Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Cargo/Stop Lamp Mounting Screws | 2 N.m | 18 lb in |
| Center High-Mounted Stop Lamp Mounting Screws | 2 N.m | 18 lb in |
| Exterior Courtesy Lamp Screws | 2 N.m | 18 lb in |
| Fog Lamp Bracket Bolt | 25 N.m | 18 lb ft |
| Mounting Bracket Screws | 15 N.m | 11 lb ft |
| Tail/Turn Signal Lamp Assembly Screws | 2 N.m | 18 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
Scheme 31
Scheme 32
| Callout | Component Name |
|---|---|
| 1 | Headlamp - High Beam - Right |
| 2 | Daytime Running Lamp (DRL) - Right |
| 3 | Exterior Illumination Lamp |
| 4 | Headlamp - High Beam - Left |
| 5 | Headlamp - Low Beam - Left |
| 6 | Marker Lamp - LF |
| 7 | Park/Turn Signal Lamp - LF |
| 8 | Daytime Running Lamp (DRL) - Left |
| 9 | Fog Lamp - LF |
| 10 | Fog Lamp - RF |
| 11 | Marker Lamp - RF |
| 12 | Park/Turn Signal Lamp - RF |
| 13 | Headlamp - Low Beam - Right |
Callouts For (Scheme 32)
Scheme 33
| Callout | Component Name |
|---|---|
| 1 | Roof Marker Lamp and Harness - Right |
| 2 | Roof Marker Lamp and Harness - Left |
| 3 | Clearance Lamps and Harness |
Callouts For (Scheme 33)
Scheme 34
| Callout | Component Name |
|---|---|
| 1 | Brake/Clutch Harness |
| 2 | Fuse Block - Underhood |
| 3 | Emergency Vehicle Roof Lamp Relay |
| 4 | C160 |
| 5 | C119 |
| 6 | C161 |
| 7 | Chassis Harness |
Callouts For (Scheme 34)
Scheme 35
| Callout | Component Name |
|---|---|
| 1 | Frame |
| 2 | Junction Block-Rear Lamps |
| 3 | Junction Block Mounting Bracket |
Callouts For (Scheme 35)
Scheme 36
| Callout | Component Name |
|---|---|
| 1 | Instrument Panel Bracket |
| 2 | Ambient Light Sensor Harness (CJ3) or Ambient Light/Sunload Sensor Harness (CJ2) |
| 3 | Ambient Light Sensor Connector (CJ3) or Ambient Light/Sunload Sensor Assembly Connector (CJ2) |
| 4 | Ambient Light Sensor (CJ3) or Ambient Light/Sunload Sensor Assembly (CJ2) |
| 5 | Instrument Panel |
Callouts For (Scheme 36)
Scheme 37
| Callout | Component Name |
|---|---|
| 1 | Hazard Button |
| 2 | Multifunction Lever |
| 3 | Cruise Control Switches |
| 4 | Tilt Steering Actuator |
| 5 | Inflatable Restraint Harness |
| 6 | C201 Inline Connector |
Callouts For (Scheme 37)
Scheme 38
| Callout | Component Name |
|---|---|
| 1 | Vacuum Booster |
| 2 | Brake Pedal |
| 3 | Stop Lamp Switch |
| 4 | Accelerator Pedal |
| 5 | Stop Lamp Switch Retainer |
| 6 | Dash Panel |
Callouts For (Scheme 38)
Scheme 39
| Callout | Component Name |
|---|---|
| 1 | Vanity Mirror Lamp - Left Connector |
| 2 | Left Sunshade |
| 3 | Right Sunshade |
| 4 | Vanity Mirror Lamp - Right Connector |
| 5 | Vanity Mirror Lamp - Right |
| 6 | Inside Rearview Mirror |
| 7 | Vanity Mirror Lamp - Left |
Callouts For (Scheme 39)
Scheme 40
| Callout | Component Name |
|---|---|
| 1 | Cellular Microphone |
| 2 | Courtesy/Reading Lamps - Front |
| 3 | C355 |
| 4 | Cellular Microphone Connector |
| 5 | Overhead Console |
Callouts For (Scheme 40)
Scheme 41
| Callout | Component Name |
|---|---|
| 1 | Automatic Transfer Case (ATC) Electrical Connector |
| 2 | Automatic Transfer Case (ATC) Electrical Connector |
| 3 | Automatic Transfer Case (ATC) Select Switch |
| 4 | Cargo/Fog Lamp Switch |
| 5 | Headlamp and Panel Dimmer Switch |
| 6 | Instrument Panel |
| 7 | Headlamp and Panel Dimmer Switch Electrical Connector |
| 8 | Cargo/Fog Lamp Switch Electrical Connector |
Callouts For (Scheme 41)
Scheme 42
| Callout | Component Name |
|---|---|
| 1 | Fog Lamp Switch (Export) |
| 2 | Roof Beacon Switch (5X7, 5Y0, 5G4, or TRW) |
| 2 | Roof Beacon Switch (5X7, 5Y0, 5G4, or TRW) |
| 3 | Accessory Switch Housing |
| 3 | Accessory Switch Housing |
| 4 | Instrument Panel |
Callouts For (Scheme 42)
Scheme 43
| Callout | Component Name |
|---|---|
| 1 | Vehicle Speed Sensor |
| 2 | NV 3500 Transmission |
| 3 | Oxygen Sensor Downstream Connector |
| 4 | Backup Lamp Switch |
| 5 | Oxygen Sensor Upstream Connector |
Callouts For (Scheme 43)
Scheme 44
| Callout | Component Name |
|---|---|
| 1 | Door Courtesy Lamp Electrical Connector |
| 2 | Door Courtesy Lamp |
| 3 | Driver Door |
Callouts For (Scheme 44)
Scheme 45
| Callout | Component Name |
|---|---|
| 1 | LR Fender |
| 2 | Clearance Lamp - LR |
| 3 | Clearance Lamp - LF |
Callouts For (Scheme 45)
Scheme 46
| Callout | Component Name |
|---|---|
| 1 | Right Rear Fender |
| 2 | Clearance Lamp - Right Front |
| 3 | Clearance Lamp - Right Rear |
Callouts For (Scheme 46)
Scheme 47
| Callout | Component Name |
|---|---|
| 1 | Tail/Stop Lamp - Left |
| 2 | Cargo Lamp |
| 3 | Center High Mounted Stop Lamp (CHMSL) |
| 4 | Cargo Lamp |
| 5 | Tail/Stop Lamp - Right |
| 6 | Turn Signal Lamp - RR |
| 7 | Backup Lamp - Right |
| 8 | Marker Lamp - RR |
| 9 | License Lamp - Right |
| 10 | License Lamp - Left |
| 11 | Marker Lamp - LR |
| 12 | Backup Lamp - Left |
| 13 | Turn Signal Lamp - LR |
Callouts For (Scheme 47)
Scheme 48
| Callout | Component Name |
|---|---|
| 1 | Frame |
| 2 | License Lamp Electrical Connector |
| 3 | License Lamp |
Callouts For (Scheme 48)
Scheme 49
| Callout | Component Name |
|---|---|
| 1 | Marker Lamp - Tail Gate |
| 2 | Tail Gate |
Callouts For (Scheme 49)
Scheme 50
| Callout | Component Name |
|---|---|
| 1 | Trailer Wiring Connector |
| 2 | Trailer Wiring Receptacle |
| 3 | Frame |
| 4 | Trailer Hitch Receiver |
Callouts For (Scheme 50)
Scheme 51
| Callout | Component Name |
|---|---|
| 1 | Backup Alarm |
| 2 | Chassis Harness |
| 3 | C429 Trailer Harness to Chassis Harness |
| 4 | Trailer Connector |
| 5 | Junction Block-Rear |
| 6 | C428 Trailer Harness to Chassis Harness |
| 7 | Camper Harness (Blunt Cuts) |
Callouts For (Scheme 51)
Ambient Light Sensor (CJ3) Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A WH 278 Ambient Light Sensor Signal B BK 279 Ambient Light Sensor Low Reference
Ambient Light/Sunload Sensor Assembly (CJ2) Connector Part Information 12064760 4-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A L-BU/BK 590 Driver Sunload Sensor Signal B GY 1548 Passenger Sunload Sensor Signal C BK 279 Ambient Light Sensor Low Reference D WH 278 Ambient Light Sensor Signal
Backup Alarm (8S3) Connector Part Information 15300027 2-Way F Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function A L-GN 1624 Trailer Backup Lamp Supply Voltage B BK 1650 Ground
Backup Lamp - Left Connector Part Information 12160393 2-Way Lamp Socket Wedge Base W3 Right Angle (L-GY) Pin Wire Color Circuit No. Function A L-GN 24 Backup Lamp Supply Voltage (Z88) D-GN 24 Backup Lamp Supply Voltage (X88) B - - Not Available G BK 1750 Ground (X88) BK 1750 Ground
Backup Lamp - Right Connector Part Information 12160393 2-Way Lamp Socket Wedge Base W3 Right Angle (L-GY) Pin Wire Color Circuit No. Function A L-GN 24 Backup Lamp Supply Voltage (Z88) D-GN 24 Backup Lamp Supply Voltage (X88) B - - Not Available G BK 1750 Ground (X88) BK 1750 Ground
Backup Lamp - Switch (M/T) Connector Part Information 12103584 2-Way M Weather Pack (BK) Pin Wire Color Circuit No. Function A PK 839 Ignition 1 Voltage B GY 1524 Backup Lamp Supply Voltage
Cargo Lamp/Center High Mounted Stop Lamp (CHMSL) Connector Part Information 12047785 4-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A OG 1732 Inadvertent Power Supply Voltage B D-BU/WH 149 Cargo Lamp Low Control C L-BU 1620 Trailer CHMSL Supply Voltage D BK 1050 Ground
Clearance Lamp - LF (RO5) Connector Part Information 12052641 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BN 2509 Left Rear Park Lamps Supply Voltage B BK 1750 Ground
Clearance Lamp - LR (RO5) Connector Part Information 12052641 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BN 2509 Left Rear Park Lamps Supply Voltage B BK 1750 Ground
Clearance Lamp - RF (RO5) Connector Part Information 12052641 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BN/WH 2609 Right Rear Park Lamps Supply Voltage B BK 1750 Ground
Clearance Lamp - RR (RO5) Connector Part Information 12052641 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BN/WH 2609 Right Rear Park Lamps Supply Voltage B BK 1750 Ground
Clearance Lamps (U01) Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BN 2409 Interior Park Lamps Supply Voltage B BK 1050 Ground
Courtesy/Reading Lamp - Rear (Crew Cab w/YE9 or Y91) Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A GY/BK 690 Courtesy Lamp Supply Voltage B BK 1050 Ground C OG 1732 Inadvertent Power Supply Voltage
Daytime Running Lamp (DRL) - Left Connector Part Information 15354859 2-Way F Lamp Socket BB W-3 (WH) Pin Wire Color Circuit No. Function A D-BU 545 DRL Supply Voltage G BK 150 Ground
Daytime Running Lamp (DRL) - Right Connector Part Information 15354859 2-Way F Lamp Socket BB W-3 (WH) Pin Wire Color Circuit No. Function A D-BU 545 DRL Supply Voltage G BK 150 Ground
Dome Lamp - Rear (Except Crew Cab w/YE9 or Y91) Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A GY/BK 690 Courtesy Lamps Supply Voltage B BK 1050 Ground C - - Not Used
Door Courtesy Lamp - LF (YE9 or Y91) Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A D-BU/WH 149 Left Door Courtesy Lamp Supply Voltage B D-BU 660 Left Door Courtesy Lamp Ground
Door Courtesy Lamp - RF (YE9/Y91) Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A WH 156 Courtesy Lamp Low Control B L-BU 661 Right Door Courtesy Lamp Ground
Door Latch Assembly (Door Jamb Switch) - Driver - C2 Connector Part Information 15366025 3-Way F GT 150 Series Sealed 3.2 X 4.0 (BK) Pin Wire Color Circuit No. Function A - - Not Available B GY/BK 745 Left Front Door Ajar Switch Signal C - - Not Available D BK 1050 Ground (w/o YE9) BN 1183 Left Front Door Switch Low Reference (YE9)
Door Latch Assembly (Door Jamb Switch) - LR - C2 (Crew Cab Only) Connector Part Information 15366025 2-Way F GT 150 Series Sealed 3.2 X 4.0 (BK) Pin Wire Color Circuit No. Function A - - Not Available B L-BU/BK 747 Left Rear Door Ajar Switch Signal C - - Not Available D BK 1150 Ground
Door Latch Assembly (Door Jamb Switch) - Passenger - C2 Connector Part Information 15366027 2-Way F GT 150 Series Sealed 3.2 X 4.0 (BK) Pin Wire Color Circuit No. Function A D-GN 1178 Right Front Door Switch Low Reference (w/YE9) BK 1050 Ground (w/o YE9) B - - Not Available C BK/WH 746 Right Front Door Ajar Switch Signal D - - Not Available
Door Latch Assembly (Door Jamb Switch) - RR - C2 (Crew Cab Only) Connector Part Information 15366025 2-Way F GT 150 Series Sealed 3.2 X 4.0 (BK) Pin Wire Color Circuit No. Function A - - Not Available B L-GN/BK 748 Right Rear Door Ajar Switch Signal C - - Not Available D BK 1250 Ground
Emergency Vehicle Roof Lamp Relay (5Y0) Connector Part Information 12129716 4-Way F Metri-Pack 150 Series Sealed (GY) Pin Wire Color Circuit No. Function 30 RD 242 Battery Positive Voltage 85 WH 111 Hazard Switch Signal 86 BK 1850 Ground 87 BN 27 Hazard Flasher Signal
Fog Lamp - LF Connector Part Information 12059183 2-Way F Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function A PU 34 Fog Lamps Supply Voltage B BK 150 Ground
Fog Lamp - RF Connector Part Information 12059183 2-Way F Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function A PU 34 Fog Lamps Supply Voltage B BK 150 Ground
Headlamp - High Beam - Left Connector Part Information 12059183 2-Way F Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function A D-GN/WH 711 Left Headlamp High Beam Supply Voltage B BK 550 Ground
Headlamp - High Beam - Right Connector Part Information 12059183 2-Way F Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function A L-GN/BK 311 Right Headlamp High Beam Supply Voltage B BK 150 Ground
Headlamp - Low Beam - Left Connector Part Information 12059181 2-Way F Metri-Pack 280 Series Sealed (GY) Pin Wire Color Circuit No. Function A YE 712 Left Headlamp Low Beam Supply Voltage B BK 550 Ground
Headlamp - Low Beam - Right Connector Part Information 12059181 2-Way F Metri-Pack 280 Series Sealed (GY) Pin Wire Color Circuit No. Function A TN/WH 312 Right Headlamp Low Beam Supply Voltage B BK 150 Ground
Headlamp Switch Connector Part Information 15405512 14-Way F (GN) Pin Wire Color Circuit No. Function 1 PU 328 Interior Lamp Defeat Switch Signal 2 GY/BK 308 Park Lamp Switch On Signal 3 BK/WH 1851 Ground 4 WH 103 Headlamp Switch Headlamps On Signal 5 D-GN 588 DRL Switch Signal 6 BK 1050 Ground 7 PK 1348 Headlamp ON Indicator Control 8 PU 359 DRL OFF Indicator Control 9 PU/WH 1382 LED Dimming Supply 10 D-BU/WH 1495 Courtesy Lamp ON Signal 11 OG/BK 2090 Dimming Input 12 GY/BK 2226 Dimming Return 13 GY 1056 5-Volt Reference 14 BN/WH 230 Instrument Panel Lamps Dimming Control
Junction Block - Rear Lamps - C1 Connector Part Information 15317304 8-Way F Global Tech 280 Series (BU) Pin Wire Color Circuit No. Function A L-BU 2114 Left Turn Signal Lamps Supply Voltage B L-BU 1320 CHMSL Supply Voltage C L-GN 24 Backup Lamp Supply Voltage D BN/WH 2609 Right Rear Park Lamps Supply Voltage E BK 1550 Ground (30 Series Except Chassis Cab/20 Series w/HVY) 1650 Ground (30 Series Chassis Cab) 1750 Ground (10/20) Series F - - Not Used G BN 2509 Left Rear Park Lamps Supply Voltage H D-BU 2115 Right Turn Signal Lamps Supply Voltage
Junction Block - Rear Lamps - C2 Connector Part Information 15317305 7-Way F Global Tech 280 Series (GY) Pin Wire Color Circuit No. Function A BK 1750 Ground B BK 1750 Ground (Z88) C BK 1750 Ground (Z88) D L-BU 1320 CHMSL Supply Voltage E BN 2509 Left Rear Park Lamps Supply Voltage F D-GN 24 Backup Lamp Supply Voltage (X88) L-GN 24 Backup Lamp Supply Voltage (Z88) G - - Unavailable H D-BU 2114 Left Turn Signal Lamps Supply Voltage (X88) L-BU 2114 Left Turn Signal Lamps Supply Voltage (Z88)
Junction Block - Rear Lamps - C3 Connector Part Information 15317308 8-Way F Global Tech 280 Series (BN) Pin Wire Color Circuit No. Function A BN/WH 2609 Right Rear Park Lamps Supply Voltage B - - Not Used C BK 1750 Ground (RO5) D BK 1750 Ground (03/43/53/RO5) E BK 1750 Ground (w/o RO5) F - - Not Used G BN 2509 Left Rear Park Lamps Supply Voltage H BK 1750 Ground
Junction Block - Rear Lamps - C4 Connector Part Information 15317306 7-Way F Global Tech 280 Series (BK) Pin Wire Color Circuit No. Function A L-BU 1320 CHMSL Supply Voltage B BN 2609 Right Rear Park Lamps Supply Voltage (X88) BN/WH 2609 Right Rear Park Lamps Supply Voltage (Z88) C BK 1750 Ground D BK 1750 Ground (Z88) E D-GN 24 Backup Lamp Supply Voltage (X88) L-GN 24 Backup Lamp Supply Voltage (Z88) F D-BU 2115 Right Turn Signal Lamps Supply Voltage G - - Unavailable H BK 1750 Ground (Z88)
License Lamp - Left Connector Part Information 15324946 2-Way F Lamp Socket Wedge Base (GY) Pin Wire Color Circuit No. Function A BN 2509 Left Rear Park Lamps Supply Voltage B BK 1750 Ground
License Lamp - Right Connector Part Information 15324946 2-Way F Lamp Socket Wedge Base (GY) Pin Wire Color Circuit No. Function A BN/WH 2609 Right Rear Park Lamps Supply Voltage (w/o RO5) 2509 Left Rear Park Lamps Supply Voltage (RO5) B BK 1750 Ground
Marker Lamp - LF Connector Part Information 15324946 2-Way F Lamp Socket Wedge Base (GY) Pin Wire Color Circuit No. Function A L-BU 2114 Left Turn Signal Lamps Supply Voltage B BN 2309 Front Park Lamps Supply Voltage
Marker Lamp - LR (X88) Connector Part Information 15324946 2-Way F Lamp Socket Wedge Base (GY) Pin Wire Color Circuit No. Function A BN - Left Rear Park Lamps Supply Voltage BN - Left Rear Park Lamps Supply Voltage B D-BU - Left Turn Signal Lamps Supply Voltage D-BU - Left Turn Signal Lamps Supply Voltage
Marker Lamp - RF Connector Part Information 15324946 2-Way F Lamp Socket Wedge Base (GY) Pin Wire Color Circuit No. Function A D-BU 2115 Right Turn Signal Lamps Supply Voltage B BN 2309 Front Park Lamps Supply Voltage
Marker Lamp - RR (X88) Connector Part Information 15324946 2-Way F Lamp Socket Wedge Base (GY) Pin Wire Color Circuit No. Function A BN - Right Rear Park Lamps Supply Voltage BN - Right Rear Park Lamps Supply Voltage B D-BU - Right Turn Signal Lamps Supply Voltage D-BU - Right Turn Signal Lamps Supply Voltage
Marker Lamp - Tailgate (RO5) Connector Part Information 12010973 2-Way M Weather Pack (BK) Pin Wire Color Circuit No. Function A BN 2609 Right Rear Park Lamps Supply Voltage B BK 1750 Ground
Multifunction Accessory Switch Connector Part Information 15393435 10-Way F Micro 64 (BK) Pin Wire Color Circuit No. Function A PU/WH 1382 LED Dimming Supply (T96) B D-GN/WH 1317 Fog Lamp Relay Control (T96) C OG 192 Front Fog Lamp Switch Signal (T96) D BK/WH 1851 Ground E BN/WH 230 Instrument Panel Lamps Dimming Control F D-BU/WH 149 Cargo Lamp Low Control G-K - - Not Used
Park/Turn Signal Lamp - LF Connector Part Information 15324084 Bulb Type W-3, Right Angle (BN) Pin Wire Color Circuit No. Function A L-BU 2114 Left Turn Signal Lamps Supply Voltage B BN 2309 Front Park Lamps Supply Voltage G BK 150 Ground
Park/Turn Signal Lamp - RF Connector Part Information 15324084 Bulb Type W-3, Right Angle (BN) Pin Wire Color Circuit No. Function A D-BU 2115 Right Turn Signal Lamps Supply Voltage B BN 2309 Front Park Lamps Supply Voltage G BK 150 Ground
Roof Beacon Relay (5G4/TRW) Connector Part Information 12110541 6-Way F Metri-Pack 280 Series Flexlock (BK) Pin Wire Color Circuit No. Function A1 BK 2351 Ground (All Others) BK 1150 Ground (Crew Cab) A2 BN 27 Hazard Flasher Signal B1-B2 - - Not Used C1 OG 2340 Battery Positive Voltage C2 WH 111 Hazard Switch Signal
Roof Beacon Switch (5X7, 5G4, TRW, or 5Y0) Connector Part Information 12177195 6-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A - - Not Used B BK 2250 Ground C WH 111 Hazard Switch Signal D PU/WH 1382 LED Dimming Signal E GY 8 Instrument Panel Lamp Supply Voltage F OG 2240 Battery Positive Voltage
Roof Marker Lamp - Left (U01) Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BN 2409 Interior Park Lamps Supply Voltage B BK 1050 Ground
Roof Marker Lamp - Right (U01) Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BN 2409 Interior Park Lamps Supply Voltage B BK 1050 Ground
Stop Lamp Switch Connector Part Information 12040551 6-Way F Metri-Pack 480 Series (BK) Pin Wire Color Circuit No. Function A WH 17 Stop Lamp Switch Signal B OG 1540 Battery Positive Voltage C BN 441 Ignition 3 Voltage D PU 420 TCC Brake Switch Signal E L-GN/BK 584 A/T Shift Lock Control Switch Supply Voltage F D-GN/WH 1135 A/T Shift Lock Control Solenoid Supply Voltage
Tail/Stop Lamp - Left (Chevy) Connector Part Information 12160395 3-Way Lamp Socket Wedge Base W3 Right Angle (GY) Pin Wire Color Circuit No. Function A L-BU 1320 Stop Lamp Supply Voltage B BN 2509 Left Rear Park Lamps Supply Voltage G BK 1750 Ground
Tail/Stop Lamp - Left (GMC) Connector Part Information 12160395 3-Way Lamp Socket Wedge Base W3 Right Angle (GY) Pin Wire Color Circuit No. Function A L-BU 1320 Stop Lamp Supply Voltage B BN 2509 Left Rear Park Lamps Supply Voltage G BK 1750 Ground
Tail/Stop Lamp - Right (Chevy) Connector Part Information 12160395 3-Way Lamp Socket Wedge Base W3 Right Angle (BK) Pin Wire Color Circuit No. Function A L-BU 1320 Stop Lamp Supply Voltage B BN 2509 Right Rear Park Lamps Supply Voltage G BK 1750 Ground
Tail/Stop Lamp - Right (GMC) Connector Part Information 12160395 3-Way Lamp Socket Wedge Base W3 Right Angle (GY) Pin Wire Color Circuit No. Function A L-BU 1320 Stop Lamp Supply Voltage B BN 2609 Right Rear Park Lamps Supply Voltage G BK 1750 Ground
Trailer Connector (1-Way) - (Heavy Duty) Connector Part Information 12065171 1-Way F Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function A L-BU 1620 Stop Lamp Switch Signal
Trailer Connector (1-Way) - (UY2) Connector Part Information 12065171 1-Way M Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function A L-BU 1620 Stop Lamp Switch Signal
Trailer Connector (7-Way) - (Heavy Duty or UY2) Connector Part Information 15354653 7-Way F Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function A L-GN 1624 Trailer Backup Lamps Supply Voltage B BK 1550 Ground (30 Series Except Chassis Cab) 1650 Ground (30 Series Chassis Cab) 1750 Ground (10/20 Series) WH 22 Ground (UY2) C D-BU 47 Trailer Auxiliary Supply Voltage D D-GN 1619 Trailer Right Rear Turn/Stop Lamp Supply Voltage E RD 742 Battery Positive Voltage F BN 2109 Trailer Park Lamps Supply Voltage G YE 1618 Trailer Left Rear Turn/Stop Lamp Supply Voltage
Turn Signal - LR (Chevy) Connector Part Information 12160394 2-Way Lamp Socket Wedge Base W3 Right Angle (BK) Pin Wire Color Circuit No. Function A D-BU 2114 Left Turn Signal Lamps Supply Voltage B - - Unavailable G BK 1750 Ground BK 1750 Ground
Turn Signal - LR (GMC) Connector Part Information 12160394 2-Way Lamp Socket Wedge Base W3 Right Angle (WH) Pin Wire Color Circuit No. Function A L-BU 2114 Left Turn Signal Lamps Supply Voltage B - - Not Used G BK 1750 Ground
Turn Signal - RR (Chevy) Connector Part Information 12160394 2-Way Lamp Socket Wedge Base W3 Right Angle (BK) Pin Wire Color Circuit No. Function A D-BU 2114 Right Turn Signal Lamps Supply Voltage B - - Unavailable G BK 1750 Ground BK 1750 Ground
Turn Signal - RR (GMC) Connector Part Information 12160394 2-Way Lamp Socket Wedge Base W3 Right Angle (WH) Pin Wire Color Circuit No. Function A L-BU 2115 Right Turn Signal Lamps Supply Voltage B - - Unavailable G BK 1750 Ground
Turn Signal Multifunction Switch - C1 Connector Part Information 12064862 8-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A L-GN 1427 Right Turn Signal Switch Signal B PK 639 Ignition 1 Voltage C D-GN 1428 Left Turn Signal Switch Signal D-F - - Not Used G BK/YE 28 Horn Relay Control H WH 111 Hazard Switch Signal
Turn Signal Multifunction Switch - C2 Connector Part Information 12059800 5-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A TN 1851 Ground B YE/BK 307 Headlamp Switch Flash to Pass Signal C L-GN/BK 11 Headlamp Dimmer Switch Signal D-E - - Not Used
Turn Signal Multifunction Switch - C3 Connector Part Information 15339058 7-Way F Metri-Pack 150 Series (GY) Pin Wire Color Circuit No. Function G - - Not Used H PK 94 Windshield Wiper Switch Signal 1 J YE 143 Windshield Wiper Switch Supply Voltage K D-BU/WH 477 Windshield Wiper Switch High Signal L-N - - Not Used
Turn Signal Multifunction Switch - C4 (K34) Connector Part Information 12047786 4-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BN 41 Ignition 3 Voltage B GY/WH 397 Cruise Control On Switch Signal C GY/BK 87 Cruise Control Resume/Accel Switch Signal D D-BU 84 Cruise Control Set/Coast Switch Signal
Vanity Mirror Lamp - Left (Y91) Connector Part Information 12047663 2-Way M Metri-Pack 150 Series Sealed (BK) Pin Wire Color Circuit No. Function A OG 1732 Inadvertent Power Supply Voltage B BK 1050 Ground
Vanity Mirror Lamp - Right (Y91) Connector Part Information 12047663 2-Way M Metri-Pack 150 Series Sealed (BK) Pin Wire Color Circuit No. Function A OG 1732 Inadvertent Power Supply Voltage B BK 1050 Ground
Wrecker Relay (5X7) Connector Part Information 12047663 2-Way F Metri-Pack 150 Series Sealed (BK) Pin Wire Color Circuit No. Function A WH 111 Hazard Switch Signal B BK 1050 Ground
