Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Plenum Reinforcement Panel Bolts | 9 N.m | 80 lb in |
| Washer Solvent Container Bolts | 9 N.m | 80 lb in |
| Wiper Arm to the Shaft Nut | 30 N.m | 22 lb ft |
| Wiper Motor Assembly Bolts | 8 N.m | 71 lb in |
| Wiper Motor Cover Screws | 2.6 N.m | 23 lb in |
| Wiper Transmission to the Vehicle Bolts | 9 N.m | 80 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 2
Scheme 3
| Callout | Component Name |
|---|---|
| 1 | Windshield Wiper Motor Module Electrical Connector |
| 2 | Cruise Control Module Electrical Connector |
| 3 | Plenum Panel |
| 4 | Cruise Control Module |
| 5 | Pass - Through 100 (P100) |
| 6 | Dash Panel |
| 7 | Cap For Connector, Without Cruise Control |
| 8 | Cruise Control Module Electrical Connector |
| 9 | Harness - Pass Through |
| 10 | Windshield Wiper Motor Module |
Callouts For (Scheme 3)
Scheme 4
| Callout | Component Name |
|---|---|
| 1 | Forward Lamp Harness |
| 2 | Windshield Washer Reservoir |
| 3 | Windshield Washer Fluid Pump Connector |
| 4 | Washer Fluid Level Switch |
| 5 | Radiator Support |
Callouts For (Scheme 4)
Scheme 5
| Callout | Component Name |
|---|---|
| 1 | Hazard Button |
| 2 | Multi-Function Lever |
| 3 | Cruise Control Switches |
| 4 | Tilt Steering Actuator |
| 5 | Inflatable Restraint Harness |
| 6 | C201 Inline Connector |
Callouts For (Scheme 5)
