Engine Exhaust System Chevrolet Silverado 1500

Exhaust 1 illustration ~10496 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Catalytic Converter to Exhaust Manifold Nut (4.3L, 4.8L, 5.3L, 6.0L, 6.2L)50 N.m37 lb ft
Catalytic Converter to Muffler Nut (4.3L, 4.8L, 5.3L, 6.0L, 6.2L)45 N.m33 lb ft
Catalytic Converter to Particulate Filter Nut (6.6L)45 N.m33 lb ft
Exhaust Gas Recirculation (EGR) Cooler Pipe Bracket Upper Bolt (6.6L)9 N.m80 lb in
Exhaust Gas Recirculation (EGR) Cooler Pipe Lower Bolt (6.6L)9 N.m80 lb in
Exhaust Heat Shield Nut9 N.m80 lb in
Exhaust Manifold Bolts (4.8L, 5.3L, 6.0L, 6.2L)
First Pass15 N.m11 lb ft
Final Pass25 N.m18 lb ft
Exhaust Manifold Bolt/Nut (6.6L)
First Pass57 N.m42 lb ft
4 Center Bolts an Additional Pass57 N.m42 lb ft
Exhaust Manifold Bolt/Stud (4.3L)30 N.m22 lb ft
Exhaust Manifold Heat Shield Bolt (4.3L, 4.8L, 5.3L, 6.0L, 6.2L)9 N.m80 lb in
Exhaust Manifold Heat Shield Bolt (6.6L)10 N.m89 lb in
Exhaust Manifold Pipe to Exhaust Manifold Nut (6.0L)50 N.m37 lb ft
Exhaust Muffler Clamp (6.0L)47 N.m35 lb ft
Exhaust Muffler to Exhaust Manifold Pipe Nut (6.0L)45 N.m33 lb ft
Exhaust Muffler to Exhaust Particulate Filter Nut (6.6L)45 N.m33 lb ft
Exhaust Pipe Bolt (6.6L)53 N.m39 lb ft
Exhaust Pipe Hanger Bracket Bolt (6.0L, 6.6L)25 N.m18 lb ft
Exhaust Pipe Heat Shield Bolt (6.6L)10 N.m89 lb in
Heated Oxygen Sensor (HO2S) (4.3L, 4.8L, 5.3L, 6.0L, 6.2L)42 N.m31 lb ft
Muffler to Catalytic Converter Nut (4.3L, 4.8L, 5.3L, 6.0L, 6.2L)45 N.m33 lb ft
Oil Level Indicator Tube Bolt (4.8L, 5.3L, 6.0L, 6.2L)25 N.m18 lb ft
Oil Level Indicator Tube Bolt (6.6L)21 N.m15 lb ft
Oil Pan Skid Plate Bolt28 N.m21 lb ft
Rear Shock Absorber Lower Bolt (6.0L, 6.2L, 6.6L)95 N.m70 lb ft
Steering Shaft Coupling Bolt/Nut (4.8L, 5.3L, 6.0L, 6.2L)50 N.m37 lb ft
Transmission Fluid Fill Tube Nut (6.6L)18 N.m13 lb ft
Transmission Mount to Support Nut (6.0L, 6.6L)40 N.m30 lb ft
Transmission Support Crossmember Bolt (6.0L, 6.6L)95 N.m70 lb ft
Turbocharger Exhaust Pipe to Bracket Bolt (6.6L)34 N.m25 lb ft
Turbocharger Exhaust Pipe to Catalytic Converter Clamp (6.6L)12 N.m106 lb in
Turbocharger Exhaust Pipe Heat Shield Bolt (6.6L)10 N.m89 lb in
Turbocharger Exhaust Pipe to Turbocharger Clamp Bolt (6.6L)15 N.m11 lb ft
Turbocharger Upper Heat Shield Bolt (6.6L)10 N.m89 lb in

Fastener Tightening Specifications

Diagnostic Starting Point - Engine Exhaust

Begin the system diagnosis by reviewing the system Description and Operation. Reviewing the information will help you determine the correct symptom diagnostic procedure when a malfunction exists. It will also help you determine if the condition described by the customer is normal operation. Refer to Symptoms - Engine Exhaust in order to identify the correct procedure for diagnosing the system.

Symptoms - Engine Exhaust

  1. Review the Exhaust System Description and Operation in order to familiarize yourself with the system functions. Refer to «Exhaust System Description»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system__exhaust-system-description) .
  2. All diagnostics on a vehicle should follow a logical process. Strategy Based Diagnostics is a uniform approach for repairing all systems. The diagnostic flow is the place to start when repairs are necessary and may always be used in order to resolve a system problem. For a detailed explanation, refer to «Strategy Based Diagnosis»(/chevrolet/silverado-1500/2007-2007/remont/hoistjack/#general-information__strategy-based-diagnosis) .

Visual/Physical Inspection

  1. Inspect for aftermarket or non-OEM devices such as, but not limited too; tailpipe extensions, headers, and exhaust cutouts. This could affect the operation and proper performance of the exhaust system.
  2. Verify the exact operating conditions under which the concern exists. Note factors such as engine RPM, engine temperature, engine load, and frequency of concern.
  3. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause any symptom.

Intermittent

Test the vehicle under the same conditions that the customer reported in order to verify the system is operating as designed.

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

  1. Loss of power. Refer to «Restricted Exhaust»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  2. Poor acceleration. Refer to «Restricted Exhaust»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  3. Poor fuel economy. Refer to «Restricted Exhaust»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  4. Exhaust hissing noise. Refer to «Exhaust Leakage»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system__exhaust-leakage) .
  5. Exhaust popping noise. Refer to «Exhaust Leakage»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system__exhaust-leakage) .
  6. Exhaust rattle noise. Refer to «Exhaust Noise»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system__exhaust-noise) .
  7. Loud exhaust noise. Refer to «Exhaust Noise»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system__exhaust-noise) .
  8. Exhaust buzz, groan, hum noise. Refer to «Exhaust Noise»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system__exhaust-noise) .

Diagnostic Aids

CAUTIONWhile engine is operating, the exhaust system will become extremely hot. To prevent burns avoid contacting a hot exhaust system.
IMPORTANTDo not replace a restricted particulate filter. Repair the engine condition that clogged the particulate filter, and then attempt to perform a service regeneration. Refer to Exhaust Particulate Filter Cleaning (DPF Service Regeneration) or Exhaust Particulate Filter Cleaning (DPF Regeneration Enable) .

If the vehicle is equipped with a 6.6 L diesel engine do not perform this diagnostic. The exhaust system does not have a location for installing the J 35314-A Exhaust Back Pressure Gage. See Special Tools . Instead remove the suspect component, operate the vehicle, verify for improved performance. If performance is improved then replace the faulty component.

Test Description

The numbers below refer to the step numbers on the diagnostic table.

  1. 4: The exhaust system has very low back pressure under normal conditions. If the exhaust system is restricted, a significant increase in the exhaust pressure is noticed on the J 35314-A . See «Special Tools»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system__special-tools) .Removing the heated oxygen sensor (HO2S) sensor may set a DTC. When finishing this diagnostic table, be sure to clear all codes.
  2. 5: This step will isolate the catalytic converter from the remainder of the exhaust system.
  3. 8: Confirming that the condition has been fixed is essential. If the symptom still exists and the vehicle has a dual exhaust system, proceed to Step 2 and repeat diagnostic procedure on the opposite exhaust pipe.
StepActionValue(s)YesNo
1Did you verify the customers complaint?Go to Step 2
2Did you review the exhaust symptoms diagnostic information and perform the necessary inspections?Go to Step 3Go to Symptoms - Engine Exhaust
3Is the vehicle equipped with a 6.6L diesel engine?Go to Diagnostic AidsGo to Step 4
4Remove the HO2S that is in front of and closest to the catalytic converter. Refer to Heated Oxygen Sensor Replacement - Bank 1 Sensor 1 or Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 for the 4.3L engine, or to Heated Oxygen Sensor Replacement - Bank 1 Sensor 1 (1500 Series) or Heated Oxygen Sensor Replacement - Bank 1 Sensor 1 (2500 Series) or Heated Oxygen Sensor Replacement - Bank 1 Sensor 1 (2500 Series - Cab/Chassis) or Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (1500 Series) or Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series) or Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series - Cab/Chassis) for the 4.8L, 5.3L, 6.0L, and 6.2L engines. Install the J 35314-A Exhaust Back Pressure Gage in place of the HO2S. See Special Tools . Start the engine. Increase and monitor the engine speed at 2,000 RPM. Observe the exhaust system back pressure reading on the gage. Does the reading exceed the specified value?20 kPa (3 psi) If equipped with a 4.8L, 5.3L, 6.0L, or 6.2L - 3.4 kPa (0.5 psi)Go to Step 5Go to Step 8
5Turn the engine off and place the ignition in the lock position. Remove the J 35314-A . See Special Tools . Re-install the HO2S. Refer to Heated Oxygen Sensor Replacement - Bank 1 Sensor 1 or Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 for the 4.3L engine, or to Heated Oxygen Sensor Replacement - Bank 1 Sensor 1 (1500 Series) or Heated Oxygen Sensor Replacement - Bank 1 Sensor 1 (2500 Series) or Heated Oxygen Sensor Replacement - Bank 1 Sensor 1 (2500 Series - Cab/Chassis) or Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (1500 Series) or Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series) or Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series - Cab/Chassis) for the 4.8L, 5.3L, 6.0L, and 6.2L engines. Remove the post-catalyst HO2S. Refer to Heated Oxygen Sensor Replacement - Bank 1 Sensor 2 or Heated Oxygen Sensor Replacement - Bank 2 Sensor 2 for the 4.3L engine, or to Heated Oxygen Sensor Replacement - Bank 1 Sensor 2 (1500 Series) or Heated Oxygen Sensor Replacement - Bank 1 Sensor 2 (2500 Series) or Heated Oxygen Sensor Replacement - Bank 1 Sensor 2 (2500 Series - Cab/Chassis) or Heated Oxygen Sensor Replacement - Bank 2 Sensor 2 (1500 Series) or Heated Oxygen Sensor Replacement - Bank 2 Sensor 2 (2500 Series) or Heated Oxygen Sensor Replacement - Bank 2 Sensor 2 (2500 Series - Cab/Chassis) for the 4.8L, 5.3L, 6.0L, and 6.2L engines. Install the J 35314-A in place of the post HO2S. See Special Tools . Start the engine. Increase and monitor the engine speed at 2,000 RPM. Observe the exhaust system back pressure reading on the gage. Does the reading exceed the specified value?20 kPa (3 psi) If equipped with a 4.8L, 5.3L, 6.0L, or 6.2L - 3.4 kPa (0.5 psi)Go to Step 6Go to Step 7
6Inspect the exhaust system for the following conditions: Damage in the exhaust pipe Debris in the exhaust pipe Muffler or resonator internal failure Two-layer exhaust pipe separation Did you find and correct the condition?Go to Step 8
7Replace the catalytic converter. Refer to Catalytic Converter Replacement (4.3L) or Catalytic Converter Replacement (4.8L, 5.3L, 6.0L, 6.2L) or Catalytic Converter Replacement (6.6L) or Catalytic Converter Replacement - Left Side (6.0L - Cab/Chassis) . Did you find and correct the condition?Go to Step 8
8Remove the J 35314-A . See Special Tools . Reinstall the HO2S. Refer to Heated Oxygen Sensor Replacement - Bank 1 Sensor 2 or Heated Oxygen Sensor Replacement - Bank 2 Sensor 2 for the 4.3L engine, or to Heated Oxygen Sensor Replacement - Bank 1 Sensor 2 (1500 Series) or Heated Oxygen Sensor Replacement - Bank 1 Sensor 2 (2500 Series) or Heated Oxygen Sensor Replacement - Bank 1 Sensor 2 (2500 Series - Cab/Chassis) or Heated Oxygen Sensor Replacement - Bank 2 Sensor 2 (1500 Series) or Heated Oxygen Sensor Replacement - Bank 2 Sensor 2 (2500 Series) or Heated Oxygen Sensor Replacement - Bank 2 Sensor 2 (2500 Series - Cab/Chassis) for the 4.8L, 5.3L, 6.0L, and 6.2L engines. Clear any codes. Road test the vehicle in order to verify the repair. Did you correct the condition?System OKGo to Step 2

Restricted Exhaust

Exhaust Leakage

ProblemAction
CAUTION: While engine is operating, the exhaust system will become extremely hot. To prevent burns avoid contacting a hot exhaust system. DEFINITION: An exhaust leak may show stains at the area of the leak. The leak may be felt by holding a hand close to the suspected areas or using a smoke pencil. The leak may make a popping or hissing noise.Refer to Symptoms - Engine Exhaust prior to beginning this table.
Misaligned or improperly installed exhaust system components.Align and tighten the components to the specifications. Refer to Fastener Tightening Specifications . Ensure the exhaust hangers are in the proper locations and not loose.
Exhaust leaks at the following connections: Exhaust manifold to pipe Flanges Pipe clampsTighten the components to the specifications. Refer to Fastener Tightening Specifications .
Seals or gaskets leaking. Exhaust manifold to cylinder head Exhaust pipes to exhaust manifold Catalytic converter connection EGR connections, if equippedReplace the leaking seal or gasket. Refer to the affected components procedure for service.
Irregularities at the mating surfaces on the flange connections.Repair as required or replace the affected component. Refer to the affected components procedure for service.
Exhaust manifold cracked or broken.Replace the exhaust manifold. Refer to: Exhaust Manifold Replacement - Left Side (4.3L) or Exhaust Manifold Replacement - Left Side (4.8L, 5.3L, 6.0L, and 6.2L) or Exhaust Manifold Replacement - Left Side (6.6L) Exhaust Manifold Replacement - Right Side (4.3L) or Exhaust Manifold Replacement - Right Side (4.8L, 5.3L, 6.0L, and 6.2L) or Exhaust Manifold Replacement - Right Side (6.6L) .
Exhaust system component connection welds leaking.Replace the leaking component. Refer to the affected component's procedure for service.
Muffler damaged or leaking at the seams.Replace the affected muffler. Refer to Muffler Replacement (1500 Series w/4.3L, 4.8L, 5.3L, 6.0L) or Muffler Replacement (1500 Series w/6.2L) or Muffler Replacement (2500/3500 Series w/6.0L) or Muffler Replacement (2500/3500 - Cab/Chassis w/6.0L) or Muffler Replacement (6.6L) .
CAUTION
While engine is operating, the exhaust system will become extremely hot. To prevent burns avoid contacting a hot exhaust system.

Exhaust Leakage

Exhaust Noise

ConditionAction
CAUTION: While engine is operating, the exhaust system will become extremely hot. To prevent burns avoid contacting a hot exhaust system. DEFINITION: An audible or physical noise due to a faulty component or damaged components causing a loose or misaligned exhaust system resulting in a rattle or vibration noise (buzz, groan, hum).Refer to Symptoms - Engine Exhaust prior to beginning this table.
Popping or hissing noiseExhaust leak. Refer to Exhaust Leakage .
Loud exhaustCompare to a known good vehicle. Inspect for a damaged or failed muffler or resonator. Replace the faulty muffler. Refer to Muffler Replacement (1500 Series w/4.3L, 4.8L, 5.3L, 6.0L) or Muffler Replacement (1500 Series w/6.2L) or Muffler Replacement (2500/3500 Series w/6.0L) or Muffler Replacement (2500/3500 - Cab/Chassis w/6.0L) or Muffler Replacement (6.6L) .
External rattle or vibration noiseInspect for a bent or loose hanger, loose heat shield, or loose clamp. Inspect for a exhaust pipe causing interference. Repair or replace the affected component. Refer to the affected component's service procedure.
Internal rattleTest the components by tapping with a rubber mallet to confirm a rattle. Replace the faulty catalytic converter, or muffler. Refer to one of the following procedures: Catalytic Converter Replacement (4.3L) Catalytic Converter Replacement (4.8L, 5.3L, 6.0L, 6.2L) Catalytic Converter Replacement (6.6L) Muffler Replacement (1500 Series w/4.3L, 4.8L, 5.3L, 6.0L) Muffler Replacement (1500 Series w/6.2L) Muffler Replacement (2500/3500 Series w/6.0L) Muffler Replacement (2500/3500 - Cab/Chassis w/6.0L) Muffler Replacement (6.6L)
CAUTION
While engine is operating, the exhaust system will become extremely hot. To prevent burns avoid contacting a hot exhaust system.

Exhaust Noise

Removal Procedure

  1. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/silverado-1500/2007-2007/remont/hoistjack/#general-information) .
  2. Remove the catalytic converter to exhaust manifold nuts (1).
  3. Lower the vehicle.
  4. Remove the exhaust manifold heat shield bolts and shield.
  5. Remove the spark plugs. Refer to «Spark Plug Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-43l-introduction-2-of-2) .
  6. Reposition the spark plug wires out of the way, if necessary.
  7. Remove the exhaust manifold bolts and stud.
  8. Remove the exhaust manifold and gaskets (1). Discard the gaskets.
  9. Remove the exhaust manifold to catalytic converter seal (2). Discard the seal.

Installation Procedure

  1. Install a NEW exhaust manifold to catalytic converter seal (2) into the relief in the catalytic converter.
  2. Place the exhaust manifold into position and install the manifold studs to the catalytic converter.
  3. Place the NEW exhaust manifold gaskets (1) between the manifold and the cylinder head.
  4. Install the exhaust manifold bolts and stud. Tighten: Tighten the bolts/stud to 30 N.m (22 lb ft).
  5. Install the spark plugs. Refer to «Spark Plug Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-43l-introduction-2-of-2) .
  6. Position the exhaust manifold heat shield to the manifold and install the bolts. Tighten: Tighten the bolts to 9 N.m (80 lb in).
  7. Raise and support the vehicle.
  8. Install the catalytic converter to exhaust manifold nuts (1). Tighten: Tighten the nuts to 50 N.m (37 lb ft).
  9. Lower the vehicle.

Tools Required

J 42640 Steering Column Anti-Rotation Pin

  1. Install the J 42640 into the steering column lower access hole.
  2. Remove the left wheelhouse liner. Refer to «Front Wheelhouse Liner Replacement - Left Side (Chevrolet)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Wheelhouse Liner Replacement - Left Side (GMC)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  3. Fully raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/silverado-1500/2007-2007/remont/hoistjack/#general-information) .
  4. Remove the catalytic converter to exhaust manifold nuts. (1500 series shown, 2500 series similar).
  5. Lower the vehicle part way in order to work through the wheel opening.
  6. Remove the spark plug wires from the spark plugs. Twist the spark plug wire boot a 1/2 turn. Pull only on the boot in order to remove the wire from the spark plug.
  7. Remove the spark plug wires from the ignition coils. Twist the spark plug wire boot a 1/2 turn. Pull only on the boot in order to remove the wire from the ignition coil.
  8. Mark the relationship of the upper intermediate steering shaft to the steering column.
  9. Remove the steering shaft coupling bolt (2) and nut (1) from the upper intermediate steering shaft.
  10. Separate the upper intermediate steering shaft (3) from the steering column, position both shafts out of the way.
  11. Remove the exhaust manifold bolts, and exhaust manifold.
  12. Remove and discard the exhaust manifold gasket.
  13. Remove and discard the catalytic converter seal.
  14. If replacing the exhaust manifold, remove the exhaust manifold heat shield bolts, and shield from the exhaust manifold.
IMPORTANTTighten the exhaust manifold bolts as specified in the service procedure. Improperly installed and/or leaking exhaust manifold gaskets may affect vehicle emissions and/or On-Board Diagnostic (OBD) II system performance. The cylinder head exhaust manifold bolt hole threads must be clean and free of debris or threadlocking material. Do not apply sealant to the first 3 threads of the bolt.
  1. If the exhaust manifold was replaced, position and install the exhaust manifold heat shield, and bolts to the exhaust manifold. Tighten: Tighten the bolts to 9 N.m (80 lb in).
  2. Clean the threads of the exhaust manifold bolts.
  3. Apply a 5 mm (0.2 in) wide band of threadlock GM P/N 12345493 (Canadian P/N 10953488), or equivalent to the threads of the exhaust manifold bolts.
  4. Install a NEW catalytic converter seal to the catalytic converter.
  5. Position the NEW exhaust manifold gasket and exhaust manifold to the cylinder head.
  6. Ensure that the exhaust manifold is seated to the catalytic converter.
  7. Install the exhaust manifold bolts. Tighten: Tighten the bolts a first pass to 15 N.m (11 lb ft). Tighten the exhaust manifold bolts beginning with the center 2 bolts. Alternate from side-to-side, and work toward the outside bolts. Tighten the bolts a final pass to 20 N.m (15 lb ft). Tighten the exhaust manifold bolts beginning with the center 2 bolts. Alternate from side-to-side, and work toward the outside bolts.
  8. Using a flat punch, bend the gasket tab at the rear of the gasket around the cylinder head edge.
  9. Position and align the marks on the upper intermediate steering shaft and the steering column.
  10. Install the upper intermediate steering shaft (3) to the steering column.
  11. Install the steering shaft coupling bolt (2) and nut (1) to the upper intermediate steering shaft. Tighten: Tighten the bolt/nut to 50 N.m (37 lb ft).
  12. Install the spark plug wires to the spark plugs.
  13. Install the spark plug wires to the ignition coils.
  14. Inspect the spark plug wires for proper installation. Push sideways on each boot in order to inspect the seating. Reinstall any loose boot.
  15. Fully raise and support the vehicle.
  16. Install the catalytic converter to exhaust manifold nuts. (1500 series shown, 2500 series similar). Tighten: Tighten the nuts to 50 N.m (37 lb ft).
  17. Partially lower the vehicle.
  18. Install the left wheelhouse liner. Refer to «Front Wheelhouse Liner Replacement - Left Side (Chevrolet)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Wheelhouse Liner Replacement - Left Side (GMC)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  19. Remove the J 42640 from the steering column lower access hole.
  1. Drain the cooling system. Refer to «Cooling System Draining and Filling (Static Fill)»(/chevrolet/silverado-1500/2007-2007/remont/cooling-system-mechanical/#engine-cooling-system__cooling-system-draining-and-filling-static) or «Cooling System Draining and Filling (Vac-N-Fill)»(/chevrolet/silverado-1500/2007-2007/remont/cooling-system-mechanical/#engine-cooling-system__cooling-system-draining-and-filling-vac-n-fill) .
  2. Remove the charge air cooler inlet pipe. Refer to «Charge Air Cooler Inlet Pipe Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  3. Remove the glow plug control module. Refer to «Glow Plug Control Module Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  4. Remove the exhaust gas recirculation (EGR) cooler pipe bracket upper bolt (1).
  5. Raise and suitably support the vehicle half way. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/silverado-1500/2007-2007/remont/hoistjack/#general-information) .
  6. Perform the following steps working through the wheelhouse opening, remove the EGR cooler pipe lower bolt (1) at the oil cooler.
  7. Reposition the EGR cooler pipe (2) out of the way.
  8. Remove the exhaust pipe to exhaust manifold bolts (1).
  9. Remove the exhaust manifold heat shield bolts (1) and shield (2).
  10. Remove the exhaust manifold bolts and nuts in the sequence shown.
  11. Remove the exhaust manifold and gasket. Discard the gasket.
  1. Install the a NEW exhaust manifold gasket onto the manifold studs.
  2. Position a NEW exhaust pipe gasket between the exhaust manifold and exhaust pipe. Align the tab on the gasket to face outward.
  3. Install the exhaust manifold onto the studs.
  4. Install and tighten the exhaust manifold bolts and nuts in the sequence shown. Tighten: Tighten the bolts/nuts to 57 N.m (42 lb ft). Tighten the 4 center bolts/nuts an additional pass to 57 N.m (42 lb ft).
  5. Install and tighten the exhaust pipe to exhaust manifold bolts in the sequence shown (1, 2, and 3). Tighten: Tighten the bolts to 53 N.m (39 lb ft).
  6. Position the exhaust manifold heat shield (2) to the manifold and install the bolts (1). Tighten: Tighten the bolts to 10 N.m (89 lb in).
  7. Position the EGR cooler pipe (2) to the oil cooler.
  8. Install the EGR cooler pipe lower bolt (1) at the oil cooler. Tighten: Tighten the bolt to 9 N.m (80 lb in).
  9. Lower the vehicle.
  10. Install the EGR cooler pipe bracket upper bolt (1). Tighten: Tighten the bolt to 9 N.m (80 lb in).
  11. Install the glow plug control module. Refer to «Glow Plug Control Module Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  12. Install the charge air cooler inlet pipe. Refer to «Charge Air Cooler Inlet Pipe Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  13. Fill the cooling system. Refer to «Cooling System Draining and Filling (Static Fill)»(/chevrolet/silverado-1500/2007-2007/remont/cooling-system-mechanical/#engine-cooling-system__cooling-system-draining-and-filling-static) or «Cooling System Draining and Filling (Vac-N-Fill)»(/chevrolet/silverado-1500/2007-2007/remont/cooling-system-mechanical/#engine-cooling-system__cooling-system-draining-and-filling-vac-n-fill) .
  1. Remove the heated oxygen sensor (HO2S). Refer to «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-43l-introduction-2-of-2) .
  2. Remove the catalytic converter to exhaust manifold nuts (1).
  3. Lower the vehicle.
  4. Remove the exhaust manifold heat shield bolts and shield.
  5. Remove the spark plugs. Refer to «Spark Plug Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-43l-introduction-2-of-2) .
  6. Reposition the spark plug wires out of the way, if necessary.
  7. Remove the exhaust manifold bolts.
  8. Remove the exhaust manifold and gaskets (1). Discard the gaskets.
  9. Remove the exhaust manifold to catalytic converter seal (2). Discard the seal.
  1. Install a NEW exhaust manifold to catalytic converter seal (2) into the exhaust manifold.
  2. Place the exhaust manifold into position and install the manifold studs to the catalytic converter.
  3. Place the NEW exhaust manifold gaskets (1) between the manifold and the cylinder head.
  4. Install the exhaust manifold bolts and stud. Tighten: Tighten the bolts/stud to 30 N.m (22 lb ft).
  5. Install the spark plugs. Refer to «Spark Plug Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-43l-introduction-2-of-2) .
  6. Position the exhaust manifold heat shield to the manifold and install the bolts. Tighten: Tighten the bolts to 9 N.m (80 lb in).
  7. Raise and support the vehicle.
  8. Install the catalytic converter to exhaust manifold nuts (1). Tighten: Tighten the nuts to 50 N.m (37 lb ft).
  9. Lower the vehicle.
  1. Remove the heated oxygen sensor (HO2S). Refer to «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (1500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) .
  2. Fully raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/silverado-1500/2007-2007/remont/hoistjack/#general-information) .
  3. Remove the catalytic converter to exhaust manifold nuts. (1500 series shown, 2500 series similar).
  4. Partially lower the vehicle in order to work through the wheel opening.
  5. Remove the spark plug wires (1) from the spark plugs. Twist the spark plug wire boot a 1/2 turn. Pull only on the boot in order to remove the wire from the spark plug.
  6. Remove the spark plug wires from the ignition coils. Twist the spark plug wire boot a 1/2 turn. Pull only on the boot in order to remove the wire from the ignition coil.
  7. Remove the oil level indicator tube bolt (419).
  8. Remove the oil level indicator tube (420) from the engine block.
  9. Remove the exhaust manifold bolts and exhaust manifold.
  10. Remove and discard the exhaust manifold gasket.
  11. Remove and discard the exhaust manifold seal.
  12. If replacing the exhaust manifold, remove the exhaust manifold heat shield bolts, and shield from the exhaust manifold.
IMPORTANTTighten the exhaust manifold bolts as specified in the service procedure. Improperly installed and/or leaking exhaust manifold gaskets may affect vehicle emissions and/or On-Board Diagnostics (OBD) II system performance. The cylinder head exhaust manifold bolt hole threads must be clean and free of debris or threadlocking material. Do not apply sealant to the first 3 threads of the bolt.
  1. If the exhaust manifold was replaced, position and install the exhaust manifold heat shield, and bolts to the exhaust manifold. Tighten: Tighten the bolts to 9 N.m (80 lb in).
  2. Clean the threads of the exhaust manifold bolts.
  3. Apply a 5 mm (0.2 in) wide band of threadlock GM P/N 12345493 (Canadian P/N 10953488), or equivalent to the threads of the exhaust manifold bolts.
  4. Install a NEW catalytic converter seal to the exhaust manifold.
  5. Position the NEW exhaust manifold gasket and exhaust manifold to the cylinder head.
  6. Ensure that the catalytic converter seal is seated to the catalytic converter.
  7. Install the exhaust manifold bolts. Tighten: Tighten the bolts a first pass to 15 N.m (11 lb ft). Tighten the exhaust manifold bolts beginning with the center 2 bolts. Alternate from side-to-side, and work toward the outside bolts. Tighten the bolts a final pass to 20 N.m (15 lb ft). Tighten the exhaust manifold bolts beginning with the center 2 bolts. Alternate from side-to-side, and work toward the outside bolts.
  8. Using a flat punch, bend the gasket tab at the rear of the gasket around the cylinder head edge.
  9. Inspect the O-ring seal (421) for cuts or damage, replace as necessary.
  10. Lubricate the O-ring seal (421) with clean engine oil.
  11. Install the oil level indicator tube (420) to the engine block.
  12. Install the oil level indicator tube bolt (419). Tighten: Tighten the bolt 25 N.m (18 lb ft).
  13. Install the spark plug wires (1) to the spark plugs.
  14. Install the spark plug wires to the ignition coils.
  15. Inspect the spark plug wires for proper installation. Push sideways on each boot in order to inspect the seating. Reinstall any loose boot.
  16. Fully raise and support the vehicle.
  17. Install the catalytic converter to exhaust manifold nuts. (1500 series shown, 2500 series similar). Tighten: Tighten the nuts to 50 N.m (37 lb ft). Partially lower the vehicle in order to work through the wheel opening. Install the HO2S. Refer to «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (1500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) .
  1. Remove the turbocharger exhaust pipe. Refer to «Turbocharger Exhaust Pipe Replacement (6.6L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  2. Remove the wheelhouse liner. Refer to «Front Wheelhouse Liner Replacement - Right Side (Chevrolet)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Wheelhouse Liner Replacement - Right Side (GMC)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  3. Perform the following steps working through the wheelhouse opening, remove the exhaust pipe to exhaust manifold bolts (1) and bracket.
  4. Remove the exhaust manifold heat shield bolts (1) and shield.
  5. Remove the exhaust manifold bolts and nuts in the proper sequence.
  6. Remove the exhaust manifold and exhaust manifold to pipe gasket.
  7. Remove the oil level indicator tube bolt (2) and rotate the oil level indicator tube out of the way.
  8. Remove and discard the exhaust manifold gasket (1).
  1. Install a NEW exhaust manifold gasket (1) onto the studs.
  2. Rotate the oil level indicator tube into position and install the oil level indicator tube bolt (2). Tighten: Tighten the bolt to 21 N.m (15 lb ft).
  3. Position a NEW exhaust pipe gasket between the exhaust manifold and exhaust pipe. Align the tabs on the gasket to face downward.
  4. Install the exhaust manifold onto the studs.
  5. Install and tighten the exhaust manifold bolts and nuts in the sequence shown. Tighten: Tighten the bolts/nuts to 57 N.m (42 lb ft). Tighten the 4 center bolts/nuts an additional pass to 57 N.m (42 lb ft).
  6. Position the exhaust manifold heat shield to the manifold and install the exhaust manifold bolts (1). Tighten: Tighten the bolts to 10 N.m (89 lb in).
  7. Install the exhaust pipe bracket and the exhaust pipe to exhaust manifold bolts (1).
  8. Tighten the exhaust pipe to exhaust manifold bolts in the sequence shown (4, 5, and 6). Tighten: Tighten the bolts to 53 N.m (39 lb ft).
  9. Install the wheelhouse liner. Refer to «Front Wheelhouse Liner Replacement - Right Side (Chevrolet)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Wheelhouse Liner Replacement - Right Side (GMC)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  10. Install the turbocharger exhaust pipe. Refer to «Turbocharger Exhaust Pipe Replacement (6.6L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  1. Remove the glow plug control module. Refer to «Glow Plug Control Module Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  2. Remove the exhaust gas recirculation (EGR) valve cooler. Refer to «Exhaust Gas Recirculation Valve Cooler Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  3. Remove the turbocharger upper heat shield bolts and shield.
  4. Loosen the turbocharger exhaust pipe to turbocharger clamp bolt (1).
  5. Remover the catalytic converter. Refer to «Catalytic Converter Replacement (4.3L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (4.8L, 5.3L, 6.0L, 6.2L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (6.6L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  6. Perform the following steps working through the wheelhouse opening, Remove the transmission fluid fill tube to bellhousing nuts.
  7. Position the transmission fluid fill tube to the right side of the vehicle. The tube does not require removal from the transmission.
  8. Remove the turbocharger exhaust pipe heat shield bolts and shield.
  9. Remove the turbocharger exhaust pipe to bracket bolt (1).
  10. Remove the turbocharger exhaust pipe.
  1. Install the turbocharger exhaust pipe into the clamp and position the pipe flat against the turbocharger.
  2. Loosely install the turbocharger exhaust pipe to bracket bolt (1).
  3. Position the turbocharger exhaust pipe heat shield and install the heat shield bolts. Tighten: Tighten the bolts to 10 N.m (89 lb ft).
  4. Position the transmission fluid fill tube.
  5. Install the transmission fluid fill tube to bellhousing nuts. Tighten: Tighten the nuts to 18 N.m (13 lb ft).
  6. Tighten the turbocharger exhaust pipe to turbocharger clamp bolt (1). Tighten: Tighten the bolt to 15 N.m (11 lb ft).
  7. Install the catalytic converter. Refer to «Catalytic Converter Replacement (4.3L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (4.8L, 5.3L, 6.0L, 6.2L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (6.6L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  8. Tighten the turbocharger exhaust pipe to bracket bolt. Tighten: Tighten the bolt to 34 N.m (25 lb ft).
  9. Install the turbocharger upper heat shield and bolts. Tighten: Tighten the bolts to 10 N.m (89 lb in).
  10. Install the EGR valve cooler. Refer to «Exhaust Gas Recirculation Valve Cooler Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  11. Install the glow plug control module. Refer to «Glow Plug Control Module Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  1. Remove the heated oxygen sensor (HO2S). Refer to «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (1500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) .
  2. Support the transmission with a suitable transmission jack.
  3. Remove the transmission mount to transmission support nuts.
  4. Using the transmission jack, raise the transmission up off of the transmission support.
  5. Remove the transmission support crossmember bolts.
  6. Remove the transmission support crossmember.
  7. Remove the exhaust muffler to exhaust manifold pipe nuts (1).
  8. Remove the exhaust manifold pipe to exhaust manifold nuts.
  9. Using the transmission jack, lower the transmission slightly.
  10. Separate any necessary exhaust muffler insulators so that the pipe may be separated from the muffler.
  11. Remove the exhaust manifold pipe.
  12. Discard the exhaust manifold pipe gasket.
  1. Install a NEW exhaust manifold pipe gasket onto the muffler studs.
  2. Install the exhaust manifold pipe.
  3. Install any necessary exhaust muffler insulators that were separated from the muffler.
  4. Using the transmission jack, raise the transmission slightly.
  5. Install the exhaust manifold pipe to exhaust manifold nuts. Tighten: Tighten the nuts to 50 N.m (37 lb ft).
  6. Install the exhaust muffler to exhaust manifold pipe nuts (1). Tighten: Tighten the nuts to 45 N.m (33 lb ft).
  7. Position the transmission support crossmember.
  8. Install the transmission support crossmember bolts. Tighten: Tighten the bolts to 95 N.m (70 lb ft).
  9. Using the transmission jack, lower the transmission onto the transmission support.
  10. Install the transmission mount to transmission support nuts. Tighten: Tighten the nuts to 40 N.m (30 lb ft).
  11. Remove the support from the transmission.
  12. Install the HO2S. Refer to «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (1500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) .
  1. Remove the transmission. Refer to «Transmission Replacement»(/chevrolet/silverado-1500/2007-2007/remont/automatic-trans/#automatic-transmission-allison-removal-installation-service-overhaul-troubleshooting-diagnosis__transmission-replacement) .
  2. Remove the exhaust heat shield nuts (2) and heat shield (3) from the dash panel.
  3. Remove the exhaust pipe heat shield bolts and shield.
  4. Remove the exhaust pipe bolts in the sequence shown.
  5. Remove the exhaust pipe and gaskets. Discard the gaskets.
  1. Position the exhaust pipe with a NEW gasket to the turbocharger.
  2. Loosely install the exhaust pipe to turbocharger bolts.
  3. Position the exhaust pipe with a NEW gasket to the exhaust manifold. Align the tabs on the gasket to face downward.
  4. Loosely install the exhaust pipe to exhaust manifold bolts.
  5. Tighten the exhaust pipe bolts in the sequence shown. Tighten: Tighten the bolts to 53 N.m (39 lb ft).
  6. Install the exhaust pipe heat shield bolts. Tighten: Tighten the bolts to 10 N.m (89 lb in).
  7. Install the left side exhaust heat shield (3) at the dash panel.
  8. Install the heat shield nuts (2). Tighten: Tighten the nuts to 9 N.m (80 lb in).
  9. Install the transmission. Refer to «Transmission Replacement»(/chevrolet/silverado-1500/2007-2007/remont/automatic-trans/#automatic-transmission-allison-removal-installation-service-overhaul-troubleshooting-diagnosis__transmission-replacement) .
  1. Remove the turbocharger exhaust pipe. Refer to «Turbocharger Exhaust Pipe Replacement (6.6L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  2. Remove the transmission. Refer to «Transmission Replacement»(/chevrolet/silverado-1500/2007-2007/remont/automatic-trans/#automatic-transmission-allison-removal-installation-service-overhaul-troubleshooting-diagnosis__transmission-replacement) .
  3. Remove the exhaust pipe bolts in the proper sequence.
  4. Remove the exhaust pipe, bracket and gaskets. Discard the gaskets.
  1. Position the exhaust pipe with a NEW gasket to the turbocharger.
  2. Loosely install the exhaust pipe to turbocharger bolts.
  3. Position the exhaust pipe with a NEW gasket to the exhaust manifold. Align the tabs on the gasket to face downward.
  4. Loosely install the exhaust pipe to exhaust manifold bolts.
  5. Tighten the exhaust pipe bolts in the sequence shown. Tighten: Tighten the bolts to 53 N.m (39 lb ft).
  6. Install the transmission. Refer to «Transmission Replacement»(/chevrolet/silverado-1500/2007-2007/remont/automatic-trans/#automatic-transmission-allison-removal-installation-service-overhaul-troubleshooting-diagnosis__transmission-replacement) .
  7. Install the turbocharger exhaust pipe. Refer to «Turbocharger Exhaust Pipe Replacement (6.6L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  1. Remove the catalytic converter. Refer to «Catalytic Converter Replacement (4.3L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (4.8L, 5.3L, 6.0L, 6.2L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (6.6L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  2. Remove and discard the appropriate exhaust seal (1 or 2). (1500 series shown, 2500 series similar).
  1. Install the NEW appropriate exhaust seal (1 or 2). (1500 series shown, 2500 series similar).
  2. Install the catalytic converter. Refer to «Catalytic Converter Replacement (4.3L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (4.8L, 5.3L, 6.0L, 6.2L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (6.6L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  1. Remove the left catalytic converter, if required. Refer to «Catalytic Converter Replacement - Left Side (6.0L - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  2. Remove the exhaust manifold pipe, if required. Refer to «Exhaust Manifold Pipe Replacement (6.0L - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  3. Remove and discard the appropriate exhaust seal (1) or gasket (2).
  1. Install the NEW appropriate exhaust seal (1) or gasket (2).
  2. Install the exhaust manifold pipe, if required. Refer to «Exhaust Manifold Pipe Replacement (6.0L - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  3. Install the left catalytic converter, if required. Refer to «Catalytic Converter Replacement - Left Side (6.0L - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/silverado-1500/2007-2007/remont/hoistjack/#general-information) .
  2. Remove the oil pan skid plate bolts and skid plate, if equipped.
  3. Remove the transmission crossmember. Refer to «Transmission Support Crossmember Replacement (2WD 1500/2500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Transmission Support Crossmember Replacement (2WD 2500 HD/3500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Transmission Support Crossmember Replacement (4WD 1500/2500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Transmission Support Crossmember Replacement (4WD 2500 HD/3500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  4. Remove the right front connector position assurance (CPA) retainer.
  5. Disconnect the right front heated oxygen sensor (HO2S) electrical connector (5) from the engine wiring harness electrical connector (4).
  6. Remove the right rear CPA retainer.
  7. Disconnect the engine wiring harness electrical connector (2) from the right rear HO2S electrical connector (1).
  8. Remove the right rear HO2S electrical connector clip from the engine harness clip (3).
  9. Remove the left rear CPA retainer.
  10. Disconnect the engine wiring harness electrical connector (1) from the left rear HO2S electrical connector (2).
  11. Remove the left rear HO2S electrical connector clip from the frame.
  12. For vehicles equipped with 2 wheel drive (2WD) perform the following steps, for vehicles equipped with 4 wheel drive (4WD) proceed to step 15.
  13. Remove the left front CPA retainer.
  14. Disconnect the left front HO2S electrical connector (7) from the engine wiring harness electrical connector (6).
  15. For vehicles equipped with 4WD perform the following steps, remove the left front CPA retainer.
  16. Disconnect the engine wiring harness electrical connector (7) from the left front HO2S electrical connector (8).
  17. Remove the left front HO2S electrical connector clip from the fuel line clip (2).
  18. Remove the catalytic converter to muffler nuts.
  19. Remove the catalytic converter to exhaust manifold nuts (1).
  20. Separate the catalytic converter assembly from the exhaust manifolds.
  21. Remove the catalytic converter assembly from the exhaust muffler.
  22. If replacing the catalytic converter assembly, perform the following steps, otherwise proceed to step 4 in the installation procedure.
  23. Remove the exhaust seals (2 and 3).
  24. Remove the HO2S (1-4) from the catalytic converter assembly.
IMPORTANTA special anti-seize compound is used on the HO2S threads. The compound consists of liquid graphite and glass beads. The graphite tends to burn away, but the glass beads remain, making the sensor easier to remove. New, or service replacement sensors already have the compound applied to the threads. If the sensor is removed from as exhaust component and if for any reason the sensor is to be reinstalled, the threads must have anti-seize compound applied before the reinstallation.
  1. If replacing the catalytic converter assembly, perform the following steps, otherwise proceed to step 4.
  2. If reinstalling the old sensors, coat the threads with anti-seize compound GM P/N 12377953, or equivalent.
  3. Install the HO2S (1-4) to the catalytic converter assembly. Tighten: Tighten the sensors to 42 N.m (31 lb ft).
  4. Install the NEW exhaust seals (2 and 3) as required.
  5. Install the catalytic converter assembly to the muffler.
  6. Install the catalytic converter assembly to the exhaust manifolds.
  7. Install the catalytic converter to exhaust manifold nuts (1). Tighten: Tighten the nuts to 50 N.m (37 lb ft).
  8. Install the catalytic converter to muffler nuts. Tighten: Tighten the nuts to 45 N.m (33 lb ft).
  9. For vehicles equipped with 4WD perform the following steps, for vehicles equipped with 2WD proceed to step 13.
  10. Connect the engine wiring harness electrical connector (6) to the left front HO2S electrical connector (7).
  11. Install the CPA retainer.
  12. Install the HO2S electrical connector clip to the fuel line clip (2).
  13. For vehicles equipped with 4WD perform the following steps, connect the engine wiring harness electrical connector (7) to the left front HO2S electrical connector (8).
  14. Install the left front CPA retainer.
  15. Connect the engine wiring harness electrical connector (1) to the left rear HO2S electrical connector (2).
  16. Install the left rear HO2S electrical connector clip to the frame.
  17. Install the CPA retainer.
  18. Connect the engine wiring harness electrical connector (2) to the right rear HO2S electrical connector (1).
  19. Install the right rear CPA retainer.
  20. Install the right rear HO2S electrical connector clip to the engine harness clip (3).
  21. Connect the right front HO2S electrical connector (5) to the engine wiring harness electrical connector (4).
  22. Install the right front CPA retainer.
  23. Install the transmission crossmember. Refer to «Transmission Support Crossmember Replacement (2WD 1500/2500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Transmission Support Crossmember Replacement (2WD 2500 HD/3500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Transmission Support Crossmember Replacement (4WD 1500/2500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Transmission Support Crossmember Replacement (4WD 2500 HD/3500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  24. Position the oil pan skid plate and install the oil pan skid plate bolts, if equipped. Tighten: Tighten the bolts to 28 N.m (21 lb ft).
  25. Lower the vehicle.
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/silverado-1500/2007-2007/remont/hoistjack/#general-information) .
  2. Remove the oil pan skid plate bolts and skid plate, if equipped.
  3. Remove the transmission crossmember. Refer to «Transmission Support Crossmember Replacement (2WD 1500/2500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Transmission Support Crossmember Replacement (2WD 2500 HD/3500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Transmission Support Crossmember Replacement (4WD 1500/2500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Transmission Support Crossmember Replacement (4WD 2500 HD/3500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  4. Remove the right front connector position assurance (CPA) retainer (2).
  5. Disconnect the right front heated oxygen sensor (HO2S) electrical connector from the engine wiring harness electrical connector (1).
  6. Remove the right rear CPA retainer (4).
  7. Disconnect the engine wiring harness electrical connector (3) from the right rear HO2S electrical connector.
  8. Remove the right rear HO2S electrical connector clip from the engine harness clip (5).
  9. Remove the left rear CPA retainer (1).
  10. Disconnect the left rear HO2S electrical connector from the engine wiring harness electrical connector (3).
  11. For vehicles equipped with a 4L60-E/4L70-E automatic transmission perform the following steps, for vehicles equipped with a 6L80-E automatic transmission proceed to step 15.
  12. Remove the left front CPA retainer.
  13. Disconnect the engine wiring harness electrical connector (2) from the left front HO2S.
  14. Remove the left front HO2S electrical connector clip (1) from the fuel line clip.
  15. Remove the left front CPA retainer (2).
  16. Remove the engine wiring harness electrical connector clip (1) from the fuel line clip.
  17. Disconnect the engine wiring harness electrical connector (3) from the left front HO2S.
  18. If the vehicle is a 1500 series, remove the catalytic converter to muffler nuts.
  19. If the vehicle is a 2500/3500 series, remove the muffler to catalytic converter nuts.
  20. Remove the HO2S. Refer to «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (1500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) .
  21. Remove the catalytic converter to exhaust manifold nuts (1). (1500 series shown, 2500/3500 series similar).
  22. Separate the catalytic converter assembly from the exhaust manifolds.
  23. Remove the catalytic converter assembly from the exhaust muffler.
  24. If replacing the catalytic converter assembly, perform the following steps, otherwise proceed to step 4 in the installation procedure.
  25. Remove the exhaust seals (2 and 3).
  26. Remove the HO2S (1-5) from the catalytic converter assembly. (1500 series shown, 2500/3500 series similar).
IMPORTANTA special anti-seize compound is used on the HO2S threads. The compound consists of liquid graphite and glass beads. The graphite tends to burn away, but the glass beads remain, making the sensor easier to remove. New, or service replacement sensors already have the compound applied to the threads. If the sensor is removed from as exhaust component and if for any reason the sensor is to be reinstalled, the threads must have anti-seize compound applied before the reinstallation.
  1. If replacing the catalytic converter assembly, perform the following steps, otherwise proceed to step 4.
  2. If reinstalling the old sensors, coat the threads with anti-seize compound GM P/N 12377953, or equivalent.
  3. Install the HO2S (1-5) to the catalytic converter assembly. (1500 series shown, 2500/3500 series similar). Tighten: Tighten the sensors to 42 N.m (31 lb ft).
  4. Install the NEW exhaust seals (2 and 3) as required. (1500 series shown, 2500/3500 series similar).
  5. Install the catalytic converter assembly to the muffler.
  6. Install the catalytic converter assembly to the exhaust manifolds.
  7. Install the catalytic converter to exhaust manifold nuts (1). Tighten: Tighten the nuts to 50 N.m (37 lb ft).
  8. Install the HO2S. Refer to «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (1500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 1 (2500 Series - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) .
  9. If the vehicle is a 2500/3500 series, install the muffler to catalytic converter nuts. Tighten: Tighten the nuts to 45 N.m (33 lb ft).
  10. If the vehicle is a 1500 series, install the catalytic converter to muffler nuts. Tighten: Tighten the nuts to 45 N.m (33 lb ft).
  11. For vehicles equipped with a 4L60-E/4L70-E automatic transmission perform the following steps, for vehicles equipped with a 6L80-E automatic transmission proceed to step 13.
  12. Install the HO2S electrical connector clip (1) to the fuel line clip.
  13. Connect the engine wiring harness electrical connector (2) to the HO2S.
  14. Install the CPA retainer.
  15. Connect the engine wiring harness electrical connector (3) to the HO2S.
  16. Install the engine wiring harness electrical connector clip (1) to the fuel line clip.
  17. Install the CPA retainer (2).
  18. Connect the left rear HO2S electrical connector to the engine wiring harness electrical connector (3).
  19. Install the left rear CPA retainer (1).
  20. Install the right rear HO2S electrical connector clip to the engine harness clip (5).
  21. Connect the engine wiring harness electrical connector (3) to the right rear HO2S electrical connector.
  22. Install the right rear CPA retainer (4).
  23. Connect the right front HO2S electrical connector to the engine wiring harness electrical connector (1).
  24. Install the right front CPA retainer (2).
  25. Install the transmission crossmember. Refer to «Transmission Support Crossmember Replacement (2WD 1500/2500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Transmission Support Crossmember Replacement (2WD 2500 HD/3500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Transmission Support Crossmember Replacement (4WD 1500/2500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Transmission Support Crossmember Replacement (4WD 2500 HD/3500)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  26. Position the oil pan skid plate and install the oil pan skid plate bolts, if equipped. Tighten: Tighten the bolts to 28 N.m (21 lb ft).
  27. Lower the vehicle.
  1. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/silverado-1500/2007-2007/remont/hoistjack/#general-information) .
  2. Support the transmission with a suitable transmission jack.
  3. Remove the transmission mount to transmission support nuts.
  4. Raise the transmission off of the transmission support.
  5. Remove the transmission support crossmember bolts.
  6. Remove the transmission support crossmember.
  7. Remove the catalytic converter to particulate filter nuts.
  8. Loosen the turbocharger exhaust pipe to catalytic converter clamp.
  9. Slide the clamp up onto the turbocharger exhaust pipe.
  10. Remove the catalytic converter.
  1. Apply water based lubricant to the exhaust pipe hanger bracket, in order to aid in installation.
  2. Install the catalytic converter.
  3. Slide the down turbocharger exhaust pipe to catalytic converter clamp.
  4. Tighten the turbocharger exhaust pipe to catalytic converter clamp. Tighten: Tighten the clamp to 12 N.m (106 lb in).
  5. Install the catalytic converter to particulate filter nuts. Tighten: Tighten the nuts to 45 N.m (33 lb ft).
  6. Install the transmission support crossmember.
  7. Install the transmission support crossmember bolts. Tighten: Tighten the bolts to 95 N.m (70 lb ft).
  8. Lower the transmission onto the transmission support.
  9. Install the transmission mount to transmission support nuts. Tighten: Tighten the bolts to 40 N.m (30 lb ft).
  10. Remove the support from the transmission.
  11. Lower the vehicle.
  1. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/silverado-1500/2007-2007/remont/hoistjack/#general-information) .
  2. Support the transmission with a suitable transmission jack.
  3. Remove the transmission mount to transmission support nuts.
  4. Raise the transmission off of the transmission support.
  5. Remove the transmission support crossmember bolts.
  6. Remove the transmission support crossmember.
  7. Loosen the exhaust muffler clamp (3).
  8. Separate any necessary exhaust muffler insulators so that the pipe may be separated from the muffler.
  9. Use a jack stand to support the muffler.
  10. Remove the connector position assurance (CPA) retainer (3) from the left front heated oxygen sensor (HO2S).
  11. Disconnect the engine wiring harness electrical connector (2) from the left front HO2S (1) electrical connector.
  12. Remove the CPA retainer (8) from the left rear HO2S.
  13. Disconnect the engine wiring harness electrical connector (4) from the left rear HO2S electrical connector (3).
  14. Loosen the exhaust manifold pipe to exhaust manifold nuts.
  15. Remove the left catalytic converter to exhaust manifold nuts.
  16. Using the transmission jack, lower the transmission slightly.
  17. Remove the left catalytic converter.
  18. If the left catalytic converter is being replaced, remove the HO2S (1 and 4).
IMPORTANTA special anti-seize compound is used on the HO2S threads. The compound consists of liquid graphite and glass beads. The graphite tends to burn away, but the glass beads remain, making the sensor easier to remove. New, or service replacement sensors already have the compound applied to the threads. If the sensor is removed from an exhaust component and if for any reason the sensor is to be reinstalled, the threads must have the anti-seize compound applied before the reinstallation.
  1. If the left catalytic converter was replaced, perform the following steps: If reinstalling the old sensor, coat the threads with anti-seize compound GM P/N 12377953 or equivalent. Install the HO2S (1 and 4). Tighten: Tighten the sensors to 42 N.m (31 lb ft).
  2. Install the left catalytic converter.
  3. Using the transmission jack, raise the transmission slightly.
  4. Install the left catalytic converter to exhaust manifold nuts. Tighten: Tighten the nuts to 50 N.m (37 lb ft).
  5. Tighten the exhaust manifold pipe to exhaust manifold nuts. Tighten: Tighten the nuts to 50 N.m (37 lb ft).
  6. Connect the engine wiring harness electrical connector (4) to the left rear HO2S electrical connector (3).
  7. Install the CPA retainer (8) to the left rear HO2S.
  8. Connect the engine wiring harness electrical connector (2) to the left front HO2S (1) electrical connector.
  9. Install the CPA retainer (3) to the left front HO2S.
  10. Tighten the exhaust muffler clamp (3). Tighten: Tighten the clamp to 47 N.m (35 lb ft).
  11. Install any necessary exhaust muffler insulators that were separated from the muffler.
  12. Remove the jack stand from under the muffler.
  13. Position the transmission support crossmember.
  14. Install the transmission support crossmember bolts. Tighten: Tighten the bolts to 95 N.m (70 lb ft).
  15. Using the transmission jack, lower the transmission onto the transmission support.
  16. Install the transmission mount to transmission support nuts. Tighten: Tighten the nuts to 95 N.m (70 lb ft).
  17. Remove the support from the transmission.
  18. Lower the vehicle.

Exhaust Particulate Filter Cleaning (DPF Service Regeneration)

CAUTIONTailpipe outlet exhaust temperature will be greater than 300°C (572°F) during service regeneration. To help prevent personal injury or property damage from fire or burns, perform the following: Do not connect any shop exhaust removal hoses to the vehicle's tailpipe. Park the vehicle outdoors and keep people, other vehicles, and combustible material away during service regeneration. Do not leave the vehicle unattended.
CAUTIONTo avoid extremely elevated exhaust temperatures, inspect and remove any debris or mud build up at the exhaust cooler located at the tailpipe.

Note. Due to the elevated engine temperatures created while performing this procedure it is imperative to keep the front of vehicle in an open environment, with the hood open, away from any walls or buildings. This will ensure proper airflow across the radiator.

Conditions for Running

The following conditions must be met in order to enable DPF Service Regeneration

  1. There are no active DTCs displayed.
  2. The battery voltage is greater than 10 volts.
  3. The engine speed is between 600-1,250 RPM.
  4. The exhaust gas temperature (EGT) sensors 1 and 2 are less than 400°C (752°F).
  5. The engine coolant temperature (ECT) sensor 1 is between 70-115°C (158-239°F).
  6. The brake pedal and accelerator pedal are in the released position.
  7. The transmission is in Park or Neutral.

Test Procedure

  1. Clear all DTCs with a scan tool before proceeding with DPF Service Regeneration.
  2. Observe the scan tool DPF Regenerations Completed parameter and record the value.
  3. Check the following fluid levels before and after this procedure: Engine oil Engine coolant Power steering Transmission Fuel level should be over 15 percent to ensure a successful regeneration.
  4. Park the vehicle outside the facility, away from any obstacles, place the transmission in Park and apply the parking brake.
  5. Ensure the hood is open.
  6. Select DPF Service Regeneration in the Output Controls menu and follow the instruction on the scan tool.
  7. Command the DPF Service Regeneration with the scan tool.
  8. The DPF Service Regeneration will take approximately 35 minutes consisting of the following: 8 minutes for the exhaust system to warm up, with the engine speed slowly increasing to 1,600 RPM, then 2,200 RPM and finally 2,500 RPM 20 minutes for the DPF to regenerate at 2,500 RPM 3 minutes for the exhaust system to cool down with the engine speed will slowly returning to 1,400 RPM 3 minutes at 800 RPM, then idle speed of 680 RPM
  9. The DPF Service Regeneration will be terminated if any of the following actions are performed: Applying the brake pedal Applying the accelerator pedal Selecting Drive or Reverse Commanding DPF Service Regeneration OFF using the scan tool or disconnecting the scan tool from the vehicle
  10. After the service regeneration completes, allow the vehicle to idle for an additional 2 minutes while monitoring the scan tool DTC information. There should be no additional DTCs setting. If DTC P224B sets, replace the Exhaust Particulate Filter. If service regeneration aborted or failed, repair the vehicle for the condition indicated by the scan tool DPF Regen Inhibit Reason parameter. Refer to the «Service Regeneration Fault Table»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  11. Ignition OFF for 90 seconds, perform the following within 10 minutes of a completed service regeneration. Operate the vehicle within the following conditions to run the DTC. Refer to «DTC P2002»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-dtc-p154b-to-dtc-p2693) . If DTC P2002 sets, replace the Exhaust Particulate Filter.
  12. Verify that the scan tool DPF Soot Mass parameter is less than 10 grams. If greater than the specified range, refer to «Service Regeneration Unsuccessful»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system__service-regeneration-unsuccessful) .
  13. Verify that the scan tool DPF Regenerations Completed parameter has increased by one. If the value has not increased by one, refer to «Service Regeneration Unsuccessful»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system__service-regeneration-unsuccessful) .

Service Regeneration Unsuccessful

  1. The scan tool DPF Regen Inhibit Reason parameter, will display a reason for not enabling DPF Service Regeneration. Refer to the parameters that are displayed.
  2. The scan tool DPF Regeneration Status parameter will display Active or Required depending on the current commanded state of regeneration.
  3. The scan tool DPF Regenerations Completed parameter did not increment.
  4. The scan tool DPF Soot Mass parameter, will display greater than 10 grams, indicating excessive particulate matter is still present in the filter.
DPF Regeneration ParametersSuccessful RegenerationUnsuccessful Regeneration
DPF Regeneration StatusCompleteActive or Required
DPF Regeneration ReasonNoneFuel Used Engine Run Time Distance Traveled DPF Pressure Soot Mass Calculated Soot
DPF Regeneration Inhibit ReasonNoneVaries
DPF Soot MassLess than 10 gramsGreater than 10 grams

Service Regeneration Status Fault Table

DPF Regeneration Enable

IMPORTANTThe DPF Regeneration Enable is required when specific service procedures have been performed. Do not perform a DPF Regeneration Enable unless instructed to in the Repair Instruction section of the service procedure. After the system repair perform the following to avoid possible damage to the DPF.
  1. Ignition ON, clear all DTCs with a scan tool.
  2. Select DPF Regeneration Enable within the Special Function menu.
  3. Select ON. The selection can be confirmed by the DPF Regeneration Reason parameter indicating Device Control.
  4. Exit the Special Function Menu. The scan tool can now be removed.

The vehicle will perform an active Regeneration as soon as the engine running conditions are met.

  1. Remove the catalytic converter. Refer to «Catalytic Converter Replacement (4.3L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (4.8L, 5.3L, 6.0L, 6.2L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (6.6L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  2. Remove the exhaust temperature sensors. Refer to «Exhaust Temperature Sensor Replacement - Position 1»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) and «Exhaust Temperature Sensor Replacement - Position 2»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  3. Remove the exhaust pressure differential sensor pipe. Refer to «Exhaust Pressure Differential Sensor Pipe Replacement (Pickup)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) or «Exhaust Pressure Differential Sensor Pipe Replacement (Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  4. Remove the exhaust muffler to exhaust particulate filter nuts (1).
  5. Remove the exhaust particulate filter hangers from the exhaust insulators (1).
  6. Remove the exhaust particulate filter. (2500/3500 crew cab shown, regular/extended cabs similar).
  7. Remove and discard the exhaust particulate filter to muffler gasket.
  1. Install a NEW gasket onto the exhaust muffler studs.
  2. Install the exhaust particulate filter to the muffler studs.
  3. Install the exhaust particulate filter hangers to the exhaust insulators (1).
  4. Install the exhaust muffler to exhaust particulate filter nuts (1). Tighten: Tighten the nuts to 45 N.m (33 lb ft).
  5. Install the exhaust pressure differential sensor pipe. Refer to «Exhaust Pressure Differential Sensor Pipe Replacement (Pickup)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) or «Exhaust Pressure Differential Sensor Pipe Replacement (Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  6. Install the exhaust temperature sensors. Refer to «Exhaust Temperature Sensor Replacement - Position 1»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) and «Exhaust Temperature Sensor Replacement - Position 2»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  7. Install the catalytic converter. Refer to «Catalytic Converter Replacement (4.3L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (4.8L, 5.3L, 6.0L, 6.2L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (6.6L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  8. Using a scan tool, perform the DPF Reset For Replace DPF.
  1. Remove the exhaust temperature sensors. Refer to «Exhaust Temperature Sensor Replacement - Position 1»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) and «Exhaust Temperature Sensor Replacement - Position 2»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  2. Remove the exhaust pressure differential sensor pipe. Refer to «Exhaust Pressure Differential Sensor Pipe Replacement (Pickup)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) or «Exhaust Pressure Differential Sensor Pipe Replacement (Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  3. Remove the catalytic converter to exhaust particulate filter nuts (1).
  4. Remove the exhaust particulate filter hangers from the exhaust insulators (1).
  5. Remove the exhaust particulate filter (1).
  6. Remove and discard the catalytic converter to particulate filter gasket (2).
  1. Install a NEW gasket (2) onto the exhaust particulate filter studs.
  2. Install the exhaust particulate filter (1) to the catalytic converter.
  3. Install the exhaust particulate filter hangers to the exhaust insulators (1).
  4. Install the exhaust particulate filter to catalytic converter nuts (1). Tighten: Tighten the nuts to 45 N.m (33 lb ft).
  5. Install the exhaust pressure differential sensor pipe. Refer to «Exhaust Pressure Differential Sensor Pipe Replacement (Pickup)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) or «Exhaust Pressure Differential Sensor Pipe Replacement (Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  6. Install the exhaust temperature sensors. Refer to «Exhaust Temperature Sensor Replacement - Position 1»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) and «Exhaust Temperature Sensor Replacement - Position 2»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-66l-lmm-introduction-2-of-2) .
  7. Using a scan tool, perform the DPF Reset For Replace DPF.
  1. If equipped with a 6.0L engine, remove the exhaust manifold pipe. Refer to «Exhaust Manifold Pipe Replacement (6.0L - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  2. If equipped with a 6.0L engine, remove the left catalytic converter. Refer to «Catalytic Converter Replacement - Left Side (6.0L - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  3. If equipped with a 6.6L engine, remove the catalytic converter. Refer to «Catalytic Converter Replacement (4.3L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (4.8L, 5.3L, 6.0L, 6.2L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (6.6L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  4. If equipped with a 4L80-E automatic transmission, regular production option (RPO) MT1, remove the exhaust pipe hanger bracket bolts and bracket.
  5. If equipped with a Allison® automatic transmission, RPO MW7, remove the exhaust pipe hanger bracket bolt/stud and bracket.
  6. If equipped with a 6L90-E automatic transmission, RPO MYD, remove the exhaust pipe hanger bracket bolts and bracket.
  1. If equipped with a 6L90-E automatic transmission, RPO MYD, install the exhaust pipe hanger bracket and bolts. Tighten: Tighten the bolts to 25 N.m (18 lb ft).
  2. If equipped with a Allison® automatic transmission, RPO MW7, install the exhaust pipe hanger bracket and bolt/stud. Tighten: Tighten the bolt/stud to 25 N.m (18 lb ft).
  3. If equipped with a 4L80-E automatic transmission, RPO MT1, install the exhaust pipe hanger bracket and bolts. Tighten: Tighten the bolts to 25 N.m (18 lb ft).
  4. If equipped with a 6.6L engine, install the catalytic converter. Refer to «Catalytic Converter Replacement (4.3L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (4.8L, 5.3L, 6.0L, 6.2L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (6.6L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  5. If equipped with a 6.0L engine, install the left catalytic converter. Refer to «Catalytic Converter Replacement - Left Side (6.0L - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  6. If equipped with a 6.0L engine, install the exhaust manifold pipe. Refer to «Exhaust Manifold Pipe Replacement (6.0L - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  1. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/silverado-1500/2007-2007/remont/hoistjack/#general-information) .
  2. Remove the catalytic converter to exhaust muffler nuts.
  3. If equipped with a 4.8L engine, perform the following steps, otherwise proceed to step 7.
  4. Lubricate the 3 insulators where the muffler assembly hangers are inserted in order to ease removal.
  5. With the aid of an assistant, remove the insulators (1 and 2) from the front and rear muffler assembly hangers.
  6. Remove the insulator (1) from the intermediate muffler assembly hanger and remove the muffler assembly.
  7. If equipped with a 5.3L, or a 6.0L engine, perform the following steps.
  8. Lubricate the 3 insulators where the muffler assembly hangers are inserted in order to ease removal.
  9. With the aid of an assistant, remove the insulators (1 and 2) from the front and rear muffler assembly hangers.
  10. Remove the insulators (1) from the intermediate muffler assembly hangers and remove the muffler assembly.
  1. If equipped with a 4.8L engine, perform the following steps, otherwise proceed to step 6.
  2. Lubricate the 3 insulators where the muffler assembly hangers are inserted in order to ease installation.
  3. With the aid of an assistant, position and install the muffler assembly.
  4. Install the insulators (1 and 2) to the front and rear muffler assembly hangers.
  5. Install the insulator (1) to the intermediate muffler assembly hanger.
  6. If equipped with a 5.3L, or a 6.0L engine, perform the following steps.
  7. Lubricate the 3 insulators where the muffler assembly hangers are inserted in order to ease installation.
  8. With the aid of an assistant, position and install the muffler assembly.
  9. Install the insulators (1 and 2) to the front and rear muffler assembly hangers.
  10. Install the insulator (1) to the intermediate muffler assembly hanger.
  11. Install the catalytic converter to exhaust muffler nuts. Tighten: Tighten the nuts to 45 N.m (33 lb ft).
  12. Lower the vehicle.
  1. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/silverado-1500/2007-2007/remont/hoistjack/#general-information) .
  2. Remove the spare tire, if necessary.
  3. Install adjustable jack stands under the rear axle, if necessary.
  4. If equipped with a 8.6 or a 9.5 inch ring gear, remove the rear axle vent hose from the rear axle, if necessary.
  5. Remove the vent hose swivel clip from the rear brake crossover pipe, if necessary.
  6. If equipped with a 10.5 inch ring gear, remove the rear axle vent hose from the rear axle, if necessary.
  7. Remove the vent hose swivel clip from the rear brake crossover pipe, if necessary.
  8. Remove the rear shock absorber lower bolts and nuts, if necessary.
  9. Lower the rear axle using the adjustable jack stands, if necessary.
  10. Remove the catalytic converter to muffler nuts.
  11. Lubricate the 5 insulators where the muffler assembly hangers are inserted in order to ease removal.
  12. With the aid of an assistant, remove the insulators (1-3) from the front, intermediate and rear muffler assembly hangers.
  13. Remove the insulator (1) from the tail pipe hanger and remove the muffler assembly.
  1. Lubricate the 5 insulators where the muffler assembly hangers are inserted in order to ease installation.
  2. With the aid of an assistant, position and install the muffler assembly.
  3. Install the insulator (1) to the rear tail pipe hanger.
  4. Install the insulators (1-3) to the front, intermediate, and rear muffler assembly hangers.
  5. Install the catalytic converter to muffler nuts. Tighten: Tighten the nuts to 45 N.m (33 lb ft).
  6. Raise the rear axle using the adjustable jack stands, if necessary.
  7. Install the rear shock absorber lower bolts and nuts, if necessary. Tighten: Tighten the bolts to 95 N.m (70 lb ft).
  8. If equipped with a 10.5 inch ring gear, install the rear axle vent hose to the rear axle, if necessary.
  9. Connect the vent hose swivel clip to the rear brake crossover pipe, if necessary.
  10. If equipped with a 8.6 or a 9.5 inch ring gear, install the rear axle vent hose to the rear axle, if necessary.
  11. Install the vent hose swivel clip to the rear brake crossover pipe, if necessary.
  12. Remove the adjustable jack stands from under the rear axle, if necessary.
  13. Install the spare tire, if necessary.
  14. Lower the vehicle.
  1. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/silverado-1500/2007-2007/remont/hoistjack/#general-information) .
  2. Remove the spare tire, if necessary.
  3. Install adjustable jack stands under the rear axle, if necessary.
  4. If equipped with a 8.6 or a 9.5 inch ring gear, remove the rear axle vent hose from the rear axle, if necessary.
  5. Remove the vent hose swivel clip from the rear brake crossover pipe, if necessary.
  6. If equipped with a 10.5 inch ring gear, remove the rear axle vent hose from the rear axle, if necessary.
  7. Remove the vent hose swivel clip from the rear brake crossover pipe, if necessary.
  8. Remove the rear shock absorber lower bolts and nuts, if necessary.
  9. Lower the rear axle using the adjustable jack stands, if necessary.
  10. Remove the muffler to catalytic converter nuts.
  11. If the vehicle is a non heavy duty (HD), perform the following steps, otherwise proceed to step 14
  12. Lubricate the 4 insulators where the muffler assembly hangers are inserted in order to ease removal.
  13. With the aid of an assistant, remove the insulators (1-4) from the front, intermediate, and rear muffler assembly hangers and remove the muffler assembly.
  14. If the vehicle is a heavy duty (HD) perform the following steps
  15. Lubricate the 3 insulators where the muffler assembly hangers are inserted in order to ease removal.
  16. With the aid of an assistant, remove the insulators (1-3) from the front, intermediate, and rear muffler assembly hangers and remove the muffler assembly.
  1. If the vehicle is a non HD, perform the following steps, otherwise proceed to step 5
  2. Lubricate the 4 insulators where the muffler assembly hangers are inserted in order to ease installation.
  3. With the aid of an assistant, position and install the muffler assembly.
  4. Install the insulators (1-4) to the front, intermediate, and rear muffler assembly hangers.
  5. If the vehicle is a HD, perform the following steps
  6. Lubricate the 3 insulators where the muffler assembly hangers are inserted in order to ease installation.
  7. With the aid of an assistant, position and install the muffler assembly.
  8. Install the insulators (1-3) to the front, intermediate, and rear muffler assembly hangers.
  9. Install the catalytic converter to exhaust muffler nuts. Tighten: Tighten the nuts to 45 N.m (33 lb ft).
  10. Raise the rear axle using the adjustable jack stands, if necessary.
  11. Install the rear shock absorber lower bolts and nuts, if necessary. Tighten: Tighten the bolts to 95 N.m (70 lb ft).
  12. If equipped with a 10.5 inch ring gear, install the rear axle vent hose to the rear axle, if necessary.
  13. Connect the vent hose swivel clip to the rear brake crossover pipe, if necessary.
  14. If equipped with a 8.6 or a 9.5 inch ring gear, install the rear axle vent hose to the rear axle, if necessary.
  15. Install the vent hose swivel clip to the rear brake crossover pipe, if necessary.
  16. Remove the adjustable jack stands from under the rear axle, if necessary.
  17. Install the spare tire, if necessary.
  18. Lower the vehicle.
  1. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/silverado-1500/2007-2007/remont/hoistjack/#general-information) .
  2. Remove the spare tire, if necessary.
  3. Install adjustable jack stands under the rear axle, if necessary.
  4. If equipped with a 8.6 or a 9.5 inch ring gear, remove the rear axle vent hose from the rear axle, if necessary.
  5. Remove the vent hose swivel clip from the rear brake crossover pipe, if necessary.
  6. If equipped with a 10.5 inch ring gear, remove the rear axle vent hose from the rear axle, if necessary.
  7. Remove the vent hose swivel clip from the rear brake crossover pipe, if necessary.
  8. Remove the rear shock absorber lower bolts and nuts, if necessary.
  9. Lower the rear axle using the adjustable jack stands, if necessary.
  10. Remove the exhaust muffler to exhaust manifold pipe nuts (1).
  11. Loosen the exhaust muffler clamp (3).
  12. Remove the heated oxygen sensor (HO2S). Refer to «Heated Oxygen Sensor Replacement - Bank 2 Sensor 2 (1500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 2 (2500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 2 (2500 Series - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) .
  13. Lubricate the 4 insulators where the muffler assembly hangers are inserted in order to ease removal.
  14. With the aid of an assistant, remove the insulators (1-4) from the front, intermediate, and rear muffler assembly hangers and remove the muffler assembly.
  1. Lubricate the 4 insulators where the muffler assembly hangers are inserted in order to ease installation.
  2. With the aid of an assistant, position and install the muffler assembly.
  3. Install the insulators (1-4) to the front, intermediate, and rear muffler assembly hangers.
  4. Install the HO2S. Refer to «Heated Oxygen Sensor Replacement - Bank 2 Sensor 2 (1500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 2 (2500 Series)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) or «Heated Oxygen Sensor Replacement - Bank 2 Sensor 2 (2500 Series - Cab/Chassis)»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) .
  5. Tighten the exhaust muffler clamp (3). Tighten: Tighten the nuts to 47 N.m (35 lb ft).
  6. Install the exhaust muffler to exhaust manifold pipe nuts (1). Tighten: Tighten the nuts to 45 N.m (33 lb ft).
  7. Raise the rear axle using the adjustable jack stands, if necessary.
  8. Install the rear shock absorber lower bolts and nuts, if necessary. Tighten: Tighten the bolts to 95 N.m (70 lb ft).
  9. If equipped with a 10.5 inch ring gear, install the rear axle vent hose to the rear axle, if necessary.
  10. Connect the vent hose swivel clip to the rear brake crossover pipe, if necessary.
  11. If equipped with a 8.6 or a 9.5 inch ring gear, install the rear axle vent hose to the rear axle, if necessary.
  12. Install the vent hose swivel clip to the rear brake crossover pipe, if necessary.
  13. Remove the adjustable jack stands from under the rear axle, if necessary.
  14. Install the spare tire, if necessary.
  15. Lower the vehicle.
  1. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/silverado-1500/2007-2007/remont/hoistjack/#general-information) .
  2. Remove the spare tire, if necessary.
  3. Install adjustable jack stands under the rear axle, if necessary.
  4. Remove the rear axle vent hose from the rear axle, if necessary.
  5. Remove the vent hose swivel clip from the rear brake crossover pipe, if necessary.
  6. Remove the rear shock absorbers lower bolts and nuts, if necessary.
  7. Lower the rear axle using the adjustable jack stands, if necessary.
  8. Remove the exhaust muffler to exhaust particulate filter nuts (1).
  9. With the aid of an assistant, support the exhaust muffler.
  10. Remove the exhaust muffler hangers from the exhaust insulators (1).
  11. Remove the exhaust muffler. (2500/3500 crew cab shown, regular/extended cabs similar).
  12. Remove and discard the exhaust particulate filter to muffler gasket.
  1. Install a NEW gasket onto the exhaust muffler studs.
  2. Install the exhaust muffler to the particulate filter.
  3. With the aid of an assistant, support the exhaust muffler.
  4. Install the exhaust muffler hangers to the exhaust insulators (1).
  5. Install the exhaust muffler to exhaust particulate filter nuts (1). Tighten: Tighten the nuts to 45 N.m (33 lb ft).
  6. Raise the rear axle using the adjustable jack stands, if necessary.
  7. Install the rear shock absorbers lower bolts and nuts, if necessary. Tighten: Tighten the bolts to 95 N.m (70 lb ft).
  8. Install the rear axle vent hose to the rear axle, if necessary.
  9. Connect the vent hose swivel clip to the rear brake crossover pipe, if necessary.
  10. Remove the adjustable jack stands from under the rear axle, if necessary.
  11. Install the spare tire, if necessary.
  12. Lower the vehicle.
  1. Remove the catalytic converter. Refer to «Catalytic Converter Replacement (4.3L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (4.8L, 5.3L, 6.0L, 6.2L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (6.6L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  2. If vehicle has a regular cab, remove the exhaust heat shield nuts.
  3. Remove the exhaust front heat shield (1) and/or the rear exhaust heat shield (2) from the studs.
  4. If vehicle has extended cab, remove the exhaust heat shield nuts.
  5. Remove the exhaust front heat shield (1) and/or the rear exhaust heat shield (2) from the studs.
  6. If vehicle has a crew cab, remove the exhaust heat shield nuts.
  7. Remove the exhaust front heat shield (1) and/or the rear exhaust heat shield (2) from the studs.
  1. If vehicle has a crew cab, position and install the rear exhaust heat shield (2) and/or the front exhaust heat shield (1) to the underbody studs.
  2. Install the exhaust heat shield nuts. Tighten: Tighten the nuts to 9 N.m (80 lb in).
  3. If vehicle has a extended cab, position and install the rear exhaust heat shield (2) and/or the front exhaust heat shield (1) to the underbody studs.
  4. Install the exhaust heat shield nuts. Tighten: Tighten the nuts to 9 N.m (80 lb in).
  5. If vehicle has a regular cab, position and install the rear exhaust heat shield (2) and/or the front exhaust heat shield (1) to the studs.
  6. Install the exhaust heat shield nuts. Tighten: Tighten the nuts to 9 N.m (80 lb in).
  7. Install the catalytic converter. Refer to «Catalytic Converter Replacement (4.3L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (4.8L, 5.3L, 6.0L, 6.2L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) or «Catalytic Converter Replacement (6.6L)»(/chevrolet/silverado-1500/2007-2007/remont/exhaust/#engine-exhaust-system) .
  1. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/silverado-1500/2007-2007/remont/hoistjack/#general-information) .
  2. Remove the exhaust heat shield nuts.
  3. Remove the exhaust heat shield (1, 3) from the dash panel studs.
  4. If removing the heat shield (3), remove the shield out thru the passenger side wheelwell.
  1. If installing the heat shield (3), install the shield thru the passenger side wheelwell.
  2. Install the exhaust heat shield (1, 3) to the dash panel studs. NOTE: Refer to «Fastener Notice»(/chevrolet/silverado-1500/2007-2007/remont/oem-general-information/#warnings-and-cautions__fastener-notice) .
  3. Install the exhaust heat shield nuts. Tighten: Tighten the nuts to 9 N.m (80 lb in).
  4. Lower the vehicle.

Exhaust Manifold Heat Shield Replacement - Right Side (4.3L)

  1. Remove the spark plug wires. Refer to «Spark Plug Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) .
  2. Reposition the spark plug wires out of the way, if necessary.
  3. Remove the exhaust manifold heat shield bolts and heat shield from the exhaust manifold.
  1. Position the exhaust manifold heat shield to the exhaust manifold and install the heat shield bolts. Tighten: Tighten the bolts to 9 N.m (80 lb in).
  2. Install the spark plug wires. Refer to «Spark Plug Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) .

Exhaust Manifold Heat Shield Replacement - Right Side (4.8L, 5.3L, 6.0L, and 6.2L)

  1. Remove the right wheelhouse liner. Refer to «Front Wheelhouse Liner Replacement - Right Side (Chevrolet)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Wheelhouse Liner Replacement - Right Side (GMC)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  2. Remove the exhaust manifold heat shield bolts and heat shield from the exhaust manifold.
  1. Position the exhaust manifold heat shield to the exhaust manifold and install the heat shield bolts. Tighten: Tighten the bolts to 9 N.m (80 lb in).
  2. Install the right wheelhouse liner. Refer to «Front Wheelhouse Liner Replacement - Right Side (Chevrolet)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Wheelhouse Liner Replacement - Right Side (GMC)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  1. Remove the spark plug wires. Refer to «Spark Plug Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) .
  2. Reposition the spark plug wires out of the way, if necessary.
  3. Remove the exhaust manifold heat shield bolts and heat shield from the exhaust manifold.
  1. Position the exhaust manifold heat shield to the exhaust manifold and install the heat shield bolts. Tighten: Tighten the bolts to 9 N.m (80 lb in).
  2. Install the spark plug wires. Refer to «Spark Plug Replacement»(/chevrolet/silverado-1500/2007-2007/remont/testing-diagnostics/#engine-controls-and-fuel-48l-53l-60l-and-62l-introduction-2-of-2) .
  1. Remove the right wheelhouse liner. Refer to «Front Wheelhouse Liner Replacement - Right Side (Chevrolet)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Wheelhouse Liner Replacement - Right Side (GMC)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  2. Remove the exhaust manifold heat shield bolts and heat shield from the exhaust manifold.
  1. Position the exhaust manifold heat shield to the exhaust manifold and install the heat shield bolts. Tighten: Tighten the bolts to 9 N.m (80 lb in).
  2. Install the right wheelhouse liner. Refer to «Front Wheelhouse Liner Replacement - Right Side (Chevrolet)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Wheelhouse Liner Replacement - Right Side (GMC)»(/chevrolet/silverado-1500/2007-2007/remont/frames-subframes-crossmembers/#frame-and-underbody) .

Exhaust System Description

IMPORTANTUse of non-OEM parts may cause driveability concerns.

The exhaust system carries exhaust gases, treated by the catalytic converter, through the muffler and into a resonator, if applicable where exhaust noise is lessened.

In order to secure the exhaust muffler assembly to the exhaust manifold, a flange and seal-joint coupling is utilized. The exhaust system may utilize a slip-joint coupling design with a clamp and a U-bolt or a flange connection with a gasket.

Exhaust hangers and rubber insulators help to support the weight of the exhaust system along with insulating any exhaust system vibration, rattle, or noise.

Exhaust hangers also space the exhaust system away from the underbody of the vehicle and allows the exhaust system to expand as the exhaust system warms up.

Exhaust heat shields are used to protect the underbody and other components from damage due to the heat from the exhaust system.

The exhaust system may be comprised of the following components

  1. Catalytic converter
  2. Exhaust hanger
  3. Exhaust heat shield
  4. Exhaust insulator
  5. Exhaust manifold
  6. Exhaust muffler
  7. Exhaust pipe
  8. Exhaust resonator, if equipped
  9. Exhaust tail pipe, if equipped

Catalytic Converter

The catalytic converter is an emission control device added to the engine exhaust system in order to reduce hydrocarbons (HC), carbon monoxide (CO), and oxides of nitrogen (NOx) pollutants from the exhaust gas.

The catalytic converter is comprised of a ceramic monolith substrate, supported in insulation and housed within a sheet metal shell. The substrate may be washcoated with 3 noble metals

  1. Palladium (Pd)
  2. Platium (Pt)
  3. Rhodium (Rh)

The catalyst in the converter is not serviceable.

Muffler

The exhaust muffler reduces the noise levels of the engine exhaust by the use of tuning tubes. The tuning tubes create channels inside the exhaust muffler that lower the sound levels created by the combustion of the engine.

Resonator

Some exhaust systems may be equipped with a resonator. The resonator, located either before or after the muffler, allows the use of mufflers with less back pressure. Resonators are used when vehicle characteristics require specific exhaust tuning.

Special Tools

Special Tools Illustration Tool Number/ Description J 35314-A/BT-8515/BT-8515A Exhaust Back Pressure Tester J 38185 Hose Clamp Pliers

Scheme 1

Scheme 1: Special Tools
Scheme 1: Special Tools
