Door System, Mirror System & Window System: Specifications Chevrolet Silverado 1500 HD

Door Locks & Anti-Theft Systems 49 illustrations ~119 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Armrest Mounting Screw2 N.m18 lb in
Check Strap Bolt24 N.m18 lb ft
Check Strap Nuts24 N.m18 lb ft
Clevis Bolt24 N.m18 lb ft
Door Hinge Bolt24 N.m18 lb ft
Door Lock and Actuator Assembly Mounting Bolt9 N.m80 lb in
Door Striker Bolt24 N.m18 lb ft
Inside Door Handle Mounting Bolt9 N.m80 lb in
Outside Door Handle Mounting Bolt9 N.m80 lb in
Outside Rearview Mirror Retaining Nut9 N.m80 lb in
Side Access Door Inside Handle Nut9 N.m80 lb in
Side Access Door Latch Bolt9 N.m80 lb ft
Side Access Door Latch Control9 N.m80 lb in
Side Access Door Lower Striker Bolt24 N.m18 lb ft
Side Access Door Upper Striker Bolt24 N.m18 lb ft
Side Door Inside Handle Nut9 N.m80 lb in
Window Glass Retaining Bolt2 N.m18 lb in
Window Run Channel Bolt9 N.m80 lb in
Window to Regulator Bolt9 N.m80 lb in
Window Sash Channel Bolt6 N.m53 lb in

Fastener Tightening Specifications

Scheme 45

Scheme 45: Power Window Schematics
Scheme 45: Power Window Schematics

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47: Door Lock/Indicator Schematics
Scheme 47: Door Lock/Indicator Schematics

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54: Outside Mirror Schematics
Scheme 54: Outside Mirror Schematics

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57: Door Control Module Schematics
Scheme 57: Door Control Module Schematics

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63: Power Door Systems Component Views
Scheme 63: Power Door Systems Component Views

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66
Scheme 66

Scheme 67

Scheme 67: Power Door Systems Connector End Views
Scheme 67: Power Door Systems Connector End Views

Scheme 68

Scheme 68
Scheme 68

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73
Scheme 73

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75
Scheme 75

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78

Scheme 79

Scheme 79
Scheme 79

Scheme 80

Scheme 80
Scheme 80

Scheme 81

Scheme 81
Scheme 81

Scheme 82

Scheme 82
Scheme 82

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85
Scheme 85

Scheme 86

Scheme 86
Scheme 86

Scheme 87

Scheme 87
Scheme 87

Scheme 88

Scheme 88
Scheme 88

Scheme 89

Scheme 89
Scheme 89

Scheme 90

Scheme 90
Scheme 90

Scheme 91

Scheme 91
Scheme 91

Scheme 92

Scheme 92
Scheme 92

Scheme 93

Scheme 93
Scheme 93
