8. See «Special Tools»(ref-317243-S25031904232009060900000) .25 inch axle, or the J 29369-2 , 9. See «Special Tools»(ref-317243-S25031904232009060900000) .25 inch axle, behind the inner axle shaft seal or the inner axle shaft bearing as necessary. Install the J 2619-01 (2) to the J 29369-1 or the J 29369-2 (1). See «Special Tools»(ref-317243-S25031904232009060900000) . Remove the inner axle shaft seal and/or the inner axle shaft bearing using the J 2619-01 .
4. If only replacing the left side seal, perform the following steps: Place an alignment mark between the inner axle shaft and the wheel drive shaft. If servicing the 8.25 inch axle, remove the shock module. Refer to «Shock Absorber and Spring Assembly Replacement»(ref-317187-S32059282162009060900000) . Disconnect the wheel drive shaft from the inner axle shaft. Remove the inner axle shaft using a hammer and a brass drift. Remove the inner axle shaft seal using a suitable seal remover tool.
5. If replacing both the left side seal and bearing, perform the following steps: Remove the differential carrier assembly. Refer to «Differential Carrier Assembly Replacement (1500 FWD)»(ref-317243-S16103732222009060900000) or «Differential Carrier Assembly Replacement (2500 4WD)»(ref-317243-S00981163962009060900000) . Place the differential carrier assembly into a vise. Clamp only on the mounting flange of the differential carrier assembly case. Remove the inner axle shaft using a hammer and a brass drift. Install the J 29369-1 , 8. See «Special Tools»(ref-317243-S25031904232009060900000) .25 inch axle, or the J 29369-2 , 9. See «Special Tools»(ref-317243-S25031904232009060900000) .25 inch axle (1), behind the inner axle shaft seal or the inner axle shaft bearing as necessary. Install the J 2619-01 (2) to the J 29369-1 or the J 29369-2 . See «Special Tools»(ref-317243-S25031904232009060900000) . Remove the inner axle shaft seal and/or the inner axle shaft bearing using the J 2619-01 .

1. J 8614-01 Flange and Pulley Holding Tool. See «Special Tools»(ref-317243-S25031904232009060900000) .
2. J 36366 Pinion Oil Seal Installer

1. J 22888-D Side Bearing Remover Kit. See «Special Tools»(ref-317243-S25031904232009060900000) .
2. J 36597 Side Bearing Puller Pilot - 9. See «Special Tools»(ref-317243-S25031904232009060900000) .25 in Axle

Scheme 84

1. Remove the differential side bearing by performing the following steps: Place the differential case in a vise. Install the J 22888-20A (2) and the J 36597 (1) as shown. See «Special Tools»(ref-317243-S25031904232009060900000) . Remove the differential side bearings using the J 22888-20A .
2. Remove the differential assembly from the vise.
3. Remove the ring gear bolts. Discard the bolts.
4. Remove the ring gear from the differential case. Drive the ring gear off with a brass drift if necessary.
5. Remove the pinion shaft lock bolt.
6. Remove the pinion shaft.
7. Remove the differential side gear spacers.
8. Remove the differential pinion gears and thrust washers by performing the following steps: Drive the pinion gear thrust washers out from the differential case using a hammer and a brass drift. Roll the differential pinion gears out of the differential case. Mark the pinion gears and thrust washers top and bottom.
9. Remove the differential side gears and thrust washers. Mark the differential side gears and thrust washers left and right.

J 22888-D Side Bearing Remover Kit. See Special Tools .

1. J 8092 Universal Driver Handle - 3/4 in - 10
2. J 29710 Differential Side Bearing Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .
3. J 36597 Side Bearing Puller Pilot - 9. See «Special Tools»(ref-317243-S25031904232009060900000) .25 in Axle

1. J 8092 Universal Driver Handle - 3/4 in - 10
2. J 22761 Differential Side Bearing Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .
3. J 22888-D Side Bearing Remover Kit. See «Special Tools»(ref-317243-S25031904232009060900000) .

1. J 36601 Pinion Shim Selector. See «Special Tools»(ref-317243-S25031904232009060900000) .
2. J 29763 Static Timing Gage. See «Special Tools»(ref-317243-S25031904232009060900000) .

1. J 8092 Universal Driver Handle - 3/4 in - 10
2. J 8614-01 Flange and Pulley Holding Tool. See «Special Tools»(ref-317243-S25031904232009060900000) .
3. J 35512 Inner Pinion Bearing Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .
4. J 36366 Pinion Oil Seal Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .
5. J 36599-A Side Bearing Nut Wrench. See «Special Tools»(ref-317243-S25031904232009060900000) .
6. J 36603 Side Bearing Cup Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .
7. J 36609 Axle Tube Bearing Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .
8. J 36612 Output Shaft Bearing Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .
9. J 36614 Inner Pinion Bearing Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .
10. J 36615 Side Bearing Nut Wrench (9. See «Special Tools»(ref-317243-S25031904232009060900000) .25 inch axle)

1. J 8092 Universal Driver Handle-3/4 in 10
2. J 8614-01 Flange and Pulley Holding Tool. See «Special Tools»(ref-317243-S25031904232009060900000) .
3. J 35512 Inner Pinion Bearing Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .
4. J 36366 Pinion Oil Seal Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .
5. J 36599-A Side Bearing Nut Wrench. See «Special Tools»(ref-317243-S25031904232009060900000) .
6. J 36603 Side Bearing Cup Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .
7. J 36609 Axle Tube Bearing Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .
8. J 36612 Output Shaft Bearing Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .
9. J 36614 Pinion Bearing Installer. See «Special Tools»(ref-317243-S25031904232009060900000) .
10. J 36615 Side Bearing Nut Wrench. See «Special Tools»(ref-317243-S25031904232009060900000) .
11. J 36616 Adjuster Nut Wrench. See «Special Tools»(ref-317243-S25031904232009060900000) .

1. J 8092: Universal Driver Handle - 3/4 in - 10
2. J 33842: Output Pilot Bearing Installer
3. J 36609: Axle Tube Bearing Installer
4. J 36616: Axle Mount Bushing Remover/installer
5. J 45225: Axle Seal Installer

1. J 8092: Universal Driver Handle - 3/4 in - 10
2. J 33791: Carrier Bushing Remover/Installer
3. J 36609: Axle Tube Bearing Installer
4. J 36616: Axle Mount Bushing Remover/Installer
5. J 45225: Axle Seal Installer

Illustration Tool Number/Description J 2619-01 Slide Hammer J 8001 Dial Indicator Set J 8092 Driver Handle J 8614-01 Flange and Pulley Holding Tool J 22761 Differential Side Bearing Installer J 22888-D Side Bearing Remover Kit J 22912-01 Rear Pinion and Axle Bearing Remover J 29369-1 Bushing and Bearing Remover J 29369-2 Bushing and Bearing Remover - 2-3 in J 29710 Differential Side Bearing Installer J 29763 Static Timing Gage J 33791 Carrier Bushing Remover/Installer J 33842 Pilot Bearing Installer J 34011 Pilot Bearing Remover J 34672 Depth Micrometer J 34673 Flat Gage Bar J 35512 Inner Pinion Bearing Installer J 36366 Pinion Oil Seal Installer J 36597 Side Bearing Puller Pilot - 9.25 Inch Axle J 36598 Holding Fixture J 36599-A Side Bearing Nut Wrench J 36601 Pinion Shim Selector J 36603 Side Bearing Cup Installer J 36609 Axle Tube Bearing Installer J 36612 Output Shaft Bearing Installer J 36614 Inner Pinion Bearing Installer J 36615 Side Bearing Nut Wrench J 36616 Axle Mount Bushing Remover/Installer J 45225 Axle Seal Installer J 45754 Pinion Bearing Race Remover/Installer - 9.25 Inch Axle J 45765 Pinion Remover - 8.25 inch/9.25 inch Axles J 45858 Pinion Bearing Race Remover/Installer - 8.25 Inch Axle
