Keyless Entry System and Remote Functions: Specifications Chevrolet Silverado 2500 HD

Door Locks & Anti-Theft Systems 6 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Garage Door Opener Transmitter Screws2 N.m18 lb in

Fastener Tightening Specifications

Scheme 40

Scheme 40: Remote Function Schematics
Scheme 40: Remote Function Schematics

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42: Remote Function Component Views
Scheme 42: Remote Function Component Views
CalloutComponent Name
1Inside Air Temperature Sensor - Front (CJ2)
2Cellular Microphone (UE1/U3U/UVB)
3Courtesy/Reading Lamps - Rear (Extended Cab/Crew Cab)
4Sunroof Switch (CF5)
5Sunshade - Right (DH6)
6Garage Door Opener (UG1)
7Onstar Button Assembly
8Inside Rearview Mirror (ISRVM)
9Courtesy/Reading Lamps - Front
10Windshield
11Sunshade - Left (DH6)

Scheme 43

Scheme 43
Scheme 43
CalloutComponent Name
1Rear Window
2Remote Control Door Lock Receiver (RCDLR) (AP3/AP8)

Scheme 44

Scheme 44: Garage Door Opener (UG1)
Scheme 44: Garage Door Opener (UG1)
Connector Part Information OEM: 12162335 Service: See Catalog Description: 3-Way F P/C Series, Unsealed (NA)
Terminal Part Information Terminal/Tray: 08-50-0115/20 Core/Insulation Crimp: E/C Release Tool/Test Probe: J-38125-213/J-35616-4A (PU)

Garage Door Opener (UG1) Connector Parts Information

PinWire ColorCircuit No.Function
10.5 RD/WH240Battery Positive Voltage
20.35 BN/WH230Instrument Panel Lamps Dimming Control
30.5 BK1050Ground

Garage Door Opener (UG1) Connector Terminal Identification

Scheme 45

Scheme 45: Remote Control Door Lock Receiver (RCDLR)
Scheme 45: Remote Control Door Lock Receiver (RCDLR)
Connector Part Information OEM: 15462684 Service: 88988745 Description: 4-Way F ILAG5 Series (GN)
Terminal Part Information Terminal/Tray: IL-AG5-C1-5000 /20 Core/Insulation Crimp: K/K Release Tool/Test Probe: J-38125-211/J-35616-64B (L-BU)

Remote Control Door Lock Receiver (RCDLR) Connector Parts Information

PinWire ColorCircuit No.Function
10.35 RD/WH1140Battery Positive Voltage (AN3)
0.8 RD/WH1140Battery Positive Voltage (-AN3)
20.35 D-GN5060Low Speed GMLAN Serial Data
3Not Used
40.35 BK/WH2751Ground

Remote Control Door Lock Receiver (RCDLR) Connector Terminal Identification
