Fastener Tightening Specifications
| Application | Specifications |
|---|
| Metric | English |
| Sunroof Actuator to Bracket Screws | 3 N.m | 27 lb in |
| Sunroof Air Deflector Screws | 3 N.m | 27 lb in |
| Sunroof Module | 10 N.m | 89 lb in |
| Sunroof Water Tray to Sunroof Module Screws | 1 N.m | 9 lb in |
| Sunroof Window to Module Screws | 3 N.m | 27 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Sunroof Schematics
Scheme 2
Scheme 2: Sunroof Component Views
| Callout | Component Name |
|---|
| 1 | Inside Air Temperature Sensor - Front (CJ2) |
| 2 | Cellular Microphone (UE1/U3U/UVB) |
| 3 | Courtesy/Reading Lamps - Rear (Extended Cab/Crew Cab) |
| 4 | Sunroof Switch (CF5) |
| 5 | Sunshade - Right (DH6) |
| 6 | Garage Door Opener (UG1) |
| 7 | Onstar Button Assembly |
| 8 | Inside Rearview Mirror (ISRVM) |
| 9 | Courtesy/Reading Lamps - Front |
| 10 | Windshield |
| 11 | Sunshade - Left (DH6) |
Scheme 3
| Callout | Component Name |
|---|
| 1 | Sunroof Module |
| 2 | Left Outer Frame Panel |
Scheme 4
| Connector Part Information OEM: 7283-5909-40 Service: See Catalog Description: 10-Way F 1.5 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: See Catalog Core/Insulation Crimp: See Catalog Release Tool/Test Probe: See Catalog |
Sunroof Module Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 2 BK | 1050 | Ground |
| 2 | | | Not Used |
| 3 | 0.35 YE | 43 | Accessory Voltage |
| 4 | 0.35 D-GN | 2074 | Sunroof Switch Express Signal |
| 5 | 0.35 BN | 100 | Sunroof Switch Open Signal |
| 6 | 2 RD/WH | 3140 | Battery Positive Voltage |
| 7 | | | Not Used |
| 8 | 0.35 PK | 2075 | Sunroof Switch Close Vent Signal (Crew Cab) |
| 9 | 0.35 OG | 144 | Sunroof Switch Open Vent Signal (Crew Cab) |
| 10 | 0.35 OG | 110 | Sunroof Switch Close Signal |
Sunroof Module Connector Terminal Identification
Scheme 5
| Connector Part Information OEM: 12103492 Service: 89046705 Description: 8-Way F 0.64 Series Unsealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: See Catalog Core/Insulation Crimp: See Catalog Release Tool/Test Probe: See Catalog |
Sunroof Switch Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 0.35 D-GN | 2074 | Sunroof Switch Express Signal |
| 2 | 0.35 OG | 144 | Sunroof Switch Open Vent Signal (Crew Cab) |
| 3 | 0.35 BN/WH | 230 | Instrument Panel Lamps Dimming Control |
| 4 | 0.35 OG | 110 | Sunroof Switch Close Signal |
| 5 | 0.35 BK | 1050 | Ground |
| 6 | 0.35 BN | 100 | Sunroof Switch Open Signal |
| 7 | | | Not Used |
| 8 | 0.35 PK | 2075 | Sunroof Switch Close Vent Signal (Crew Cab) |
Sunroof Switch Connector Terminal Identification
