Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Seat Belt Anchor Plate Bolts | 70 N.m | 52 lb ft |
| Seat Belt Assembly Bolts | 52 N.m | 38 lb ft |
| Seat Belt Assembly Nuts | 52 N.m | 38 lb ft |
| Seat Belt Bracket Screws | 2 N.m | 18 lb in |
| Seat Belt Guide Adjuster Bolts | 50 N.m | 37 lb ft |
| Seat Belt Retractor Assembly Bolts | 43 N.m | 32 lb ft |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Seat Belt Schematics
Scheme 2
Scheme 2: Seat Belt Component Views
| Callout | Component Name |
|---|
| 1 | Seat Recline Motor - Driver (AN3) |
| 2 | Seat Lumbar Vertical Motor Position Sensor - Driver (AN3) |
| 3 | Seat Lumbar Vertical Motor - Driver (AN3) |
| 4 | X324 (AN3) |
| 5 | Seat Lumbar Horizontal Motor - Driver (AN3) |
| 6 | Seat Lumbar Horizontal Motor Position Sensor - Driver (AN3) |
| 7 | Seat Recline Position Sensor - Driver (AN3) |
| 8 | Seat Lumbar Switch - Driver (AN3) |
| 9 | Seat Adjuster Switch - Driver |
| 10 | Memory Seat Module (AN3) |
| 11 | Inflatable Restraint Seat Position Sensor (SPS) - Left (10 Series) |
| 12 | Seat Adjuster Assembly - Driver |
| 13 | Seat Belt Buckle - Driver |
Scheme 3
| Callout | Component Name |
|---|
| 1 | Seat Frame |
| 2 | X325 (AN3) |
| 3 | Seat Lumbar Vertical Motor - Passenger (AN3) |
| 4 | Seat Adjuster Switch - Passenger |
| 5 | Seat Lumbar Switch - Passenger (AN3) |
| 6 | Seat Belt Buckle - Passenger |
| 7 | Inflatable Restraint Passenger Presence System (PPS) Module (AL0) |
| 8 | Seat Adjuster Assembly - Passenger |
| 9 | Inflatable Restraint Passenger Presence System (PPS) Sensor (AL0) |
| 10 | Seat Recline Motor - Passenger (AN3) |
| 11 | Seat Lumbar Horizontal Motor - Passenger (AN3) |
Scheme 4
Scheme 4: Seat Belt Buckle - Driver
| Connector Part Information OEM: 12052833 Service: 12117275 Description: 2-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 1204758/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY) |
Seat Belt Buckle - Driver Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.35 TN/WH | 238 | Driver Seat Belt Switch Signal |
| B | 0.35 PK | 5057 | Low Reference |
Seat Belt Buckle - Driver Connector Terminal Identification
