Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Accelerator Actuator Screws | 2.5 N.m | 22 lb in |
| Accelerator Pedal Bracket Nuts | 9 N.m | 80 lb in |
| Adjustable Pedal Bracket Nuts | 36 N.m | 27 lb ft |
| Adjustable Pedal Bracket to Dash Panel Bolt | 36 N.m | 27 lb ft |
| Brake and Accelerator Pedal Position Sensor Bolts | 2 N.m | 18 lb in |
| Brake Pedal Pushrod Retainer Bolt | 10 N.m | 89 lb in |
| Master Cylinder Nuts - With JL4 | 32 N.m | 24 lb ft |
| Master Cylinder Nuts - Without JL4 | 25 N.m | 18 lb ft |
| Transmission Range Selector Cable Support Bolt | 10 N.m | 89 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 2
