TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Seat mounting nuts | 41 (56) | |
| Steering wheel nut | 30 (41) | |
| INCH Lbs. (N.m) | ||
| Electronic Frontal Sensor (EFS) mounting bolt | 89 (10.0) | |
| Front end discriminating sensor mounting bolt | 89 (10.0) | |
| Instrument panel upper trim pad screws | 18 (2.0) | |
| Instrument Panel Cluster (IPC) retaining screws | 18 (2.0) | |
| Passenger-side air bag module bolts | 89 (10.0) | |
| Sensing & Diagnostic Module (SDM) mounting nuts | 89 (10.0) | |
| Steering column cover | ||
| Upper Torx screw | 13 (1.5) | |
| Lower rear screw | 31 (3.5) | |
| Lower front screw | 18 (2.0) | |
