Automatic Transmission - 4L80-E/4L85-E - Overhaul: Specifications Chevrolet Silverado 1500

Automatic Trans 24 illustrations ~578 words

Fastener Tightening Specifications

ApplicationRef No.*QtySizeSpecification
MetricEnglish
Accumulator Housing to Valve Body536M6x1.0x10011 N.m97 lb in
Case Center Support2513/8-16x27.243 N.m32 lb ft
Control Valve Body to Case3521M6x1.0x5511 N.m97 lb in
Cooler Pipe Connector Nut to Case9021/4-18NPS(SPL)38 N.m28 lb ft
Extension Housing to Case216M10x1.50x3034 N.m25 lb ft
Flywheel to ConvertorN/A6M10x1.5x2343 N.m32 lb ft
Fourth Clutch Housing2615/16-18x24.423 N.m17 lb ft
Line Pressure Test Hole Plug2411/8-27NPTFx15.811 N.m97 lb ft
Manual Shaft Detent Lever Nut7121M10x1.50x10.824 N.m18 lb ft
Oil Drain Plug791M12x1.75x19.334 N.m25 lb ft
Oil Pan to Case2717M8x1.25x2024 N.m18 lb ft
Parking Pawl Bracket to Case7141M8x1.25x2024 N.m18 lb ft
Pressure Control Solenoid Bracket to Valve Body3101M6x1.0x19.68 N.m71 lb in
Pump Assembly to Case38M8x1.25x6324 N.m18 lb ft
Pump Body to Cover2205M8x1.25x4024 N.m18 lb ft
Rear Servo Cover to Case616M8x1.25x2024 N.m18 lb ft
Solenoid to Valve Body3102M6x1.0x19.68 N.m71 lb in
Speed Sensor Bracket to Case232M6x1.0x1411 N.m97 lb in
Valve Body to Case/Lube Pipe352M6x1.0x3511 N.m97 lb in
Valve Body to Case/TFP766M6x1.0x5511 N.m97 lb in
* Reference Number refers to the callout number on the disassembled view.

Fastener Tightening Specifications

Fluid Capacity Specifications (Overhaul)

ApplicationSpecification
MetricEnglish
Oil Pan Removal7.3 liters7.7 quarts
Overhaul12.8 liters13.5 quarts

Fluid Capacity Specifications (Overhaul)

End Play Specifications

ApplicationSpecification
MetricEnglish
Front End Play0.102-0.559 mm0.004-0.022 in
Output Carrier Pinion Gear End Play0.228-0.610 mm0.009-0.024 in
Overdrive Carrier Pinion Gear End Play0.2032-0.6350 mm0.008-0.025 in
Reaction Drum and Carrier Assembly Pinion Gear End Play0.228-0.610 mm0.009-0.024 in
Rear End Play0.127-0.508 mm0.005-0.020 in
Torque Converter End Play0.0-0.38 mm0.0-0.015 in

End Play Specifications

Overrun Clutch Housing Selective Thrust Washer Specifications

ColorSpecification
MetricEnglish
Blue1.448-1.549 mm0.057-0.061 in
Red1.854-1.956 mm0.073-0.077 in
Brown2.261-2.362 mm0.089-0.093 in
Green2.667-2.769 mm0.105-0.109 in
Black3.073-3.175 mm0.121-0.125 in

Overrun Clutch Housing Selective Thrust Washer Specifications

Output Shaft Selective Thrust Washer Specifications

Identification NotchNumeralSpecification
MetricEnglish
None11.880-1.981 mm0.074-0.078 in
On the side of 1 tab22.083-2.184 mm0.082-0.086 in
On the side of 2 tabs32.286-2.388 mm0.090-0.094 in
On the end of 1 tab42.489-2.591 mm0.098-0.102 in
On the end of 2 tabs52.692-2.794 mm0.106-0.110 in
On the end of 3 tabs62.896-2.997 mm0.114-0.118 in

Output Shaft Selective Thrust Washer Specifications

Oil Pump Specifications

SpecificationSpecification
MetricEnglish
Oil Pump Gear Clearance0.017-0.071 mm0.0008-0.0028 in

Oil Pump Specifications

Transmission General Specifications

SpecificationSpecification
MetricEnglish
Direct Clutch Piston Travel Specification1.27-4.369 mm0.050-0.172 in
Intermediate Clutch Piston Travel Specification1.02-2.72 mm0.040-0.107 in
Forward Clutch Piston Travel Specification1.27-4.369 mm0.050-0.172 in
Overrun Clutch Piston Travel Specification0.838-2.38 mm0.033-0.094 in
Fourth Clutch Piston Travel Specification1.016-2.540 mm0.040-0.100 in

Transmission General Specifications

Low and Reverse Band Servo Piston Pin Specification Chart

Refer to the chart in order to determine the correct low and reverse band servo pin length to use. A, B and C on the chart refer to markings on the J 21370-10 Band Apply Pin Gauge. See Special Tools . Numbers 1-7 match the correct piston pin length to the J 21370-10 land indicated by the low and reverse band servo pin inspection procedure. See Special Tools .

Scheme 496

Scheme 496: Low and Reverse Band Servo Piston Pin Specification Chart
Pin LengthPin Identification
MmInch
83.82-83.973.300-3.3061
84.53-84.683.328-3.3342
85.24-85.393.356-3.3623
85.95-86.103.384-3.3904
86.66-87.533.412-3.4465
87.38-87.533.440-3.4466
88.09-88.243.468-3.4747

Servo Piston Pin Selection

Scheme 497

Scheme 497: Disassembled Views
CalloutComponent Name
1Torque Converter Assembly
2Turbine Shaft Front Oil Seal Ring
3A/Trans O/Pump Bolt and Seal Assembly
4A/Trans Oil Pump Assembly
5A/Trans Oil Pump Seal
6A/Trans Oil Pump Gasket
7A/Trans Case Assembly
8Transmission Oil Cooler Pipe Connector
9Vent Pipe
10Nameplate Pin
11A/Trans Name Plate
12Orifice Lube Oil - 2WD Plug Case - 4WD
13Output Shaft Seal
14Output Shaft Seal Retainer Ring
15Case Extension Seal
16Bearing Retainer Ring
17Ball Bearing Assembly
17Ball Bearing Assembly
18Bearing Spacer
19Case Extension Assembly
19Case Extension Assembly
20Prop Shaft Front Slip Yoke Oil Seal Assembly
20Prop Shaft Front Slip Yoke Oil Seal Assembly
20Prop Shaft Front Slip Yoke Oil Seal Assembly
21Case Extension Bolt
21Case Extension Bolt
22A/T Input Speed and 2WD Output Speed Sensor Assembly (4WD Plug)
23Input Speed and Output Speed Sensor Bolt
24Line Pressure Test Hole Plug
77Prop Shaft Front Slip Yoke Bushing
78Output Shaft Bushing
79Direct Oil Gal - 0.25 Diameter Cup Plug
80Manual 2-1 Band Anchor Pin
81Low and Reverse Band Anchor Pin
89Transmission Oil Cooler Pipe Retainer (Some Models)
89Transmission Oil Cooler Pipe Retainer (Some Models)
90Transmission Rear Oil Cooler Pipe Fitting
91Transmission Rear Oil Cooler Pipe Fitting Seal

Callouts For (Scheme 497)

Scheme 498

Scheme 498
CalloutComponent Name
7A/Trans Case Assembly
27Transmission Oil Pan Bolt
28Transmission Oil Pan
29Transmission Oil Pan Gasket
30A/Trans Oil Pan Magnet
31Transmission Oil Filter Assembly
32Filter Neck Seal Assembly
33A/Trans Wiring Harness Clamp
34A/Trans Wiring Harness Assembly
36Pass Thru O-ring seal

Callouts For (Scheme 498)

Scheme 499

Scheme 499
CalloutComponent Name
7A/Trans Case Assembly
25Center Support Bolt
26Fourth Clutch Housing Bolt
33Electrical Cable Clamp
35Control Valve Body Assembly Bolt
35Control Valve Body Assembly Bolt
37Lube Oil Pipe Retainer
39Lube Oil Pipe
40A/T Fluid Pressure Manual Valve Position Switch
41Manual Shift Shaft Detent Spring Assembly
44Control Valve Assembly (w/Body and Valves)
45Control Valve Body Gasket
46Control Valve Body Spacer Plate
47Accumulator Housing Gasket
48Control Valve Body Spacer Plate Gasket
494th Clutch Accumulator Piston Spring
503rd Clutch Accumulator Piston Spring
513rd and 4th Clutch Accumulator Housing
533rd and 4th Clutch Accumulator Housing Bolt
54Control Valve Body Ball Check Valve
55Manual 2-1 Band Servo Piston Pin
56Manual 2-1 Band Servo Piston Pin Retainer Ring
57Manual 2-1 Band Servo Piston Seal
58Manual 2-1 Band Servo Piston
60Manual 2-1 Band Servo Piston Cushion Spring
61Low and Reverse Band Servo Cover Bolt
62Low and Reverse Band Servo Cover
63Low and Reverse Band Servo Cover Gasket
64Low and Reverse Band Servo Piston Pin Retainer Ring
65Low and Reverse Band Servo Piston
66Low and Reverse Band Servo Piston Seal
67Low and Reverse Accumulator Piston Outer Oil Seal Ring
681-2 Accumulator Piston
69Low and Reverse Accumulator Piston Inner Oil Seal Ring
71Low and Reverse Band Servo Piston Spring
72Low and Reverse Band Servo Piston Spring Retainer
73Low and Reverse Band Servo Piston Pin (Selective)
74Low and Reverse Accumulator Piston Spring
75TCC Solenoid Valve Screen
76TFP Manual Valve Position Switch Bolt
87Low and Reverse Band Servo Piston Spacer
881-2 Accumulator Piston Spring Assembly

Callouts For (Scheme 499)

Scheme 500

Scheme 500
CalloutComponent Name
5A/Trans Oil Pump Seal
201Torque Converter Oil Seal Assembly
202Torque Converter Bushing
203Oil Pump Body Assembly
204Oil Pump Driven Gear
205Oil Pump Drive Gear
206Oil Pump Cover
207Oil Pump Cover Plug
207Oil Pump Cover Plug
207Oil Pump Cover Plug
207Oil Pump Cover Plug
208Converter Limit Valve Bypass Orificed Cup Plug
209Oil Pump Cover Plug
209Oil Pump Cover Plug
210Line Air Bleed Orificed Cup Plug
211Pressure Regulator Valve Bore Plug Pin
211Pressure Regulator Valve Bore Plug Pin
211Pressure Regulator Valve Bore Plug Pin
212Converter Regulator Valve Bore Plug
213Converter Regulator Valve Spring
214Converter Regulator Valve
215TCC Enable Valve Spring Retainer Sleeve
216TCC Enable Valve Spring
217TCC Enable Valve
218Overrun Clutch Housing Thrust Washer
219Overrun Clutch Housing Oil Seal Ring
220Oil Pump Cover Bolt
221TCC Shift Valve Bore Plug Retainer Ring
223TCC Shift Valve
224TCC Shift Valve Spring
225TCC Shift Valve Spring Seat
226Retainer Ring (Reverse Boost Valve Bushing)
227Reverse Boost Valve Bushing
228Reverse Boost Valve
229Pressure Regulator Valve Spring Retainer
230Pressure Regulator Valve Outer Spring
231Pressure Regulator Valve
232TCC Shift Valve Lower and Pressure Regulator Valve Bore Plug
232TCC Shift Valve Lower and Pressure Regulator Valve Bore Plug
233Turbine Shaft Front Bushing
234Turbine Shaft Rear Bushing
235Stator Shaft
236Pressure Regulator Valve Feedback Orificed Cup Plug
237Converter Limit Valve Feedback Orificed Cup Plug
238Pressure Regulator Valve Inner Spring
239Vent Passage Splash Shield

Callouts For (Scheme 500)

Scheme 501

Scheme 501
CalloutComponent Name
301Control Valve Body
302Pressure Control Solenoid Valve Fluid Filter Assembly
303Shift Valve Fluid Filter Bore Plug Pin
303Shift Valve Fluid Filter Bore Plug Pin
303Shift Valve Fluid Filter Bore Plug Pin
303Shift Valve Fluid Filter Bore Plug Pin
304Low-Reverse Ball Valve Seat
305Low-Reverse Ball Valve
305Low-Reverse Ball Valve
3073rd Ball Valve Bushing Seal
3083-4 Shift Valve
3092-3, 3-4 Shift Valve Spring
3092-3, 3-4 Shift Valve Spring
310Solenoid Bolt (1-2 and 2-3 Shift Valve)
310Solenoid Bolt (1-2 and 2-3 Shift Valve)
3112-3 Shift Solenoid Valve Assembly
3122-3 Shift Valve
3131-2 Shift Solenoid Valve Assembly
3141-2 Shift Valve
3151-2 Shift Valve Spring
316Shift Valve Fluid Filter Bore Plug
317Shift Solenoid Valve Fluid Filter Assembly
318Low-Reverse Ball Valve Seat Pin
334Reverse Ball Valve Bushing
3353rd Ball Valve Bushing

Callouts For (Scheme 501)

Scheme 502

Scheme 502
CalloutComponent Name
301Control Valve Body
303Shift Valve Accumulator Valve Bore Plug Pin
303Shift Valve Accumulator Valve Bore Plug Pin
310Pressure Control Solenoid Clamp Bolt
319Manual Valve
320Pressure Control Solenoid Valve Assembly
321Pressure Control Solenoid Clamp
322TCC PWM Solenoid Valve Retainer
323TCC PWM Solenoid Valve Assembly
324TCC Regulator Apply Valve
325TCC Regulator Apply Valve Spring
327Actuator Feed Limit Valve Spring
328Actuator Feed Limit Valve
329Accumulator Valve Bore Plug
330Accumulator Valve Spring
331Accumulator Valve
333Actuator Feed Limit Valve Spring Retainer

Callouts For (Scheme 502)

Scheme 503

Scheme 503
CalloutComponent Name
494th Clutch Accumulator Piston Spring
503rd Clutch Accumulator Piston Spring
513rd and 4th Clutch Accumulator Housing
533rd and 4th Clutch Accumulator Housing Bolt
4024th Clutch Accumulator Piston Pin Ring
4043rd and 4th Clutch Accumulator Piston Seal
4043rd and 4th Clutch Accumulator Piston Seal
4053rd Clutch Accumulator Piston
4063rd Clutch Accumulator Piston Inner Seal
4074th Clutch Accumulator Piston
4084th Clutch Accumulator Piston Pin

Callouts For (Scheme 503)

Scheme 504

Scheme 504
CalloutComponent Name
501Turbine Shaft Intermediate Oil Seal Ring
502Turbine Shaft
503Turbine Shaft Rear Oil Seal Ring
504Overrun Clutch Housing Assembly
505Overrun Clutch Piston Assembly
506Overrun Clutch Spring Assembly
507Overrun Clutch Spring Retainer Ring
508Overrun Clutch Plate
509Overrun Clutch Plate Assembly
510Overrun Clutch Backing Plate
511Overrun Clutch Backing Plate Retainer Ring
512Overdrive Clutch Roller Assembly
513Overrun Clutch Housing Bearing Assembly
514Overdrive Carrier Assembly
515Overdrive Carrier Pinion Gear Thrust Washer
515Overdrive Carrier Pinion Gear Thrust Washer
516Overdrive Carrier Pinion Gear Washer Thrust (Steel)
516Overdrive Carrier Pinion Gear Washer Thrust (Steel)
517Overdrive Carrier Pinion Gear Roller Bearing
518Overdrive Carrier Pinion Gear
519Overdrive Carrier Pinion Gear Pin
520Overdrive Carrier Pinion Gear Pin Retainer
521Overdrive Carrier Pinion Gear Pin Retainer Retaining Ring
522Overdrive Carrier Retainer Ring
534Turbine Shaft Plug
537Direct Clutch Housing Ball Check Valve

Callouts For (Scheme 504)

Scheme 505

Scheme 505
CalloutComponent Name
5234th Clutch Backing Plate Retainer Ring
5244th Clutch Backing Plate
5254th Clutch Plate Assembly
5264th Clutch Plate
5274th Clutch Piston Inner Seal
5284th Clutch Piston
5294th Clutch Housing
5304th Clutch Orifice
5314th Clutch Piston Outer Seal
5324th Clutch Spring Assembly
5334th Clutch Spring Retainer Ring

Callouts For (Scheme 505)

Scheme 506

Scheme 506
CalloutComponent Name
601Overdrive Carrier/Forward Clutch Thrust Bearing Assembly
602Forward Clutch Housing Assembly
606Forward Clutch Piston Assembly
607Forward Clutch Spring Assembly
608Forward Clutch Spring Retainer Ring
609Forward Clutch (Waved) Plate
610Forward Clutch Plate
611Forward Clutch Plate Assembly
612Forward Clutch Housing Thrust Washer
613Forward Clutch Hub
614Direct Clutch Housing Thrust Washer
615Direct Clutch Hub
616Direct Clutch Hub Retainer Ring
685Forward Clutch Piston Intermediate Seal Assembly

Callouts For (Scheme 506)

Scheme 507

Scheme 507
CalloutComponent Name
537Direct Clutch Housing Ball Check Valve
607Direct Clutch Spring Assembly
608Direct Clutch Spring Retainer Ring
609Direct Clutch (Waved) Plate
611Direct Clutch Plate Assembly
616Direct Clutch Backing Plate Retaining Ring
617Direct Clutch Backing Plate
618Direct Clutch Plate
619Direct Clutch Piston Assembly
622Direct Clutch Piston Intermediate Seal
623Direct Clutch Housing Assembly
624Intermediate Clutch Sprag Assembly
625Intermediate Clutch Roller Race (Outer)
626Intermediate Clutch Roller Retainer
627Intermediate Clutch Roller Retainer Retaining Ring

Callouts For (Scheme 507)

Scheme 508

Scheme 508
CalloutComponent Name
628Manual 2-1 Band Assembly
629Intermediate Clutch Backing Plate Retainer Ring
630Intermediate Clutch Backing Plate
631Intermediate Clutch Plate Assembly
632Intermediate Clutch Plate
633Center Support Retaining Ring
684Intermediate Clutch Plate (Waved)

Callouts For (Scheme 508)

Scheme 509

Scheme 509
CalloutComponent Name
530Intermediate Clutch Orifice
634Intermediate Clutch Spring Retainer Ring
635Intermediate Clutch Spring Assembly
636Intermediate Clutch Piston
637Intermediate Clutch Piston Inner Seal
638Intermediate Clutch Piston Outer Seal
639Direct Clutch Housing Oil Seal Ring
640Center Support Assembly
642Reaction Carrier Thrust Washer
643Center Support Spacer
644Low Clutch Roller Assembly
646Sun Gear Front Thrust Bearing Race
647Sun Gear Front/Rear Internal Gear Thrust Bearing Assembly
647Sun Gear Front/Rear Internal Gear Thrust Bearing Assembly
648Sun Gear Front Thrust Bearing Race
648Sun Gear Front Thrust Bearing Race
649Sun Gear Shaft Assembly
650Sun Gear
651Reaction Carrier Assembly (4 Pinion)
651aReaction Carrier Assembly (5 Pinion)
652Reaction Carrier Pinion Gear Thrust Washer (Bronze)
652Reaction Carrier Pinion Gear Thrust Washer (Bronze)
652Reaction Carrier Pinion Gear Thrust Washer (Bronze)
652Reaction Carrier Pinion Gear Thrust Washer (Bronze)
653Reaction Carrier Pinion Gear Thrust Washer (Steel)
653Reaction Carrier Pinion Gear Thrust Washer (Steel)
653Reaction Carrier Pinion Gear Thrust Washer (Steel)
653Reaction Carrier Pinion Gear Thrust Washer (Steel)
654Reaction Carrier Pinion Gear Roller Bearing Roller
654Reaction Carrier Pinion Gear Roller Bearing
655Reaction Carrier Pinion Gear
655Reaction Carrier Pinion Gear
656Reaction Carrier Pinion Gear Pin
656Reaction Carrier Pinion Gear Pin
657Low and Reverse Band Assembly
659Output Carrier Thrust Washer
660Vehicle Speed Sensor Reluctor Ring
661Output Carrier Assembly (4 Pinion)
661aOutput Carrier Assembly (5 Pinion)
662Main Shaft
663Sun Gear Rear Thrust Bearing Race
664Sun Gear Rear Thrust Bearing Assembly
665Sun Gear Rear Thrust Bearing Race
666Rear Internal Gear
669Rear Internal Gear Thrust Bearing Race
670Main Shaft Retainer Ring
671Output Shaft Assembly
672Output Shaft Retainer Ring
673Output Shaft Thrust Washer
674Selective Thrust Washer
675Output Shaft Seal
676Main Shaft Bushing
676Main Shaft Bushing
677Rear Internal Gear Bushing
678Center Support Oil Passage Sleeve
681Reaction Carrier Bushing
682Transmission Output Shaft Yoke Seal Sleeve
683Output Shaft Seal
690Center Support Oil Cooler Pipe Fitting Seal
691Rear Internal Gear Thrust Washer

Callouts For (Scheme 509)

Scheme 510

Scheme 510
CalloutComponent Name
701Parking Pawl Shaft Hole Plug
702Parking Pawl Shaft
703Parking Pawl
704Parking Pawl Shaft Retainer
705Parking Pawl Spring
707Manual Shift Shaft Seal
708Manual Shift Shaft
708Manual Shift Shaft
709Manual Shift Shaft Pin
710Parking Pawl Actuator Assembly
711Manual Shift Shaft Detent Lever Assembly
712Manual Shift Shaft Detent Lever Nut
713Parking Pawl Actuator Bracket
714Parking Pawl Actuator Bracket Bolt

Callouts For (Scheme 510)

Scheme 511

Scheme 511: Automatic Transmission Electronic Component Views
CalloutComponent Name
22aAutomatic Transmission (AT) Input (Shaft) Speed Sensor (ISS) Assembly
22bAutomatic Transmission (AT) Output (Shaft) Speed Sensor (OSS) Assembly
34Automatic Transmission Fluid Temperature (TFT) Sensor
40Automatic Transmission Fluid Pressure (TFP) Manual Valve Position Switch
3112-3 Shift Solenoid (SS) Valve Assembly
3131-2 Shift Solenoid (SS) Valve Assembly
320Pressure Control (PC) Solenoid Valve Assembly
323Torque Converter Clutch Pulse Width Modulation (TCC PWM) Solenoid Valve Assembly

Callouts For (Scheme 511)

Scheme 512

Scheme 512: Component Location
CalloutComponent Name
77Prop Shaft Front Slip Yoke Bushing
78Output Shaft Bushing
202Torque Converter Bushing
233Turbine Shaft Front Bushing
234Turbine Shaft Rear Bushing
512Overdrive Clutch Roller Assembly
513Overrun Clutch Housing Thrust Bearing Assembly
535Overrun Clutch Housing Bushing
536Bushing, 1.12 in. Outside Diameter x 0.50 in.
601Thrust Carrier/Forward Clutch Bearing Assembly
644Low Clutch Roller Assembly
647Sun Gear Front/Rear Internal Gear Thrust Bearing Assembly
647Sun Gear Front/Rear Internal Gear Thrust Bearing Assembly
664Sun Gear Rear Thrust Bearing Assembly
676Main Shaft Bushing
676Main Shaft Bushing
677Rear Internal Gear Bushing
678Center Support Oil Passage Sleeve
679Bushing, 1.536 in. Diameter x 3.52 in.
681Reaction Carrier Bushing
691Rear Internal Gear Thrust Washer

Callouts For (Scheme 512)

Scheme 513

Scheme 513
CalloutComponent Name
2Turbine Shaft Front Oil Seal Ring
5Oil Pump Seal
13Output Shaft Seal
15Case Extension Seal
20Prop Shaft Front Slip Yoke Oil Seal Assembly
20Prop Shaft Front Slip Yoke Oil Seal Assembly
57Manual 2-1 Band Servo Piston Seal
66Low and Reverse Band Servo Piston Seal
67Low and Reverse Accumulator Piston Outer Oil Seal Ring
69Low and Reverse Accumulator Piston Inner Oil Seal Ring
201Torque Converter Oil Seal Assembly
219Overrun Clutch Housing Oil Seal Ring
4043rd Clutch Accumulator Piston Outer Seal
4063rd Clutch Accumulator Piston Inner Seal
501Turbine Shaft Intermediate Oil Seal Ring
503Turbine Shaft Rear Oil Seal Ring
505Overrun Clutch Piston Assembly
527Fourth Clutch Piston Inner Seal
531Fourth Clutch Piston Outer Seal
606Forward Clutch Piston Assembly
619Direct Clutch Piston Assembly
622Direct Clutch Piston Intermediate Seal
637Intermediate Clutch Piston Inner Seal
638Intermediate Clutch Piston Outer Seal
639Direct Clutch Housing Oil Seal Ring
685Forward Clutch Piston Intermediate Seal Assembly

Callouts For (Scheme 513)

Scheme 514

Scheme 514
CalloutComponent Name
1Overrun Clutch
3Front Band Apply
42nd Clutch
53rd Accumulator
64th Accumulator
83rd Clutch
9Reverse
104th Clutch

Callouts For (Scheme 514)

Scheme 515

Scheme 515
CalloutComponent Name
7Lo/Reverse
113rd Clutch/Reverse

Callouts For (Scheme 515)

Scheme 516

Scheme 516: Torque Converter Assembly Removal
  1. Remove the transmission torque converter assembly.
  2. Inspect the torque converter assembly for the following: External damage Metal particles found after flushing the oil cooler and the cooler lines External leaks in the hub weld area The torque converter pilot is damaged or fits poorly into the crankshaft Internal failure of the stator roller clutch Contamination from the engine coolant Excessive end play (Refer to «Torque Converter End Play Inspection»(ref-246429-S42039356172006122100000) ).

Torque Converter End Play Inspection

Tools Required

  1. J 26900-13 Magnetic Indicator Base
  2. J 8001 Dial Indicator Set
  3. J 39195 Converter End Play Check Tool

Scheme 517

Scheme 517
  1. Place the J 39195 base into the torque converter assembly (1). The J 39195 will bottom itself on the face of the stator.
  2. Insert the T-handle forcing screw of the J 39195 into the base and hand tighten.
  3. Using the J 26900-13 , position the J 8001 so that the dial indicator tip is in the center of the J 39195 T-handle.
  4. Push down on the J 39195 T-handle to bottom the stator.
  5. Preload the J 8001 .
  6. Set the J 8001-3 to 0.
  7. Pull up on the J 39195 T-handle.
  8. Inspect the reading on the dial indicator. The total end play should be 0.0-0.38 mm (0.0-0.015 in).
  9. Repeat this procedure several times in order to get an accurate measurement.
  10. Remove the tools.

Overdrive Range, Third Gear - Torque Converter Clutch Applied

In order to obtain third gear, the PCM receives input signals from both speed sensors, from the TP Sensor, and from other engine sensors. These signals determine when to energize the 2-3 Shift Solenoid (SS) Valve.

Scheme 518

Scheme 518: Overdrive Range, Third Gear - Torque Converter Clutch Applied

Overdrive Range, Fourth Gear - Torque Converter Clutch Applied

In order to obtain fourth gear, the PCM receives input signals from both speed sensors, from the TP Sensor, and from other engine sensors. These signals determine when to energize the 1-2 Shift Solenoid (SS) Valve.

Scheme 519

Scheme 519: Overdrive Range, Fourth Gear - Torque Converter Clutch Applied
