Seat System: Specifications Chevrolet Silverado 1500 HD

Seats 50 illustrations ~109 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Armrest Bolts9 N.m80 lb in
Armrest Trim Cover Screws2 N.m18 lb ft
Bench Seat Back Frame Bolts53 N.m39 lb ft
Bench Seat Grab Handle Bolts30 N.m22 lb ft
Bench Seat Rear Riser Latch Bolts53 N.m39 lb ft
Cushion Front Nuts21 N.m15 lb ft
Cushion Side Bolts35 N.m26 lb ft
Folding Head Restraint Assembly Bolts7 N.m61 lb in
Front Recliner Attachment Bolts53 N.m39 lb ft
Front Seat Belt Buckle Nut53 N.m39 lb ft
Hinge Assembly Bolts7 N.m61 lb in
Inboard Pivot Bolt35 N.m26 lb ft
Latch Cover Screws2 N.m18 lb in
Lumbar Switch Screws2 N.m18 lb in
Memory Module Screws3 N.m26 lb in
Outboard Pivot Bolt35 N.m26 lb ft
Outboard Seat Belt Anchor Bolt53 N.m39 lb ft
Outboard Seat Belt Anchor Nut53 N.m39 lb ft
Power Seat Switch Bezel Screws2 N.m18 lb in
Power Seat Switch Screws2 N.m18 lb in
Rear Heated Seat Switch Screw1.6 N.m14 lb in
Rear Seat Back Latch Bolt45 N.m33 lb ft
Rear Seat Back Latch Screw25 N.m18 lb ft
Recliner Arm Attachment Bolts53 N.m39 lb ft
Recliner/Release Handle Screws2 N.m18 lb in
Recliner Screw10 N.m89 lb in
Seat Back Folding Mechanism Bolts21 N.m15 lb ft
Seat Back Side Bolts35 N.m26 lb ft
Seat Belt Tower Cover Screw1.9 N.m17 (bin
Seat Front Retaining Nuts55 N.m41 lb ft
Seat Rear Retaining Bolts55 N.m41 lb ft
Trim Panel Screws2 N.m18 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Power Seats Schematics
Scheme 1: Power Seats Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3: Lumbar Support Schematics
Scheme 3: Lumbar Support Schematics

Scheme 4

Scheme 4: Heated Seats Schematics
Scheme 4: Heated Seats Schematics

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8: Memory Seats Schematics
Scheme 8: Memory Seats Schematics

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15: Power Seat Systems Component Views
Scheme 15: Power Seat Systems Component Views

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19: Power Seat Systems Connector End Views
Scheme 19: Power Seat Systems Connector End Views

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50
