HVAC Systems - Automatic: Specifications Chevrolet Silverado 2500

Automatic HVAC System 4 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Air Temperature Actuator Mounting Screw1.6 N.m14 lb in
Blower Motor Control Processor Screws1.6 N.m14 lb in
HVAC Control Module Screws1.9 N.m17 lb in
Mode Actuator Mounting Screw1.6 N.m14 lb in
Recirculation Actuator Mounting Screw1.6 N.m14 lb in

Fastener Tightening Specifications

Scheme 102

Scheme 102: Sensor Resistance Table (Ambient & Inside Air Temp - Ohms)
Scheme 102: Sensor Resistance Table (Ambient & Inside Air Temp - Ohms)

Scheme 103

Scheme 103
Scheme 103

Scheme 104

Scheme 104: Sensor Resistance (Upper, Lower & Aux. Air Temp - Ohms)
Scheme 104: Sensor Resistance (Upper, Lower & Aux. Air Temp - Ohms)

Scheme 105

Scheme 105
Scheme 105
