Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Front Pump Mounting Bolts | 50 N.m | 37 lb ft |
| Gear To Frame Bolts (Non-Rack and Pinion) | 135 N.m | 100 lb ft |
| Gear To Frame Bolts (Rack and Pinion) | 185 N.m | 136 lb ft |
| Inner Tie Rod to Steering Gear | 100 N.m | 74 lb ft |
| Intermediate Shaft Coupling Pinch Bolt | 45 N.m | 33 lb ft |
| Outer Tie Rod to the Steering Knuckle | 50 N.m | 37 lb ft |
| Power Steering Cooler Mounting Bolts | 9 N.m | 7 lb ft |
| Pressure Hose Connection (At Gear) | 33 N.m | 24 lb ft |
| Pressure Hose Connection (At Pump) | 28 N.m | 20 lb ft |
| Rack and Pinion Ground Strap Retaining Bolt | 10 N.m | 89 lb in |
| Rear Pump Mounting Bolt | 50 N.m | 37 lb ft |
| Side Cover Bolts | 60 N.m | 45 lb ft |
| Tie Rod Jam Nut | 68 N.m | 50 lb ft |
Fastener Tightening Specifications
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Begin the system diagnosis by reviewing the system Description and Operation. See DESCRIPTION & OPERATION . Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to Symptoms - Power Steering System in order to identify the correct procedure for diagnosing the system and where the procedure is located.
Important: Review the system description and operation in order to familiarize yourself with the system functions. Refer to Power Steering System Description & Operation .
