Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Air Cleaner Outlet Duct Clamp | 4 N.m | 35 lb in |
| Coolant Air Bleed Pipe Bolts | 12 N.m | 9 lb ft |
| Coolant Heater | 50 N.m | 37 lb ft |
| Coolant Heater Cord Bolt | 8 N.m | 71 lb in |
| Cooling Fan Motor Bolts | 10 N.m | 89 lb in |
| Cooling Fan Shroud Bolts | 9 N.m | 80 lb in |
| Differential Carrier Bolts | 100 N.m | 74 lb ft |
| Fan Clutch Bolts | 23 N.m | 17 lb ft |
| Fan Clutch Bolts | 56 N.m | 41 lb ft |
| Oil Cooler Hose Adapter Bolt | 12 N.m | 106 lb in |
| Oil Cooler Hose Bracket Bolt | 25 N.m | 18 lb ft |
| Oil Pan Skid Plate Bolts | 20 N.m | 15 lb ft |
| Radiator Bolt | 25 N.m | 18 lb ft |
| Surge Tank Bolt/Nut | 10 N.m | 89 lb in |
| TCM Cover Bolts | 9 N.m | 80 lb in |
| TCM Electrical Connector Bolts | 8 N.m | 71 lb in |
| Transmission Cooling Line Bolts | 4 N.m | 35 lb in |
| Water Pump |
| First Pass | 15 N.m | 11 lb ft |
| Final Pass | 30 N.m | 22 lb ft |
| Water Pump Inlet Bolt | 15 N.m | 11 lb ft |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Engine Cooling Schematics
Scheme 2
Scheme 3
Scheme 3: Cooling System Component Views
| Callout | Component Name |
|---|
| 1 | Cooling Fan - Left |
| 2 | Cooling Fan - Right |
| 3 | Forward Lamp Harness |
Scheme 4
| Callout | Component Name |
|---|
| 1 | Engine |
| 2 | Front Fascia |
| 3 | A/C Low Pressure Switch (C67/CJ2) |
| 4 | Surge Tank |
| 5 | Engine Coolant Level Switch |
Scheme 5
Scheme 5: Cooling Fan - Left (Gas)
| Connector Part Information OEM: 15454358 Service: 88987983 Description: 2-Way F 630 GT (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15476168/5 Core/Insulation Crimp: F/3 Release Tool/Test Probe: 15315247/J-35616-42 (RD) |
Cooling Fan - Left (Gas) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 5 YE | 5358 | Auxiliary Cooling Fan Motor Supply Voltage |
| B | 5 L-BU | 409 | Cooling Fan Motor Supply Voltage |
Cooling Fan - Left (Gas) Connector Terminal Identification
