Lighting Systems: Specifications Chevrolet RV Cutaway G3500

Exterior Lights 37 illustrations ~1877 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Backup Lens to Lamp Assembly Screws1.5 N.m13 lb in
Center High Mounted Stop Lamp to Center High Mounted Stop Lamp Applique Screws1.5 N.m13 lb in
Composite Headlamp Assembly to Radiator Support Bolts11 N.m97 lb in
Daytime Running Lamp (DRL) Diode Bracket to Driver Inner Knee Bolster Bracket Bolt4 N.m35 lb in
Dome Lamp to Dome Lamp Housing Screws1.5 N.m13 lb in
Fog Lamp Lens to Fog Lamp Assembly Screws1.5 N.m13 lb in
License Plate Lamp to License Plate Pocket Screws2.5 N.m22 lb in
Park/ Turn Signal Lamp to Radiator Grille Screws1.5 N.m13 lb in
Relay Center Bracket to Knee Bolster Bracket Bolts4 N.m35 lb in
Retaining Ring to Headlamp Housing Screws1.5 N.m13 lb in
Side Marker Lamp to Body Screws1.5 N.m13 lb in
Stepwell Lamp Lens to Stepwell Screw1.5 N.m13 lb in
Taillamp to Quarter Panel Nuts5 N.m44 lb in
Underhood (UH) Lamp to Hood Bolts2 N.m18 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Headlights Schematics

Scheme 2

Scheme 2: Exterior Lights Schematics

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8: Interior Lights Schematics

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14: Interior Lights Dimming Schematics

Scheme 15

Scheme 15

Scheme 16

Scheme 16

Scheme 17

Scheme 17: Lighting Systems Component Views
CalloutComponent Name
1Headlamp - Left

Scheme 18

Scheme 18
CalloutComponent Name
1Headlamp - Right

Scheme 19

Scheme 19
CalloutComponent Name
1Headlamp - High Beam Connector - Left
2Headlamp - Low Beam Connector - Left

Scheme 20

Scheme 20
CalloutComponent Name
1Headlamp - Low Beam Connector - Right
2Headlamp - High Beam Connector - Right

Scheme 21

Scheme 21
CalloutComponent Name
1Marker Lamp Connector - LF
2G100
3Headlamp - Low Beam Connector - Left (Composite)
4Headlamp - High Beam Connector - Left (Composite)
5S110
6S118
7Park/Turn Signal Lamp Connector - RF
8Marker Lamp Connector - RF
9G101
10Headlamp - Low Beam Connector - Right (Composite)
11Headlamp - High Beam Connector - Right (Composite)
12Park/Turn Signal Lamp Connector - LF
13Fuse Block Underhood - C4

Scheme 22

Scheme 22
CalloutComponent Name
1Underhood Lamp Connector
2C109

Scheme 23

Scheme 23
CalloutComponent Name
1C221
2Data Link Connector (DLC)
3Stop Lamp Switch Connector

Scheme 24

Scheme 24
CalloutComponent Name
1Headlamp and Panel Dimmer Switch

Scheme 25

Scheme 25
CalloutComponent Name
1Passlock Sensor
2Ignition Key Alarm Switch
3Ignition Lock Cylinder Control Actuator
4Ignition Switch
5Ignition Key Cylinder
6Horn Switch
7Inflatable Restraint Steering Wheel Module
8Turn Signal/Multifunction Switch
9Hazard Switch

Scheme 26

Scheme 26
CalloutComponent Name
1I/P Carrier
2Chime Module (UL5)
3Turn Signal/Hazard Flasher Module

Scheme 27

Scheme 27
CalloutComponent Name
1Vanity Mirror Lamp Connector - Left (DH6)

Scheme 28

Scheme 28
CalloutComponent Name
1Vanity Mirror Lamp Connector - Right (DH6)

Scheme 29

Scheme 29
CalloutComponent Name
1Door Latch Assembly - Driver

Scheme 30

Scheme 30
CalloutComponent Name
1Door Latch Assembly - Passenger

Scheme 31

Scheme 31
CalloutComponent Name
1Body Harness Cover
2S311 (w/o YF7)
3S310 (w/o YF7)
4S308 (w/o YF7)
5C304 (w/o YF7)
6C203 (YF7/DH6)
7C303 (YF7/C69 w/Rear Auxiliary Controls)
8Door Contact Plate Connector - Left Side (E26/AU3)
9C407 (ENC)
10C409 (ENC)
11Fuse Block Body - C2
12S310 (YF7)
13S308 (YF7)
14S311 (YF7)
15Body Harness
16Body Harness
17Lower B-Pillar
18Door Jamb Switch Connector - LR Side (E26)
19SP347
20G347

Scheme 32

Scheme 32
CalloutComponent Name
1C312
2Seat Belt Pretensioner Connector - RF (Light Duty)
3C306
4Door Contact Plate Connector - Right Side (Passenger/Cargo w/AU3)
5Door Jamb Switch Connector - RR Side (Passenger/Cargo)

Scheme 33

Scheme 33
CalloutComponent Name
1Fuse Block Underhood - C3
2Fuse Block Underhood - C7
3Fuse Block Underhood - C8 (UY7)
4Wheel Speed Sensor (WSS) Connector - RF
5Brake Pressure Differential Switch Connector (Light Duty)
6Evaporative Emission (EVAP) Canister Vent Solenoid Connector (Gas)
7S301
8Electronic Brake Control Module (EBCM) Connector (JL4)/Electronic Brake Control Module (EBCM) - C2 (w/o JL4)
9Electronic Brake Control Module (EBCM) - C1 (w/o JL4)
10Trailer Right Stop/Turn Relay (UY7)
11Trailer Left Stop/Turn Relay (UY7)
12S315 (JL4)
13G300
14Wheel Speed Sensor (WSS) Connector - LF
15C101

Scheme 34

Scheme 34
CalloutComponent Name
1Courtesy/Reading Lamp - Front
2Courtesy/Reading Lamp - Mid
3Courtesy/Reading Lamp - Rear
4Dome Lamp - Rear (Cargo)

Scheme 35

Scheme 35
CalloutComponent Name
1Dome Fluorescent Work Lamp - LR (UF2)
2Dome Fluorescent Work Lamp - LF (UF2)
3S350 (UF2)
4S348 (UF2)
5Dome Fluorescent Work Lamp - 2 (UF2)
6Dome Fluorescent Work Lamp - 1 (UF2)
7Dome Fluorescent Work Lamp - RH (UF2)
8Access Panel Actuator - Right Side Front
9Access Panel Actuator - Right Side Rear
10S409
11Pro Wiring Harness
12Body Control Module (BCM)
13Fuse Block - Body
14S302 (UF2)
15S303
16Dome Fluorescent Work Lamps Relay (UF2)
17Fuse Block - Rear
18S309
19S300
20S408
21G403
22Access Panel Actuator - Left Rear Side Rear
23Access Panel Actuator - Left Rear Side Front
24Access Panel Actuator - Left Front Side Rear
25Access Panel Actuator - Left Front Side Front

Scheme 36

Scheme 36
CalloutComponent Name
1Rear Window Defogger Grid Connector - Right (C49)
2Door Latch Assembly - Cargo
3Door Lock Switch Connector - Rear Cargo (AU3)
4License Lamp Connector
5S902
6Speaker Connector - RR Door (UB1/UC6)
7C412
8C400

Scheme 37

Scheme 37
CalloutComponent Name
1Tail/Stop and Turn Signal Lamp - Left
2Center High Mounted Stop Lamp (CHMSL)
3Tail/Stop and Turn Signal Lamp - Right
4Backup Lamp - Right
5License Lamp
6Backup Lamp - Left

Backup Lamp - Left (Passenger/Cargo) Connector Part Information 12160393 2-Way Lamp Socket Wedge Base W3 Right Angle (L-GY) Pin Wire Color Circuit No. Function A L-GN 24 Backup Lamp Supply Voltage G BK 850 Ground

Backup Lamp - Right (Passenger/Cargo) Connector Part Information 12160393 2-Way Lamp Socket Wedge Base W3 Right Angle (L-GY) Pin Wire Color Circuit No. Function A L-GN 24 Backup Lamp Supply Voltage G BK 1050 Ground

Center High Mounted Stop Lamp (CHMSL) (Passenger/Cargo) Connector Part Information 12047663 2-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A L-BU 1320 CHMSL Supply Voltage B BK 850 Ground

Courtesy/Reading Lamp - Front Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A D-BU/WH 149 Courtesy Lamp Supply Voltage B BK 450 Ground C OG 1732 Inadvertent Power Supply Voltage

Courtesy/Reading Lamp - Mid (Passenger/Cargo) Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A D-BU/WH 149 Courtesy Lamp Supply Voltage B BK 450 Ground C OG 1732 Inadvertent Power Supply Voltage

Courtesy/Reading Lamp - Rear (Passenger/Cargo) Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A D-BU/WH 149 Courtesy Lamp Supply Voltage B BK 450 Ground C OG 1732 Inadvertent Power Supply Voltage

Dome Fluorescent Work Lamps (PNP w/UF2) Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A OG 840 Battery Positive Voltage B BK 150 Ground

Dome Lamp - Rear (Cargo) Connector Part Information 15528758 2-Way F Dome Lamp Base (NA) Pin Wire Color Circuit No. Function A D-BU/WH 149 Courtesy Lamp Supply Voltage B BK 850 Ground

Door Jamb Switch - LR Side (E26) Connector Part Information 12059251 2-Way F Metri-Pack 150 Series (RD) Pin Wire Color Circuit No. Function A BK 450 Ground B YE/BK 1181 Rear Door Open Switch Signal

Door Jamb Switch - RR Side (Passenger/Cargo) Connector Part Information 12059251 2-Way F Metri-Pack 150 Series (RD) Pin Wire Color Circuit No. Function A BK 450 Ground B YE/BK 1181 Rear Door Open Switch Signal

Door Latch Assembly - Cargo - C1 Connector Part Information 15354716 4-Way F GT 150 Series, Sealed 3.2 X 4.0 (BK) Pin Wire Color Circuit No. Function A L-GN 1177 Door Open Switch Signal B-C - - Not Used D BK 1050 Ground

Door Latch Assembly - Driver - C1 Connector Part Information 15354716 4-Way F GT 150 Series, Sealed 3.2 X 4.0 (BK) Pin Wire Color Circuit No. Function A TN 126 Left Front Door Open Switch Signal B-C - - Not Used D BK 450 Ground

Door Latch Assembly - Passenger - C1 Connector Part Information 15354716 4-Way F GT 150 Series, Sealed 3.2 X 4.0 (BK) Pin Wire Color Circuit No. Function A BK 450 Ground B-C - - Not Used D L-GN 1177 Door Open Switch Signal

Headlamp - High Beam - Left (Composite) Connector Part Information 12059183 2-Way F Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function A D-GN/WH 711 Left Headlamp High Beam Supply Voltage B BK 250 Ground

Headlamp - High Beam - Right (Composite) Connector Part Information 12059183 2-Way F Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function A L-GN/BK 311 Right Headlamp High Beam Supply Voltage B BK 650 Ground

Headlamp - Left (Sealed) Connector Part Information 12034372 3-Way F Metri-Pack 800 Series (BK) Pin Wire Color Circuit No. Function A BK 250 Ground B D-GN/WH 711 Left Headlamp High Beam Supply Voltage C YE 712 Left Headlamp Low Beam Supply Voltage

Headlamp - Low Beam - Left (Composite) Connector Part Information 12059181 2-Way F Metri-Pack 280 Series, Sealed (GY) Pin Wire Color Circuit No. Function A YE 712 Left Headlamp Low Beam Supply Voltage B BK 250 Ground

Headlamp - Low Beam - Right (Composite) Connector Part Information 12059181 2-Way F Metri-Pack 280 Series, Sealed (GY) Pin Wire Color Circuit No. Function A TN/WH 312 Right Headlamp Low Beam Supply Voltage B BK 650 Ground

Headlamp - Right (Sealed) Connector Part Information 12034372 3-Way F Metri-Pack 800 Series (BK) Pin Wire Color Circuit No. Function A BK 650 Ground B L-GN/BK 311 Right Headlamp High Beam Supply Voltage C TN/WH 312 Right Headlamp Low Beam Supply Voltage

Headlamp and Panel Dimmer Switch - C1 Connector Part Information 15332161 12-Way F GT 150 Series (BK) Pin Wire Color Circuit No. Function A GY 705 5-Volt Reference B BN/WH 230 Instrument Panel Lamps Dimming Control C BK 350 Ground D WH 103 Headlamp Switch Headlamps On Signal E BN/WH 301 Park Lamp Switch On Signal F D-GN 306 DRL On/Off Signal G OG/BK 2090 Dimming Input H GY/BK 2226 Dimming Return J D-BU/WH 1495 Courtesy Lamps On Signal K PU/WH 1382 LED Dimming Signal L PK 1348 Headlamp On Indicator Supply Voltage M PU 328 Interior Lamp Defeat Switch Signal

License Lamp (Passenger/Cargo) Connector Part Information 12110053 2-Way F Wedge Base Type W-2 Sealed (GY) Pin Wire Color Circuit No. Function A BN 2509 Left Rear Park Lamps Supply Voltage B BK 1050 Ground

Marker Lamp - LF Connector Part Information 15300027 2-Way F Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function A BN 2309 Front Park Lamps Supply Voltage B BK 250 Ground

Marker Lamp - RF Connector Part Information 15300027 2-Way F Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function A BN 2309 Front Park Lamps Supply Voltage B BK 650 Ground

Park/Turn Signal Lamp - LF Connector Part Information 12040977 3-Way F M/P 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function A L-BU 2114 Left Front Turn Signal Lamps Supply Voltage B BN 2309 Front Park Lamps Supply Voltage C BK 250 Ground

Park/Turn Signal Lamp - RF Connector Part Information 12040977 3-Way F M/P 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function A D-BU 2115 Right Front Turn Signal Lamps Supply Voltage B BN 2309 Front Park Lamps Supply Voltage C BK 650 Ground

Stop Lamp Switch Connector Part Information 12040551 6-Way F Metri-Pack 480 Series (BK) Pin Wire Color Circuit No. Function A WH 17 Stop Lamp Switch Signal B RD/WH 1540 Battery Positive Voltage C PK 739 Ignition 1 Voltage D PU 420 TCC Brake Switch/Cruise Control Release Signal E L-GN/BK 584 A/T Shift Lock Control Switch Supply Voltage F D-GN/WH 1135 A/T Shift Lock Control Solenoid Supply Voltage

Tail/Stop and Turn Signal Lamp - Left (Passenger/Cargo) Connector Part Information 12160394 3-Way Lamp Socket Wedge Base W3 Right Angle (WH) Pin Wire Color Circuit No. Function A YE 618 Left Rear Turn Signal Lamp Supply Voltage B BN 2509 Left Rear Park Lamps Supply Voltage G BK 850 Ground BK 850 Ground

Tail/Stop and Turn Signal Lamp - Right (Passenger/Cargo) Connector Part Information 12160394 3-Way Lamp Socket Wedge Base W3 Right Angle (WH) Pin Wire Color Circuit No. Function A YE 619 Right Rear Turn Signal Lamp Supply Voltage B BN 2609 Right Rear Park Lamps Supply Voltage G BK 1050 Ground BK 1050 Ground

Trailer Stop/Turn Relay - Left (UY7) Connector Part Information 12129716 4-Way F Metri-Pack 280 Series Flexlock (GY) Pin Wire Color Circuit No. Function 30 OG 1340 Battery Positive Voltage 85 YE 618 Left Rear Turn Signal Lamp Supply Voltage 86 BK 150 Ground 87 YE 1618 Trailer Left Rear Turn/Stop Lamp Supply Voltage

Trailer Stop/Turn Relay - Right (UY7) Connector Part Information 12129716 4-Way F Metri-Pack 280 Series Flexlock (GY) Pin Wire Color Circuit No. Function 30 OG 1340 Battery Positive Voltage 85 D-GN 619 Right Rear Turn Signal Lamp Supply Voltage 86 BK 150 Ground 87 D-GN 1619 Trailer Right Rear Turn/Stop Lamp Supply Voltage

Turn Signal/Hazard Flasher Module Connector Part Information 15332177 16-Way F GT 150 Series (BK) Pin Wire Color Circuit No. Function A D-BU 5364 Left DRL/Turn Supply Voltage B YE 18 Left Rear Stop/Turn Lamp Supply Voltage C L-GN/BK 592 DRL Low Control D D-GN 19 Right Rear Stop/Turn Lamp Supply Voltage E D-GN 5365 Right DRL/Turn Supply Voltage F WH 17 Stop Lamp Switch Signal G L-BU/WH 1314 Left Front Turn Signal Lamp Supply Voltage H D-BU/WH 1315 Right Front Turn Signal Lamp Supply Voltage J RD/WH 540 Battery Positive Voltage K WH 111 Hazard Switch Signal L L-BU/WH 1414 Left Turn Signal Switch Signal M D-BU/WH 1415 Right Turn Signal Switch Signal N BK 350 Ground P-S - - Not Used

Turn Signal/Multi-Function Switch - C1 Connector Part Information 12064862 8-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A D-BU/WH 1415 Right Turn Signal Switch Signal B PK 739 Ignition 1 Voltage C L-BU/WH 1414 Left Turn Signal Switch Signal D-F - - Not Used G TN 28 Horn Relay Control H WH 111 Hazard Switch Signal

Turn Signal/Multi-Function Switch - C2 Connector Part Information 12059800 5-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A YE 307 Headlamp Switch Flash to Pass Signal B L-GN 11 Headlamp Dimmer Switch Signal C-D - - Not Used E BK 350 Ground

Turn Signal/Multi-Function Switch - C3 Connector Part Information 15339058 7-Way F Metri-Pack/150 Series (GY) Pin Wire Color Circuit No. Function G - - Not Used H PK 94 Windshield Washer Switch Signal J GY 478 Windshield Wiper Switch Signal 2 K D-BU 477 Windshield Wiper Switch Signal 1 L-N - - Not Used

Turn Signal/Multi-Function Switch - C4 (K34) Connector Part Information 12047786 4-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A PK 739 Ignition 1 Voltage B GY 397 Cruise Control On Switch Signal C GY/BK 87 Cruise Control Resume/Accel Switch Signal D D-BU 84 Cruise Control Set/Coast Switch Signal

Underhood Lamp Connector Part Information 12052644 2-Way F Metri-Pack 150 Series, Sealed (GY) Pin Wire Color Circuit No. Function A OG 1732 Inadvertent Power Supply Voltage B BK 1250 Ground

Vanity Mirror Lamp - Left (DH6) Connector Part Information 12047663 2-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A OG 1732 Inadvertent Power Supply Voltage B BK 450 Ground

Vanity Mirror Lamp - Right (DH6) Connector Part Information 12047663 2-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A OG 1732 Inadvertent Power Supply Voltage B BK 450 Ground

Begin the system diagnosis with the Diagnostic System Check - Vehicle in Vehicle DTC Information. The Diagnostic System Check will provide the following information

  1. The identification of the control module(s) which command the system.
  2. The ability of the control module(s) to communicate through the serial data circuit.
  3. The identification of any stored diagnostic trouble codes (DTCs) and their status.

The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.
