Data Link Communication System: Overview Chevrolet Silverado 2500

Communication Devices 7 illustrations ~512 words

The numbers below refer to the step numbers on the diagnostic table.

  1. 1) - A DTC U1001 - U1254 "Lost Communications with XXX" with a history status may indicate the cause of U1000 or U1255.
  2. 2) - The modules not communicating are the likely cause of U1000 or U1255. The modules that are available on the class 2 serial data circuit are listed in the Circuit Description.
  3. 7) - The module which was not communicating due to a poor connection to the class 2 serial data circuit may have set DTC U1001 - U1254 "Lost Communications with XXX" for those modules that it was monitoring.
  4. 9) - The modules which can communicate indicate the module which cannot communicate. You must clear the serial data communication DTCs from these modules to avoid future misdiagnosis.
  5. 12) - If all modules are communicating, the module which set U1000 or U1255 may have done so due to some other condition.
  6. 14) - The module which set U1000 or U1255 is the likely cause of the malfunction.

The number below refers to the step numbers on the diagnostic table.

  1. 6) - The module which was not communicating on the class 2 serial data circuit may have set Loss of Communicating DTCs for those modules that it was monitoring.
Scheme 1
Scheme 2

The number below refers to the step number on the diagnostic table.

  1. 4) - If the battery positive voltage and ground circuits of the DLC are functioning properly. The malfunction must be due to the scan tool.
Scheme 3

The numbers below refer to the step numbers on the diagnostic table.

  1. 2) - A partial loss of communication in the class 2 serial data circuit uses a different procedure than a total loss of communication of the class 2 serial data circuit.
  2. 4) - The following DTCs may be retrieved with a history status. The DTCs are not the cause of the present condition. U1300 U1301 U1305
  3. 6) - A State of Health DTC with a history status may be present along with a U1000 or U1255 with a current status. This indicates that the malfunction occurred when the ignition was on.
  4. 10) - Normal class 2 serial data communication cannot take place until the body control module (BCM) sends the appropriate power mode message. If the BCM does not send a wake-up message, other modules on the class 2 serial data circuit may not communicate.
  5. 12) - Normal class 2 serial data communication cannot take place until the body control module (BCM) sends the appropriate power mode message. If the BCM does not send a wake-up message, other modules on the class 2 serial data circuit may not communication.
  6. 17) - If there are no current DTCs that begin with the letter "U", the communication concern has been repaired.
  7. 18) - The communication concern may have prevented diagnostic of the customer complaint.
Scheme 4
Scheme 5
Scheme 6
Scheme 7: Removal Procedure
  1. Remove the bolt from the data link connector.
  2. Remove the data link connector from the instrument panel.
