Lighting Systems: Removal & Installation Chevrolet Silverado 1500 HD

Removal Procedure

Note. Avoid touching the bulb or letting the bulb come in contact with anything damp. Oil from your skin or moisture on the bulb can cause the bulb to explode when the bulb is turned on. If either comes in contact with the bulb, clean the bulb with alcohol or a suitable degreaser and wipe the bulb dry.

Scheme 283

Scheme 284

Scheme 285

1. Open the hood. Rotate the headlamp retainer pins.
2. Remove the headlamp retainer pins.
3. Pull out the headlamp assembly in order to access the electrical connector.
4. Disconnect the electrical connector.
5. Remove the bulb from the headlamp assembly by twisting the bulb counterclockwise.

Installation Procedure

Scheme 286

Scheme 287

Scheme 288

1. Install the new bulb to the headlamp assembly by twisting the bulb clockwise in order to lock in place.
2. Connect the electrical connector to the bulb.
3. Install the headlamp assembly.
4. Install the headlamp retainer pins.
5. Rotate and lock the pins in place.
6. Inspect the operation.

Note. Avoid touching the bulb or letting the bulb come in contact with anything damp. Oil from your skin or moisture on the bulb can cause the bulb to explode when the bulb is turned on. If either comes in contact with the bulb, clean the bulb with alcohol or a suitable degreaser and wipe the bulb dry.

Scheme 289

Scheme 290

Scheme 291

Scheme 292

1. Open the hood.
2. Remove the upper grille baffle.
3. Remove the headlamp assembly retaining pin.
4. Pull the headlamp assembly from the vehicle, and disconnect the headlamp bulb connectors.
5. Remove the headlamp assembly from the vehicle.
6. If replacing the headlamp bulb, twist the bulb counterclockwise and remove from headlamp assembly.

Scheme 293

Scheme 294

Scheme 295

Scheme 296

1. If replacing the headlamp bulb, install the bulb to the headlamp assembly and twist clockwise to lock in place.
2. Align the headlamp assembly to the vehicle, and connect the headlamp electrical connectors.
3. Install the headlamp assembly retaining pin, making sure that the pin is fully seated and set in place in the retaining groove.
4. Install the upper grille baffle.
5. Close the hood.

Note. Avoid touching the bulb or letting the bulb come in contact with anything damp. Oil from your skin or moisture on the bulb can cause the bulb to explode when the bulb is turned on. If either comes in contact with the bulb, clean the bulb with alcohol or a suitable degreaser and wipe the bulb dry.

Scheme 297

Scheme 298

Scheme 299

Scheme 300

1. Open the hood.
2. Remove the upper grille baffle.
3. Remove the headlamp assembly retaining pin.
4. Pull the headlamp assembly from the vehicle, and disconnect the headlamp bulb connectors.
5. Remove the headlamp assembly from the vehicle.
6. If replacing the headlamp bulb, twist the bulb counterclockwise and remove from headlamp assembly.

Scheme 301

Scheme 302

Scheme 303

Scheme 304

1. If replacing the headlamp bulb, install the bulb to the headlamp assembly and twist clockwise to lock in place.
2. Align the headlamp assembly to the vehicle, and connect the headlamp electrical connectors.
3. Install the headlamp assembly retaining pin, making sure that the pin is fully seated and set in place in the retaining groove.
4. Install the upper grille baffle.
5. Close the hood.

Note. Refer to FASTENER NOTICE .

Scheme 305

1. Install the fog lamp bracket bolts and bracket, as needed. Tighten Tighten the fog lamp bolt to 25 N.m (18 lb ft).
2. Install the fog lamp to the fog lamp bracket.
3. Install the fog lamp adjuster bolt and spring to the adjuster nut.
4. Install the push pin retainers that attach the fog lamp to the bracket.
5. Connect the electrical connector to the fog lamp.
6. Inspect the fog lamp aiming.

Scheme 306

1. Disconnect the electrical connector from the fog lamp.
2. Remove the retainers that attach the fog lamp to the bracket.
3. Remove the fog lamp from the bumper fascia.

Note. Refer to FASTENER NOTICE .

Scheme 307

1. Tighten Tighten the fog lamp bolt to 9 N.m (7 lb ft).
2. Install the fog lamp to the bumper fascia.
3. Install the retainers that attach the fog lamp to the bracket.
4. Connect the electrical connector to the fog lamp.
5. Inspect the fog lamp aiming.

Scheme 308

1. Disconnect the electrical connector from the fog lamp.
2. Remove the retainers that attach the fog lamp to the bracket.
3. Remove the fog lamp from the bumper fascia.

Note. Refer to FASTENER NOTICE .

Scheme 309

1. Tighten Tighten the fog lamp bolt to 9 N.m (7 lb ft).
2. Install the fog lamp to the bumper fascia.
3. Install the retainers that attach the fog lamp to the bracket.
4. Connect the electrical connector to the fog lamp.
5. Inspect the fog lamp aiming.

Scheme 310

1. Remove the electrical connector. CAUTION: Refer to «HALOGEN BULB CAUTION»(ref-175132-S15872162902005041500000) .
2. Remove the bulb from the fog lamp assembly by twisting the bulb counterclockwise and pulling the bulb out.

Scheme 311

1. Install the bulb to the fog lamp assembly by inserting the bulb and twisting the bulb clockwise.
2. Install the electrical connector.

Scheme 312

1. Remove the electrical connector. CAUTION: Refer to «HALOGEN BULB CAUTION»(ref-175132-S15872162902005041500000) .
2. Remove the bulb from the fog lamp assembly by twisting the bulb counterclockwise and pulling the bulb out.

Scheme 313

1. Install the bulb to the fog lamp assembly by inserting the bulb and twisting the bulb clockwise.
2. Install the electrical connector.

Scheme 314

1. Remove the electrical connector. CAUTION: Refer to «HALOGEN BULB CAUTION»(ref-175132-S15872162902005041500000) .
2. Remove the bulb from the fog lamp assembly by twisting the bulb counterclockwise and pulling the bulb out.

Scheme 315

1. Install the bulb to the fog lamp assembly by inserting the bulb and twisting the bulb clockwise.
2. Install the electrical connector.

Scheme 316

1. Remove the rear fog lamp lens (1) retaining screws (2). CAUTION: Refer to «HALOGEN BULB CAUTION»(ref-175132-S15872162902005041500000) .
2. Remove the bulb from the rear fog lamp assembly by twisting the bulb counterclockwise and pulling the bulb out.

Scheme 317

1. Install the bulb to the rear fog lamp assembly by inserting the bulb and twisting the bulb clockwise. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) .
2. Install the rear fog lamp lens (1) retaining screws (2). Tighten Tighten the screws (2) to 2 N.m (18 lb in).
3. Inspect the operation of the rear fog lamp.
